1999-2003 KTM 250/300/380 SX/MXC/EXC Repair Manual (156 P.)
Complete engine service and repair documentation for KTM's liquid-cooled two-stroke motocross lineup. Technical specifications for TVC exhaust control systems, carburetor settings, and transmission assembly. Art No 3206004-E
Manual Preview
Sample pages from the 1999-2003 KTM 250/300/380 SX/MXC/EXC Repair Manual (156 P.) manual
Purchase & Download
Models Covered & Key Technical Specifications
KTM 250 SX, 300 SX, 380 EXC, 250 MXC, 300 MXC, 380 MXC (3206004-E) — 1999–2003 Comprehensive Index & Reference Manual | Engine Series Repository.
- Calibrated Displacement Data: 249 ccm (250 SX), 297 ccm (300 SX), and 368 ccm (380 EXC) is specified as the liquid-cooled single-cylinder engine cylinder volume Matrix.
- Measured Torque Output: For primary sprocket fastening, 150 N·m (110 ft·lb) provides the crankshaft main bearing retention force Standards.
- Critical Spark Gap Setting: The electrode distance is designed for 0.60 mm (0.024 in) spark plug clearance Protocol.
- Universal Coolant Volume: The system requires 1.3 litres of 40% antifreeze and 60% water mixture cooled to at least -25°C (-13°F) Architecture.
- Maximum Fuel Tank Capacity: Tank volume reaches 7.5–12 L (2.0–3.2 US gallons) across model variants Parameters.
- Documented TVC Control Range: The exhaust valve advance initiates at 5000–5900 rpm and completes opening at 7000–7750 rpm Norms.
Professional Workshop Service Manual & Technical Specifications
Comprehensive Overhaul Manual: KTM 250 SX, 300 SX, 380 EXC, 250 MXC, 300 MXC, 380 MXC (1999-2003) Service-Portfolio
Service-Level: KTM 250 SX (1999-2003), KTM 300 SX (1999-2003), KTM 380 EXC (1999-2003), KTM 250 MXC (1999-2003), KTM 300 MXC (1999-2003), KTM 380 MXC (1999-2003) // Engineering-Metrics: Single-Cylinder Two-Stroke Engine Systems // Service-Level: Liquid-cooled with Twin Valve Control exhaust system.
| Specification | Document Coverage | Support Resources |
|---|---|---|
| Engine Systems | Complete technical data for 249 cc, 297 cc, and 368 cc displacement engines | Sections 3-9 provide detailed specifications |
| Transmission and Clutch | Five-speed gearbox with hydraulic operation | Assembly procedures and component service documented |
| Fuel and Ignition | Carburetor adjustment tables for various altitudes and temperatures | Kokusan and SEM ignition systems documented |
Service procedures are grouped by engine disassembly phases, including cylinder head removal, piston and connecting rod service, crankshaft bearing inspection, transmission shaft assembly, and clutch mechanism maintenance. The document catalogs systems across electrical configuration, exhaust control, and ignition timing, while connecting intake flange service to reed valve housing operations. Repair information is provided for engine housing separation, transmission mainshaft preparation, kickstarter mechanism adjustment, and complete engine reassembly sequences. Technical content addresses crankshaft seal ring installation, bearing preload specifications, and clutch disc stack composition alongside shift mechanism preassembly tasks. Verification procedures are included for grooved ball bearing clearance, needle bushing fit tolerance, and pressure cap assembly.
The manual documents torque specifications for the cylinder head flange bolts, primary sprocket nut, inner clutch hub fastening, and crankcase cover assembly to ensure proper component alignment retention. Comprehensive troubleshooting coverage identifies carburetor operating ranges, TVC system timing verification, hydraulic clutch bleeding procedures, and electrical system testing protocols. Wiring diagrams depict ignition circuit topology, generator output connections, voltage regulator integration, and lighting system configuration for model years 1999 through 2003 variants across European, Australian, and USA specifications.
