Ferrari 348 tb, 348 ts, 348 Spider, 348 GTB, 348 GTS & Mondial t Workshop Manual - Technical Specifications and Repair Procedures 1989-1995
Product Gallery
Sample pages from the Ferrari 348 tb, 348 ts, 348 Spider, 348 GTB, 348 GTS & Mondial t Workshop Manual - Technical Specifications and Repair Procedures 1989-1995 manual
Purchase Information
Technical Specifications
- Document Number / Seller:
- 24230 / Lisa Taylor
- File Size:
- 270.20 MB
- File Type:
- Language:
- English, Italian, Spanish, German
- Pages:
- 465
- Printable:
- Yes
- Estimated Download Time:
- 5.53 Minutes
- Delivery Format:
- Digital (PDF) - Instant Access
- Category:
- Car
- Brand:
- Ferrari
- Reviewed and Approved:
- Dec 30, 2025
Ferrari Models and Parts Covered in this Car Manual
- Ferrari 348 tb (1989-1993)
- Ferrari 348 ts (1989-1993)
- Ferrari 348 Spider (1993-1995)
- Ferrari 348 GTB (1993-1994)
- Ferrari 348 GTS (1993-1994)
- Ferrari Mondial t (1989-1993)
Complete Manual Information
Ferrari 348 tb, 348 ts, 348 Spider, 348 GTB, 348 GTS & Mondial t Service & Repair Manual - 1989-1995
This workshop manual provides the necessary technical data and step-by-step instructions to maintain factory-spec performance and ensure the long-term reliability of these high-performance vehicles. By following official factory procedures, technicians and owners can minimize downtime and execute repairs with the precision required for Ferrari’s sophisticated mechanical and electronic systems.
Model Coverage & Hardware Details:
- Ferrari 348 tb (1989–1993)
- Ferrari 348 ts (1989–1993)
- Ferrari 348 Spider (1993–1995)
- Ferrari 348 GTB (1993–1994)
- Ferrari 348 GTS (1993–1994)
- Ferrari Mondial t (1989–1993)
- Engine Control System: Bosch Motronic M2.5 Electronic Control Unit (ECU).
- Engine Configuration: 90° V8, 3.4 Liters (3405 cc).
Professional Benefits:
- Reduces operational costs by enabling precise in-house diagnostics and maintenance.
- Ensures safety through verified brake system and ABS troubleshooting procedures.
- Maintains vehicle resale value by adhering to official Ferrari technical service standards.
- Eliminates mechanical errors with exact torque specifications and wear limit data.
What’s Included in This Service Manual Set:
This technical documentation set covers the complete repair instructions (Istruzioni per le Riparazioni) released by the Ferrari Technical Service Department. It includes comprehensive data on engine overhauls, the Motronic M2.5 injection/ignition system, and the ABS hydraulic circuit.
Technical Identification & Specifications
- Serial Number Locations: Identification data plates are located on the chassis/frame; the manual provides specific diagrams for locating the engine identification number and vehicle identification number (VIN) plates to ensure correct parts ordering.
- Factory Specifications (Proof of Depth):
- Engine Management: Bosch Motronic M2.5 system (controls both ignition and injection).
- ABS System Warning: Initial warning light illumination may last up to 30 seconds if the hydraulic accumulator is discharged.
- Maintenance Intervals: Chassis protection and inspection required every 2 years.
- Diagnostic Logic: System includes specific electronic signal checks for the Motronic M2.5 installation.
Visual & Diagnostic Features
- Exploded Views: Detailed mechanical breakdowns for engine and drivetrain components.
- Electrical Wiring Diagrams: Includes full electric signal mapping for the Bosch Motronic M2.5 system and secondary air enrichment circuits.
- Troubleshooting Flowcharts: Step-by-step diagnostic procedures for the ABS hydraulic circuit and system warning lights.
- Hydraulic Routing: Visual representations of the brake system and catalytic converter cooling/emissions layouts.
Contents at a Glance
- Section A: General Information (Customer Service, Identification Data, Weights, and Capacities).
- Section B: Engine (Technical Specs, Overhaul, and Repair).
- Section C: Ignition & Injection (Motronic M2.5 Operation, System Diagnosis, and Catalytic Converters).
- Section G: Braking System (ABS Operation, Hydraulic Unit, and Warning Light Diagnostics).
- Maintenance Schedules: Periodic service standards and road test procedures.
Professional Value
This manual provides official factory wear limits and service tolerances essential for identifying component fatigue. By utilizing the provided technical specifications and diagnostic signals, technicians can prevent premature system failures and ensure the vehicle operates within its original engineering parameters.
