Mercedes-Benz 300E Service Manual Set – 1986
1,063 Pages • ZIP Download: 68 Printable PDFs • 53.65 MB
Mercedes Models Covered & Key Technical Specifications
Models & Model Codes: 300E (124.030); VIN-identification references only: 1987-1988 260E, 1988 300CE, 1988 300TE Wagon
Sub-models / Variants: 4-Door Sedan 3.0L
Trade Names: Mercedes-Benz E-Class (124 chassis)
Model Years: 1986–1988 (1986, 1987, 1988)
VIN (SRS-equipped 300E): Position 8: B or D identifies an airbag-equipped vehicle.
-
Engine: 3.0L 6-Cylinder (Engine Code 103.983)
-
Displacement: 180.8 cu. in. (3.0L)
-
Horsepower: 177 HP @ 4400 RPM
-
Torque: 115 ft. lbs. @ 2750 RPM
-
Compression Ratio: 9.2:1
-
Fuel System: Fuel Injection
-
Transmission: 4-speed automatic (W4A040)
-
Oil Capacity: 6.9 quarts total (6.3 quarts with filter change)
Mercedes Manual Features & Selected Content Preview
| Publication | Pages |
|---|---|
| 3.0L 6-Cylinder — 1986 Mercedes-Benz 300E, chassis 124.030, engine 103.983; Mitchell Repair Information Company, copyright 1998 | 17 |
| Engine/VIN Identification — shared Mercedes-Benz model references | 2 |
| A/C-Heater System — Automatic | 17 |
| A/C-Heater System Uniform Inspection Guidelines — general reference | 47 |
| A/C System General Diagnostic Procedures | 5 |
| A/C System Precautions | 4 |
| Abbreviations | 12 |
| Air Bag Restraint System | 19 |
| Alternator & Regulator — Bosch | 5 |
| Anti-Lock Brake Safety Precautions | 2 |
| Anti-Lock Brake System | 14 |
| Automatic Transmission Diagnosis — W4A020 & W4A040 | 10 |
| Brake System Bleeding | 3 |
| Brake System Uniform Inspection Guidelines — general reference | 39 |
| Brake System | 12 |
| CIS-E Electronic Control System — 300E | 18 |
| Computer Relearn Procedures — general reference | 2 |
| Cooling System Specifications | 1 |
| Rear Window Defogger — general reference | 2 |
| Drive Axle | 16 |
| Drive Belt Routing | 10 |
| Drivetrain Systems Uniform Inspection Guidelines — general reference | 48 |
| Electrical Component Locator — 300E | 14 |
| Electrical System Uniform Inspection Guidelines — general reference | 61 |
| Electrostatic Discharge Warning — Basic Information | 2 |
| Emission Control Applications | 1 |
| Emission Control Visual Inspection Procedures — general reference | 15 |
| Engine Cooling Fan | 7 |
| Engine Overhaul Procedures — General Information | 34 |
| Engine Systems Uniform Inspection Guidelines — general reference | 124 |
| Exhaust System Uniform Inspection Guidelines — general reference | 10 |
| Fuel Evaporation System | 2 |
| Fuel Injection System — Bosch CIS-E, shared Mercedes-Benz article | 33 |
| Fuses & Circuit Breakers | 3 |
| Gear Tooth Contact Patterns — general reference | 3 |
| General Cooling System Servicing | 3 |
| How to Use System Wiring Diagrams | 9 |
| Inspect & Replace Airbag Unit — recall bulletin 87V073000 | 1 |
| Instrument Panel — Standard | 4 |
| Jacking & Hoisting | 2 |
| Maintenance Information — Fluid Specifications & Capacities | 10 |
| Metric Conversions | 4 |
| PCV System | 3 |
| Passive Restraint System Inspection — shared European-import reference | 18 |
| Pre-Alignment Checks | 1 |
| Scheduled Services | 31 |
| Service Indicator & Warning Lights | 3 |
| Starter — Bosch | 6 |
| Steering Column | 3 |
| Power Steering System | 6 |
| Steering Uniform Inspection Guidelines — general reference | 75 |
| Steering Wheel & Column Switches | 2 |
| Front Suspension | 7 |
| Rear Suspension | 5 |
| Suspension Uniform Inspection Guidelines — general reference | 75 |
| Symptom Checklist — general worksheets | 14 |
| System Wiring Diagrams — 300E | 18 |
| Automatic Transmission Removal & Installation | 1 |
| Manual Transmission Servicing — 190D/190E application table | 2 |
| Troubleshooting — Basic Procedures, general reference | 76 |
| Tune-Up — 6-Cylinder | 5 |
| Emission Vacuum Diagrams — other Mercedes-Benz models | 2 |
| Waveforms — Injector Pattern Tutorial, general reference | 35 |
| Wheel Alignment Specifications & Procedures | 4 |
| Wheel Alignment Theory & Operation | 4 |
| Wiper/Washer System | 4 |
| Wiring Diagram Symbols | 5 |
| Wiring Diagrams — 300E | 11 |
The system articles provide repair procedures and diagnostic tests, while the general references add inspection criteria, troubleshooting background, and workshop worksheets. Shared application tables and multi-model articles include references to 260E, 300CE, 300TE, 190, 420, and 560 models; these do not represent complete vehicle coverage for those models.
Transmission coverage: The automatic-transmission diagnosis article refers vacuum-control, hydraulic-pressure, and road-test procedures to a separate “Auto Trans Overhaul — W4A020 & W4A040” article that is not included. The manual-transmission servicing article lists 190D/190E applications.
Vacuum-diagram coverage: The separate emissions vacuum-diagram article does not include a 300E diagram. The automatic climate-control article does contain the two production-specific 300E vacuum diagrams described below.
PDF Text Search, Wiring Detail and File Contents
Search and diagram detail: Article text is searchable, but lettering within diagram images is not included in text searches. No embedded PDF bookmarks are provided. Small wiring-grid, ABS, and CIS-E labels require zooming; some fine CIS-E lettering remains soft when enlarged.
The ZIP contains 68 printable English-language PDFs totaling 1,063 pages, including 479 pages of general inspection guidelines. The total includes 24 introductory pages within those guidelines and four article-closing pages.
Engine, CIS-E and Chassis Service
The following highlights are a selection of the contents, rather than a complete contents list. Additional topics include PCV operation and serpentine-belt routing.
-
Engine repair: Step-by-step procedures for engine/transmission removal, cylinder-head service, timing-chain replacement, camshaft timing checks, valve-guide work, and internal component inspection.
-
CIS-E diagnosis: Fuel-pressure and delivery tests, cold-start checks, residual-pressure diagnosis, lambda control, idle-speed stabilization, and EZL ignition-system operation.
-
Automatic transmission: W4A040 operating descriptions, symptom-based troubleshooting, and a separate removal-and-installation procedure.
-
Brakes and ABS: Disc-brake and caliper service, bleeding, parking-brake adjustment, and Bosch ABS sensor, relay, solenoid-valve, and hydraulic-unit checks.
-
Steering and chassis: Power-steering pump and gear overhaul, front spring/strut service, rear suspension and axle removal, differential adjustment, and wheel alignment.
-
Automatic climate control: Operating checks, vacuum-circuit tests, sensor checks, control-panel service, and evaporator/heater-core removal and installation.
-
Electrical and SRS: Component locators, starting/charging and body-circuit diagrams, plus airbag-system testing, inspection, disabling/activation, and disposal procedures.
Suited to readers with prior workshop experience and access to electrical test equipment, fuel-pressure gauges, and the specialist equipment identified for the work.
Engine Repair and Workshop Equipment
Beyond the major removal procedures, the engine article covers rocker arms and hydraulic compensating valves, valve springs and seals, piston/rod assemblies, crankshaft and bearings, engine oiling, the oil pump, and water pump. Tables provide piston, ring, bearing, valve, spring, camshaft, and component-specific torque specifications.
Special-service equipment includes Guide Sleeve 103 589 00 14 00, Assembly Fixture 102 589 00 59 00, Supporting Bridge 102 589 01 59 00, and dedicated intake/exhaust valve-guide mandrels. The cautions address valve damage if head-on spring work lacks compressed-air support and oil-pan-gasket damage during front timing-cover installation.
CIS-E Fuel and Electronic Controls
Diagnosis connects fuel delivery and pressure readings with electrical checks of the airflow-sensor plate and potentiometer, electro-hydraulic actuator/differential-pressure regulator, coolant sensor, ECU, oxygen sensor, fuel-pump relay, and idle-speed controls.
The lower-chamber tests relate pressure differences to regulator current and coolant temperature. This gives the reader a way to distinguish fuel-supply problems from sensor, wiring, or control faults. Equipment references include the Bosch KDJE-P600 On-Off Ratio Tester, Fuel Pressure Gauge 100 589 00 21 00, and related adapters.
Transmission, Axle and Suspension Detail
The W4A040 article explains the compound planetary gear sets, K-1/K-2 clutches, B-1/B-2 brake bands, B-3 disc brake, primary/secondary pumps, valve body, and pressure-control circuits. Its troubleshooting charts distinguish slipping, harsh engagement, shift complaints, oil leaks, and abnormal noises.
Drive-axle coverage extends to axle-shaft and differential disassembly, pinion-depth measurement, bearing preload, and ring-gear backlash adjustment. The chassis articles add wheel-bearing inspection, transverse-link bushings, rear suspension links, wheel carriers, and alignment data.
Brake Service and ABS Diagnosis
The ABS article identifies Test Adapter 126-589-09-21-00 and separates front-wheel and rear-differential sensor checks from relay, valve, and hydraulic-unit testing. Its cautions explain how hammering sensor rings can corrupt wheel-speed signals and how abrasive cleaning can damage chrome-plated caliper pistons.
Climate Control and Electrical References
Automatic climate-control coverage follows the push-button panel, in-car and heater temperature sensors, heater valve, ECU, blower-speed controller, switchover valves, air doors, expansion valve, auxiliary fan, and evaporator temperature regulator.
The diagrams “Vacuum Diagram — 300E (Up To August 1986)” and “Vacuum Diagram — 300E (As of September 1986)” distinguish the production change before vacuum routing is selected.
Electrical examples include “Wiring Diagram For 300E CIS-E Fuel Injection System,” “ABS System Wiring Diagram (300 & 260 Series),” “Cooling Fan Circuit,” and “Charging Circuit.” Component locators and vehicle wiring cover the fuse block, under-dash areas, instrument panel, rear compartment, exterior lighting, power windows, seats, locks, mirrors, and wiper/washer circuits.
SRS Testing and Service Precautions
For airbag-equipped cars, the restraint-system article identifies SRS Tester 126-589-10-21-00 and provides warning-light and component tests, post-collision inspection information, and disposal procedures. Removal/installation instructions are not provided for the SRS control unit, voltage converter, or energy accumulator.
Work involving SRS, loaded coil springs, pressurized fuel or brake systems, hot cooling-system components, or A/C refrigerant should follow the isolation, support, depressurization, and handling precautions stated in the relevant article.
A Preview of Engine-Oil and CIS-E Test Data
The engine-oiling section lists oil pressure of 7.1 psi at 700–780 RPM and 42 psi at 3000 RPM.
The CIS-E system-pressure test specifies 76.9–79.8 psi with the engine off and fuel pump operating. Its fuel-pump delivery check specifies 1 liter in 50 seconds with 11.5 volts supplied to the pump.
