Yamaha XVS95CE(C) Owner's Manual, 2013 (P/N LIT-11626-27-09)

94 Pages • 1 Printable PDF (English) • Download

4.7starstarstarstarstar_half(3)
$11.85 Instant Download / No Shipping Fees
or

Credit/debit card, Apple Pay or Google Pay

30-day refunds for defective files or manuals not as described. Refund policy.

print
Save & print
Keep a copy on your device
lock
Secure Payment
Stripe

Yamaha Models Covered & Key Technical Specifications

Model: XVS95CE(C)

Sub-models / Variants: XVS95CE, XVS95CEC

Model Year: 2013


  • Engine displacement: 942 cm³

  • Engine configuration: Air-cooled 4-stroke, SOHC V-twin

  • Transmission: Constant mesh 5-speed

  • Fuel capacity: 12.2 L (3.22 US gal)

  • Tire pressure (Front/Rear): 225 kPa (33 psi) / 250 kPa (36 psi)

  • Maximum load: 208 kg (459 lb)

  • Battery model: YTZ14S, 12V, 11.2 Ah

  • Spark plug: NGK/CPR7EA-9

Yamaha Manual Features & Selected Content Preview

This Yamaha owner's manual covers operation, preventive maintenance, and minor repair for the XVS95CE(C). Publication details are P/N LIT-11626-27-09, first edition, January 2013, with Yamaha document code 1TP-28199-10 printed on the cover.

PDF Access and Included Pages

Text search and diagram viewing: PDF text search is not available, and there are no embedded PDF bookmarks; navigation relies on the printed contents and index. Small hose-routing and troubleshooting labels require enlargement for comfortable reading. Diagonal watermarks cross portions of the text and illustrations.

Supplied as one printable English PDF with 94 pages. The total includes seven front-matter pages, eight consumer-information pages, a two-page index, three promotional pages, one blank page, and the back cover.


Owner Maintenance, Controls and Starting Checks

The following topics are a selection of the manual's contents, rather than a complete table of contents. Other examples include recommended shift points and engine break-in guidance.

  • Engine maintenance: Engine oil and filter cartridge replacement, spark-plug inspection and installation, air-filter replacement, and separate emission-control maintenance schedules.

  • Controls and belt drive: Clutch-lever free-play adjustment, throttle-grip checks, and illustrated drive-belt slack measurement, with belt adjustment referred to a Yamaha dealer.

  • Brakes and chassis: Brake-pad and fluid-level inspections, cable and pivot lubrication, shock spring-preload adjustment, and front-fork, steering, and wheel-bearing checks.

  • Electrical maintenance: Battery care and storage, fuse identification and replacement, and replacement procedures for the halogen headlight and turn signal bulbs.

  • Starting diagnostics: Ignition circuit cut-off checks, the multi-function meter's self-diagnosis display, and a troubleshooting chart covering fuel, battery, ignition, and compression.

  • California emissions: Canister and hose inspections for the evaporative-emission-control system, with vacuum and emission hose-routing diagrams identifying the connections.

Written for owners learning operation, inspection, and basic maintenance, this manual directs work beyond the owner's tools or experience to a Yamaha dealer.

Engine, Fuel System and Maintenance Schedules

The maintenance section separates a seven-item emission-control chart from a 27-item general maintenance and lubrication chart. Initial and recurring mileage/time intervals cover valve-clearance checks, drive-belt inspections, air-filter replacement, and steering-bearing and swingarm-pivot repacking.

Hydraulic brake schedules address fluid changes, master-cylinder and caliper internal components, and hose replacement. Asterisk-marked jobs require special tools, data, and technical skills.

Fuel and drivetrain identification: Configuration data covers fuel injection, a wet multi-disc clutch, and belt final drive. Throttle-body identification differs by variant: 1TP1 00 for XVS95CE and 1TP2 10 for XVS95CEC.

Step-by-step instructions for engine oil and filter cartridge replacement distinguish oil changes with and without a new filter. Related service data includes refill quantities, filter and drain-bolt torques, fuel reserve quantity, and spark-plug gap and installation specifications.

The air-filter section warns that compressed-air cleaning damages the disposable oil-coated paper element, while operation without the element can cause excessive piston and cylinder wear.

Brake, Chassis and Tool References

Factory data covers throttle free play, cold tire pressures, maximum load, and minimum tread depth. Tire specifications identify tubeless Bridgestone Exedra G721 front and G722 rear tires.

Front and rear brake-pad and fluid-level illustrations accompany the hydraulic single-disc brake inspections. DOT 4 guidance addresses sealed-container requirements, incompatible fluid mixing, and water contamination that can cause vapor lock; incorrect hydraulic maintenance can reduce braking ability.

Illustrated references also include left- and right-side component views, the controls-and-instruments layout, and the drive-belt slack measurement diagram. Supporting instructions address stabilizing the motorcycle for front- or rear-wheel work.

Tool references cover the owner's tool kit, separate spark-plug wrench, shock-preload special wrench and extension bar, belt-tension gauge, oil-filter wrench, and torque wrench.

Electrical Checks and Repair Limits

The ignition circuit cut-off flowchart distinguishes sidestand, clutch, and neutral-switch faults. It helps narrow down an interlock-related starting problem before repair work is planned.

The no-start chart separates basic system checks from conditions requiring dealer attention. The multi-function meter displays electrical-circuit error codes for dealer follow-up; this manual does not provide wiring diagrams or service-level electrical fault isolation.

Lighting and battery care: Owner-replaceable headlight and turn signal bulbs are distinguished from dealer-directed LED tail/brake light and license plate light work. The YTZ14S VRLA battery section warns that a conventional charger can damage the battery and specifies constant-voltage charging.

Valve-clearance adjustment, fuel-injection synchronization, drive-belt adjustment, and brake-fluid replacement are dealer-directed. Internal engine or transmission teardown and full hydraulic-brake rebuilding are outside this owner's manual's repair scope.

Pre-Operation Checks and Storage

The pre-operation checklist covers fuel and oil, both brakes, clutch and throttle operation, control cables, wheels, and tires. Pedals, levers, sidestand operation and switch function, chassis fasteners, and lights are also included.

Long-term storage coverage addresses fuel stabilization, cylinder corrosion protection, cable and pivot lubrication, battery removal and charging, tire support, and exhaust protection. The storage section also calls for necessary repair work before the vehicle is put away.

Examples of Oil-Service and Free-Play Specifications

Oil-change data specifies 3.70 L without oil-filter cartridge replacement or 4.00 L with a new cartridge. The oil-filter cartridge tightening torque is 17 Nm.

Clutch-lever adjustment uses a free-play range of 5.0–10.0 mm. Drive-belt inspection specifies 6.0–8.0 mm of slack with the motorcycle on its sidestand and 45 N applied using a belt-tension gauge.
