1997 Nissan Maxima A32 Automatic Transaxle Service Manual

1997 Nissan Maxima A32 Automatic Transaxle Technical Documentation

• Covers 1997 Nissan Maxima A32 vehicles equipped with the RE4F04A 4-speed automatic transaxle and VQ30DE engine
• Original OEM publication, Nissan Motor Corporation, Ltd., section AT, 1997 model year
• Contains 47 wiring diagrams, 15 hydraulic control schematics, and 12 diagnostic flow charts
• Accessible from your device as soon as the order is placed
• OCR text layer lets you jump to a torque spec by keyword
• Suitable for printing individual sections for shop-floor use
• Permanent availability in your purchase account — no re-buy required
• This specific edition provides the factory-authorized diagnostic parameters for the RE4F04A transmission control unit and solenoid performance monitoring

Diagnostic and Service Content

The 1997 Nissan Maxima A32 service documentation provides deep technical insight into the RE4F04A automatic transmission system. It details the operational logic of the A/T control unit, including input/output signal processing from the inhibitor switch, throttle position sensors, and vehicle speed monitoring components. The text covers what factory workshop documentation is structured to provide, focusing on the diagnosis of electrical faults within the transmission wiring harnesses and the interpretation of diagnostic trouble codes through the CONSULT diagnostic system.

Specification Highlights

Included technical data spans comprehensive resistance values for internal solenoid valves, such as the 20–40 ohm range for shift solenoids A and B, and the 2.5–5 ohm specification for the line pressure solenoid. Documentation lists the A/T fluid temperature sensor resistance at 2.5 kΩ for cold conditions at 20°C (68°F), dropping to approximately 0.3 kΩ at 80°C (176°F). The manual also defines fluid inspection criteria, including color and odor analysis for detecting frictional material wear or water contamination. Reference only — always consult a certified technician before performing service on this equipment.

An official 1997 Nissan Maxima A32 OEM service manual covering the RE4F04A automatic transaxle, documenting electronic control, hydraulic circuit diagnostics, and solenoid performance specifications for the 1997 model year production fleet.
