1993–1997 Kawasaki KLX250 / D-Tracker KLX 250R Service Manual (P/N 56019-120)

• 404 PDF pages across two OEM publications — a 275-page KLX250R/KLX250 base service manual, P/N 99924-1165-03, Third Edition (2), dated July 29, 1997; and a 129-page KLX250/D-Tracker service manual supplement, Third Edition (1), dated December 14, 2002.
• Model-code coverage: KLX250 D1-D4 and E1-E3, the 1994 G1 section with G2 identification and specification data, and later H2-H5 and J2-J4 models. Kawasaki marks country-specific information for U.S./California, Australian, European, and Swiss applications where the equipment differs.
• Covers top- and bottom-end repair, including compression testing, KACR and cam-chain timing, valve-clearance adjustment and valve-seat work, piston and cylinder inspection, engine removal, crankcase splitting, crankshaft alignment, balancer setup, and constant-mesh transmission service.
• Details CVK carburetor fuel-level adjustment, water-pump and seal replacement, cooling-system pressure testing and air bleeding, oil-pump service and oil-pressure testing, plus clutch, kickstarter, and final-drive work.
• Chassis procedures span brake bleeding and caliper/master-cylinder overhaul, wheel and hub-bearing service, chain alignment, conventional and upside-down fork service, KLX250D rear-shock overhaul, Uni-Trak linkage, swingarm, and steering-stem bearings.
• Later-model electrical coverage adds charging-system diagnosis, sealed-battery specifications, starter motor, relay, one-way clutch, and torque-limiter testing, digital-meter and Hall-effect speed-sensor checks, and H/J regional wiring diagrams.
• Includes assembly torque and locking-agent tables, inspection standards, service limits, fluid data, electrical test specifications, exploded views, troubleshooting guides, cable/wire/hose routing, and Kawasaki special-tool callouts.

How the Two Publications Work Together

These are Kawasaki factory workshop publications, not a generic maintenance guide. The base book divides service information into 16 system chapters and a separate 1994-model chapter. Kawasaki states that it is designed primarily for trained mechanics in a properly equipped shop, while also providing enough detail for an owner with basic mechanical knowledge, the correct tools, and familiarity with workshop procedures to handle basic maintenance and repair. The H/J volume contains only information that differs from the base manual, so both books are required for complete repair coverage on those later models; both are included in this set.

The common powertrain is a 249 mL liquid-cooled DOHC single with a wet multi-disc clutch and six-speed constant-mesh transmission. The early D, E, and G specifications cover primary kick-start versions, while the H/J supplement adds the electric starter, starter clutch, torque limiter, sealed battery, and related control circuits. Carburetor coverage distinguishes the CVK32 used on D models from the CVK34 applications. H and J tables also separate their wheel/tire packages and final-drive gearing. Later change points are identified for H3/J4 oil-service data, H4/J4 fuel-tank drain inspection, and H5-specific cable routing, engine-side exploded views, transmission layout, and front-sprocket arrangement.

Engine, Fuel, and Cooling Repair Depth

The engine material goes well beyond removal and replacement. It covers camshaft-bearing oil-clearance checks, valve-guide clearance by the wobble method, valve-seat cutting, piston-ring and cylinder measurements, crankshaft runout and flywheel alignment, shift-fork and gear-dog inspection, and clutch-pack inspection and adjustment. Factory procedures also address the automatic compression release, cam-chain tensioner, crankcase assembly, oil-pump relief valve, and operational checks after reassembly.

Fuel-system work includes throttle-cable setup, carburetor service fuel-level checks, disassembly, cleaning, jet and diaphragm inspection, and model-specific settings. Cooling coverage reaches the water-pump impeller, mechanical and oil seals, radiator-cap testing, leak and pressure checks, flushing, coolant filling, and air removal. The electrical chapters provide component-level tests for alternator output, stator and pickup coils, regulator/rectifier, ignition coil, CDI/igniter, switches, fan relays, starter relays, starter motor, and the later digital meter.

Diagrams, Factory Data, and Repair Cautions

Useful visual references include the Engine Oil Flow Chart, camshaft-chain timing views, the KLX250-G1 Radiator Fan Circuit, Coolant Temperature Warning Circuit, electric-starter circuit, and digital-meter speed-sensor waveform. Full wiring diagrams cover KLX250D, regional KLX250E versions, KLX250-G1, KLX250-H for Australia, and KLX250-J for Europe.

Assembly and diagnosis are supported by component torque tables, wear limits, pressure-test data, capacities, clearances, and electrical values. Named Kawasaki tools include the crankshaft jig 57001-1174, rotor puller 57001-1216, fork oil level gauge 57001-1290, and later-model hand tester 57001-1394, along with the required bearing, steering, valve, wheel, and fork tools.

The manual warns against stacking shim stock or grinding valve-clearance shims because a shim can eject or fracture and cause major engine damage. It also cautions against holding the alternator rotor by its timing plate or striking the rotor, which can damage the plate or weaken the magnets. Rear-shock service involves pressurized nitrogen, and Kawasaki assigns the gas-pressurizing procedure to a qualified mechanic; the brake, fuel, cooling, and ignition sections carry their own system-specific safety instructions.
