The following models are encompassed by this manual: Raptor 80, YFM80W / Yamaha Motor Corp., Ltd
Yamaha Raptor 80, YFM80W
Production year(s): 2002, 2003, 2004, 2005, 2006, 2007, 2008
Engine: 79 cc (4.82 in3), air-cooled, 4-stroke, 47 x 45.6 mm (1.85 x 1.80 in), air-cooled, 4-stroke, SOHC, Mikuni VM16SH Carburetion System, 9.6:1
Manual Language: English
Number of pages: 232
Printable: Yes (with all printers)
Payment: PayPal or credit card.
Instant delivery/download: Your download link will appear on the checkout page after your payment is complete.
#
³
"Troubleshooting Made Easy: Download the Comprehensive ATV Manual for the 2002-2008 Yamaha Raptor 80"
Welcome to the world of the 2002-2008 Yamaha Raptor 80, an exhilarating and reliable ATV that offers a thrilling off-road experience. In this article, we will provide you with a detailed overview of the engine specs, interesting facts, maintenance tips, common issues, tuning options, accessories, owner reviews, and more, to help you get the most out of your Yamaha Raptor 80. So, get ready to explore the capabilities of this dynamic ATV!
Engine Specs/Technical Specifications:
• The 2002-2008 Yamaha Raptor 80 is equipped with an 80cc, single-cylinder, air-cooled engine.
• The engine features a 4-stroke configuration, delivering smooth and reliable power.
• It offers a displacement of 79cc, providing a balance of performance and ease of use.
• The Raptor 80 utilizes a 1-cylinder overhead camshaft (OHC) design.
• It has a bore and stroke of 47mm x 45.6mm, contributing to its responsive power delivery.
• The engine is equipped with a reliable electric start system, ensuring convenient starting every time.
• The Raptor 80 offers a 3-speed automatic transmission, allowing riders to focus on their adventure without worrying about shifting gears.
• It has a chain drive system, transferring power from the engine to the rear wheels efficiently.
• The Raptor 80 features a CDI (Capacitor Discharge Ignition) system for reliable ignition and smooth operation.
• It comes with a single A-arm front suspension system, providing a comfortable and controlled ride.
• The rear suspension consists of a swingarm setup with a single shock, offering excellent damping and stability.
• The Raptor 80 features front drum brakes and a rear hydraulic disc brake system, ensuring reliable stopping power.
• It has a total weight of approximately 245 pounds, making it agile and easy to handle.
• The Raptor 80 boasts a fuel capacity of 1.9 gallons, allowing for extended off-road adventures.
• It comes with a durable steel frame, providing strength and stability in various terrains.
• The ATV offers a ground clearance of 3.9 inches, enabling it to tackle uneven surfaces and obstacles.
• The Raptor 80 features 18x7-7 front tires and 18x9-8 rear tires, offering a good balance of traction and maneuverability.
• It has a wheelbase of 40.2 inches, providing stability and agility during rides.
• The Raptor 80 offers a seat height of 26.8 inches, accommodating riders of different sizes comfortably.
• It comes equipped with dual headlights and a taillight for enhanced visibility during night rides.
Facts and Details:
- The Yamaha Raptor 80 is designed for riders aged 12 and older, making it an ideal ATV for young enthusiasts.
- It features an adjustable throttle limiter, allowing parents to adjust the top speed to suit the rider's skill level.
- The Raptor 80 is known for its user-friendly design, making it easy for beginners to learn and enjoy ATV riding.
- Yamaha designed the Raptor 80 with a focus on safety, including features such as a tether switch and a handlebar-mounted emergency engine shut-off switch.
- It offers a comfortable and ergonomic seating position, allowing riders to enjoy longer rides without discomfort.
- The Raptor 80 boasts durable and rugged construction, ensuring it can withstand off-road adventures and rough terrains.
- It features a sporty and aggressive look, inspired by Yamaha's high-performance sport ATVs.
- The Raptor 80 is equipped with a centrifugal automatic clutch, providing smooth and seamless power transfer.
- Yamaha offers a range of genuine accessories for the Raptor 80, including nerf bars, skid plates, and graphic kits, allowing riders to customize their ATV.
- The Raptor 80 is designed to be low-maintenance, with features such as an easily accessible air filter and a simple oil change procedure.
Maintenance Intervals, General Maintenance Tips, and Common Issues/Solutions:
- Regular maintenance intervals for the Yamaha Raptor 80 include oil and filter changes every 20 hours of operation or as recommended by the manufacturer.
- It is important to inspect the air filter regularly and clean or replace it when necessary to maintain optimal engine performance.
- Check and adjust the tire pressure before each ride to ensure proper traction and stability.
- Lubricate the drive chain regularly to prevent excessive wear and maintain smooth power transfer.
- Keep an eye on the coolant level and ensure proper cooling system function to prevent overheating.
- One common issue with the Raptor 80 is carburetor-related problems, such as clogging or improper adjustment. Cleaning or rebuilding the carburetor can often solve these issues.
- Another common issue is spark plug fouling. Regularly inspect and clean or replace the spark plug to maintain reliable ignition.
- Check the brake pads regularly and replace them if they are worn to ensure proper braking performance.
- Electrical issues, such as a dead battery or faulty wiring connections, can occur. Regularly inspect the electrical components and connections to prevent issues.
Popular Tuning Tips or Modifications:
- Installing an aftermarket exhaust system can enhance the sound and performance of the Raptor 80.
- Upgrading the air filter to a high-flow performance filter can improve airflow and potentially increase power.
- Adding a jet kit or adjusting the carburetor can optimize fuel and air mixture for improved performance.
- Upgrading the suspension components, such as shocks and springs, can enhance the handling and ride quality of the ATV.
Available Accessories and Aftermarket Options:
- Nerf bars for improved rider protection and enhanced styling.
- Skid plates to protect the underside of the ATV from rocks and debris.
- Graphic kits for a customized and personalized look.
- Handguards for added hand protection during off-road riding.
- Rear rack extensions for increased cargo-carrying capacity.
- Performance air filters and exhaust systems for enhanced engine performance.
- Handlebar grips and levers for improved comfort and control.
- Storage bags and cargo racks for additional storage options.
Owner Reviews and Opinions (Strengths and Weaknesses):
Strengths:
- The Yamaha Raptor 80 is praised for its user-friendly design and ease of use, making it a great ATV for beginners and young riders.
I- t offers a comfortable seating position and smooth power delivery, providing an enjoyable riding experience.
- The Raptor 80's safety features, such as the throttle limiter and emergency engine shut-off switch, are highly appreciated by owners.
- The ATV is known for its durability and reliability, with many owners reporting minimal issues and long-term satisfaction.
- The low-maintenance nature of the Raptor 80 is a strong selling point, allowing riders to spend more time on the trails.
Weaknesses:
- Some owners have mentioned that the Raptor 80 could benefit from improved suspension components for a smoother ride over rough terrain.
- The stock tires may lackadequate traction in certain off-road conditions, prompting some owners to upgrade to more aggressive tires.
- The Raptor 80's top speed may not be as high as some other sport ATVs, which can be a limiting factor for riders seeking more speed.
Start your troubleshooting journey by purchasing the Yamaha Raptor 80 detailed shop handbook in PDF format. Click the green button and securely buy the manual from the RepairLoader marketplace using PayPal.
Upon completion of your secure PayPal payment, you will instantly receive the official Yamaha OEM shop manual/parts list download link. All necessary download information will be emailed to you immediately after your payment is processed, ensuring a smooth and secure transaction.
§
Price: 18.99 USD
