Repair your Snowmobile with the help of this professional electronic PDF download version of the detailed and specific Yamaha Mountain workshop manual / repair guide.
Specs:
Production/model years: 1998, 1999, 98, 99
Model specification: Yamaha Motor Corporation, Ltd
1998 Yamaha MSRX700PB Mountain SRX
1998 Yamaha MSRX700PB Mountain SRX700
1998 Yamaha SRX600/B
1998 Yamaha SRX600/SB
1998 Yamaha SRX700/B
1998 Yamaha SRX700/SB
1999 Yamaha SRX600
1999 Yamaha SRX700
Manual Language: English
Manual format: PDF / e-book (zip)
Printable: Yes
Delivery: Download link will appear on the checkout page after your payment is complete.
DIY
Related:
2002-2006 Yamaha SX Viper 700, VMAX, Mountain Max, Venture snowmobile manual
and use this PDF at repairloader.com: Yamaha Motor Corporation, Ltd SX Viper 700, VMAX, Mountain Max, Venture manual.
Specs:
Production/model years: 2002, 2003, 2004,
17.99 USD
This complete digital download version is the same OEM manual used by official certified professional Yamaha snowmobile mechanics and by local dealership / technicians or engineers for service, maintenance and repairs.
#
Between 1985 to 1997, the Yamaha Motor Company developed a motorcycle called the Yamaha SRX. No need to be confused with the Yamaha Sidewinder SRX which is a snowmobile.
Yamaha SRX600 snowmobile's machine identification is defined with frame serial number and engine serial number. The frame serial number is located on the right-hand side of the frame. And the engine serial number is located on the right-hand side of the crankcase.
Sheave gauge is used to measure the sheave distance and for offset adjustment. A dial gauge is used for run out measurement. A fuel level gauge is used to measure the fuel level in the float chamber. An adjusting screwdriver is used to adjust the damping force in the front suspension. These all steps are used to tune up the Yamaha SRX600 snowmobile.
A piston pin puller is used to remove the piston pin. The rotor holding tool is used to remove the starter pulley. The rotor holding puller removes the magneto rotor and the cooling system tester checks the cooling system. These steps are followed for engine service.
For power train service, primary sheave holder hold the primary sheave, sheave puller remove primary sheave, clutch spider separator and clutch separator adaptor disassemble and assemble the primary sheave, clutch bushing jig kit removes and installs primary sheave bushing, clutch bushing press removes and installs the post bushings and track clip installer installs the track clip.
For carburation service, the mity vac is used to check the fuel pump. A pocket tester is necessary for checking the electrical components. An Electro tester is used to check the electrical system.
