Massey-Ferguson MF 35, 50 & 65 Tractor Service & Repair Manual — 1954–1975
361 Pages • Printable PDF • 58.08 MB • Download
Massey-Ferguson Models Covered & Key Technical Specifications
Models: MF 35, MF 40 (power-steering pump section), MF 50, MF 65 (G-176 gasoline, GB-176 LP-Gas/Hi-Altitude gasoline, 4-A-203 diesel, AD4.203 diesel), MF 165 (G-176 gasoline/GB-176 LP-Gas specifications only), MF 3165 (G-176 gasoline specifications only), MH 50 (internal hydraulic system), TO 35, TO 40 (power-steering pump section)
Sub-models / Variants: Utility, Multi-Purpose, Hi-Arch, Standard, Row Crop, Diesel, Gasoline, LP-Gas
Model Years: 1954–1975 (1954, 1955, 1956, 1957, 1958, 1959, 1960, 1961, 1962, 1963, 1964, 1965, 1966, 1967, 1968, 1969, 1970, 1971, 1972, 1973, 1974, 1975)
Transmission Variants: Dual Range and Multi-Power (MF 35, MF 50, MF 65); 1500-540 and 1700-540 transmission speed designations (MF 65 with AD4.203 engine)
Power-Steering Serial Breaks: MF 50 — separate valve/cylinder design prior to Serial No. 516 788; integral valve/cylinder-end design after Serial No. 516 788. MF 65 — corresponding designs prior to and after Serial No. 650 369. MF 65 Diesel — separate pump/reservoir arrangement prior to Serial No. 685 996; direct-injection steering pressure specification applies to Serial No. 685 996 and up.
AD4.203 Engine Identification: MF 65 application starting with tractor Serial No. 682157; engine serial numbers begin at 2900251. “CL” identifies chrome-plated cylinder liners; engine Serial No. 2939036 and up uses cast iron liners. An additional “C” identifies engines fitted with Perkins No. 41314033 oil pump.
4-A-203 Engine Changes: Shoulderless valve guides — engine Serial Nos. 2813333–2813475 and 2814187 and up. Segmented No. 3 compression rings — engine Serial Nos. 2810500–2810543, 2810561–2810566, 2812689–2812753, and 2812813 and up. Early solenoid-type Thermostart — prior to engine Serial No. 2804837. Water pump shaft/pulley change — engine Serial No. 2806843 and up. Starter change — Delco-Remy 1108662 prior to engine Serial No. 677170; Delco-Remy 1107503 at engine Serial No. 677170 and up.
Clutch Serial Breaks: Combination coil/Belleville spring dual clutch — 35 (MF & TO) since tractor Serial No. 177395, MF 50 since tractor Serial No. 515395, and all MF 65 models. Clutch linkage/release mechanism — MF 65 prior to and after Serial No. 692 932; later MF 50 arrangement after Serial No. 533 422.
MF 65 Rear Axle and Differential Changes: Earlier wheel axle assemblies up to Serial No. 662236 (Lo-Clearance) and 660007 (Hi-Clearance); later assemblies after those numbers. Pinion bearing components change at transmission Serial No. CL26861L2; differential-lock pedal housing changes at transmission Serial No. SNY51686.
Hydraulic System Serial Ranges: Ferguson 35 — 2,000 PSI system up to and including 169395, 169408–169418, 169429–169466, and 169555–169566; 2,500 PSI system at 169396–169407, 169419–169428, 169467–169554, and 169567 and up. MH 50 Utility — 2,500 PSI system since Serial No. 500630; MH 50 Row Crop since Serial No. 500001. All MF 50 and MF 65 tractors use the 2,500 PSI system described in this section.
MF 65 LP-Gas Fuel-System Serial Ranges: Zenith LPEX91 carburetor (No. 12256) prior to Serial No. 673300; Zenith PC1J10 (No. 12447) from 673300 thru 692262; Zenith PC2J10 (No. 12726) at 692263 and up. Separate Zenith Type C final regulator prior to Serial No. 673300; final regulator integral with the carburetor at 673300 and up.
MF 65 Gasoline/LP-Gas Distributor Change: Prior to Serial No. 702826 — Delco-Remy 1112583 (gasoline) or 1112589 (LP-Gas); Serial No. 702826 and up — Delco-Remy 1112644.
Gasoline/LP-Gas Starter Serial Ranges: MF 165 — Delco-Remy 1107329 prior to 643013659; 1108324 at 643013659 and up. MF 3165 Utility — 1107329 prior to 647002021; 1108324 at 647002021 and up. MF 3165 Turf — 1107329 prior to 649000161; 1108324 at 649000161 and up. MF 65 Agricultural — 1107654 prior to 691660; 1107226 at 691660 and up. MF 65 Utility — 1107226 from 691669 thru 703203; 1107329 at 703204 and up.
MF 65 Gasoline/LP-Gas Generator Serial Ranges: Delco-Remy 1100998 prior to Serial No. 662839. Delco-Remy 1100362 from 663016 thru 694648 (gasoline) or 694698 (LP-Gas). Delco-Remy 1100435 at 694649 and up (gasoline) or 694699 and up (LP-Gas).
-
Engine Displacement: 176 cu. in. (G-176/GB-176 models), 203.5 cu. in. (4-A-203/AD4.203 models)
-
Compression Ratios: Gasoline 7.1:1 to 8.1:1; LP-Gas 8.1:1 to 8.75:1; Diesel 17.4:1 (4-A-203), 18.5:1 (AD4.203)
-
Engine Torque: Gasoline 155 ft.-lbs.; LP-Gas 155 ft.-lbs. (MF 165) or 151 ft.-lbs. (MF 65), with peak torque between 1150 and 1250 RPM in the G-176/GB-176 specification section
-
Engine Speed: G-176/GB-176 — 2000 RPM rated, 2200–2250 RPM high idle; 4-A-203 — 2000–2050 RPM rated, 2100–2150 RPM high idle; AD4.203 in MF 65 — 2000 RPM rated, 2175 RPM high idle. High-idle figures are no-load specifications.
-
Valve Tappet Clearance (Hot): G-176/GB-176 — 0.016 inch (intake), 0.018 inch (exhaust); 4-A-203/AD4.203 — 0.010 inch (intake and exhaust)
-
Steering Relief Valve Pressure: 1100–1200 PSI, except MF 65 Diesel with direct-injection engine, tractor Serial No. 685 996 and up — 1500 PSI
Massey-Ferguson Manual Features & Selected Content Preview
Massey-Ferguson factory service manual sections for MF 35, MF 50, and MF 65 tractors, covering mechanical repair, troubleshooting, and component specifications. MF 165 and MF 3165 coverage is limited to the applicable G-176/GB-176 engine specifications. That specification section is marked Reissue 9/67.
Front axle coverage: The opening MF 50/MF 65 front axle chapter is missing its printed pages 2–3.
PDF Search, Diagram Detail, and Page Count
Text search and navigation: Embedded text supports searches across the service chapters, although recognition errors and unindexed drawing labels limit some results. Small labels in the inspected electrical diagrams are readable when enlarged. Chapter bookmarks are not available; the only working bookmark opens an additional notice page.
One printable English-language PDF contains 361 pages, including 337 service pages, 23 blank pages, and one additional notice page.
Steering, Diesel Overhaul, and Drivetrain Service
The following selected topics show the main repair coverage. Other included material covers front wheel hubs, instrument-panel removal, and sheet-metal servicing.
-
Front axle and steering: Wide, single-wheel, and twin-wheel axle service; manual steering gear, pedestal and drag-link repair; power-steering pump, cylinder, and valve procedures.
-
Diesel engine overhaul: Step-by-step procedures for engine removal, internal disassembly, inspection, reassembly, and timing on the covered MF 65 diesel engines.
-
Fuel and air systems: Fuel-system troubleshooting, priming, lift-pump service, injection-pump removal and installation, injector testing, and Thermostart diagnosis for the 4-A-203.
-
Clutch and transmission: Dual-clutch overhaul, release-linkage adjustment, conventional transmission repair, and Multi-Power hydraulic-clutch and planetary-gear servicing.
-
Rear drive and PTO: MF 65 differential, pinion, rear axle, differential-lock and brake repair, plus PTO shaft and belt-pulley service sections.
-
Internal hydraulics: Lift-fault troubleshooting, draft and position-control adjustment, lift-cover overhaul, and scotch yoke pump disassembly, inspection, and reassembly.
-
Electrical testing: Wiring diagrams, starting-circuit resistance tests, starter inspection, generator tests, voltage-regulator adjustment, and charging-system troubleshooting.
Suited to mechanics familiar with tractor splitting and precision engine measurements, with access to lifting equipment, pullers, and electrical test instruments.
Steering and Power-Steering Coverage
Separate procedures distinguish early and later valve/cylinder arrangements and the different axle configurations. The pump sections cover Barnes, Cessna, and Wooster units; early MF 65 diesel illustrations also identify the Hobourn-Eaton pump and separate reservoir.
The Power Steering Oil Flow drawing shows right- and left-turn operation. Pump identification and variant-specific parts notes help match replacement components to the tractor’s steering arrangement before assembly.
Before servicing heavy axle or hydraulic components, release hydraulic pressure and use suitable lifting equipment.
Diesel Engine Overhaul and System Limits
The engine chapters cover cylinder-head work, piston and connecting-rod inspection, liner replacement, crankshaft bearings, oil seals, camshaft service, and timing checks. General engine chapters add valve-seat reconditioning and cylinder-sleeve inspection methods.
Detailed fuel, lubrication, cooling, and electrical service chapters apply to the 4-A-203. The AD4.203 material consists of engine specifications and overhaul procedures, including the Side Cross Sectional View of AD4.203 Engine.
The AD4.203 chapter explains how deglazing can damage chrome-plated liners and how excessive cylinder-head nut torque can cause thread “popping,” liner distortion, and repeated head-gasket failure. It also describes the early-block modification for longer cylinder-head studs.
Fuel Injection, Cooling, and Electrical Diagnosis
The C.A.V. DPA Distributor Type Fuel Injection Pump illustration accompanies removal, installation, and timing information. Internal injection-pump repair is assigned to an authorized C.A.V. service station. Injector coverage includes opening-pressure, leakage, spray-pattern, and servicing procedures.
Lubrication coverage includes oil-pump inspection and filter service. Cooling sections address radiator removal, water-pump overhaul, thermostat testing, and fan-belt adjustment.
The Electrical System wiring diagram and Battery Cable Resistance Test drawings support circuit checks. Starter, generator, and regulator tests help distinguish wiring faults from component faults before disassembly.
Clutch, Multi-Power, and Rear Drive
The clutch chapters distinguish the combination coil/Belleville spring unit from the dual Belleville spring design. They include adjustment tools, testing specifications, and troubleshooting; gauge FT 352 is identified for the dual Belleville spring clutch.
Multi-Power coverage reaches the hydraulic clutch, input-shaft retainer, overrunning clutch, and planetary gearing. The Clutch Details and Relative Location of Parts illustration supports assembly identification. The conventional transmission chapter also identifies the later reverse cluster’s 56 loose needle bearings, which can be lost during disassembly.
MF 65 rear-drive procedures include pinion preload, axle endplay, differential-lock service, and brake assembly work. Separate sections cover live and ground-speed PTO arrangements, shaft extensions, and light- and heavy-duty belt pulleys.
Hydraulic Lift Troubleshooting and Pump Repair
The hydraulic fault charts connect symptoms such as failure to raise, failure to lower, and erratic lift action with possible causes and checks. This supports diagnosis before removing the lift cover or pump.
The Hydraulic Pump—Exploded View and old/new pump illustrations distinguish construction details. Coverage includes control-linkage adjustment, oscillator service, and valve-seat reseating with tool N-6007. The hydraulic section explains that these repairs do not require splitting the tractor.
Crankshaft Endplay and Head-Torque Examples
For the 4-A-203, crankshaft endplay is listed at 0.002–0.010 inch in the crankshaft and main-bearing specifications. The engine chapters pair dimensional inspection data with component servicing procedures.
The G-176/GB-176 specification section lists cylinder-head torque at 70–75 ft.-lbs. This figure belongs to those gasoline/LP-Gas engine specifications and is separate from the diesel cylinder-head data.
