Honda TRX400EX ATV Service Manual 1999–2002 (P/N 61HN100)
263 Pages • Printable PDF • 107.55 MB • Download
Honda Models Covered & Key Technical Specifications
Model: TRX400EX
Model Years: 1999–2002 (1999, 2000, 2001, 2002)
-
Engine displacement: 397 cm³ (24.2 cu-in)
-
Compression ratio: 9.1:1
-
Engine type: Single cylinder, SOHC, air-cooled, dry-sump lubrication
-
Bore and stroke: 85.0 x 70.0 mm
-
Transmission: 5-speed, constant mesh
-
Idle speed: 1,400 ± 100 rpm
-
Battery specification: 12V - 8Ah
-
Charging system: Single phase output alternator, 147W at 5,000 rpm
-
Fuel tank capacity: 10 liters (2.6 US gal)
Honda Manual Features & Selected Content Preview
Honda’s September 1998 factory service manual for the 1999 TRX400EX FourTrax 400EX, identified as P/N 61HN100, provides model-specific maintenance, troubleshooting, and repair information.
PDF Search, Chapter Links, and Diagram Detail
Search and drawing access: OCR text supports searches through most procedure chapters, but some routing illustrations, the main wiring diagram, and the opening troubleshooting chart lack searchable labels. Embedded bookmarks provide chapter navigation. Small wiring codes require zooming; some captions overlap in the ignition and starter schematics.
One printable English PDF contains 263 pages, including the cover, two introductory reference pages, five memo pages, and one additional prefatory page.
Engine Overhaul, Chassis Repair, and Fault Diagnosis
The following selected contents highlight the main workshop coverage rather than reproduce the full contents list. Other topics include body-panel removal and exhaust-system service.
-
Engine repair: Engine removal and installation, compression diagnosis, cylinder-head and valve work, piston inspection, crankcase separation, crankshaft and balancer service.
-
Fuel and lubrication: Carburetor overhaul, accelerator-pump inspection, pilot-screw setup, high-altitude adjustment, oil-pump service, strainers, and oil-cooler inspection.
-
Clutch and transmission: Clutch-pack inspection and assembly, primary-drive and gearshift-linkage service, internal transmission work, alternator and starter-clutch repair.
-
Wheels, suspension, and steering: Front hub service, steering-shaft and tie-rod work, rear axle bearing replacement, shock-linkage repair, and swingarm service.
-
Hydraulic disc brakes: Fluid replacement and bleeding, pad and disc inspection, front and rear master-cylinder overhaul, caliper service, brake-pedal work, and parking-brake adjustment.
-
Electrical diagnosis: Battery and charging tests, ignition peak-voltage checks, starter-circuit troubleshooting, switch continuity testing, wiring diagrams, and system schematics.
-
Routine maintenance: Valve-clearance checks, engine oil and filter service, oil-tank strainer cleaning, air-cleaner maintenance, drive-chain inspection and lubrication, and spark-arrester service.
Honda wrote this manual for readers who already have basic maintenance knowledge of Honda motorcycles, scooters, or ATVs; specialized procedures require the appropriate tools and measuring equipment.
Cylinder Head and Bottom-End Repair
Step-by-step procedures cover camshaft and cylinder-head-cover service, decompressor and rocker-arm work, valve-guide replacement, valve-seat refacing, and cylinder and piston inspection. The Decompressor Assembly drawing supports the associated inspection and assembly text.
Internal transmission coverage includes gear, bushing, shaft, shift-fork, and shift-drum inspection, with mainshaft/countershaft assembly layouts. Transmission and crankshaft work require engine removal and crankcase separation.
Missing installation section: The supplied file jumps from printed page 9-11 to 10-0. The right crankcase cover installation section listed at page 9-12 is missing.
The bottom-end chapter warns that allowing the connecting rod to press against the crankcase mating surface during crankshaft installation can damage the case sealing surface.
Carburetor Overhaul and Oil-System Service
Carburetor instructions extend through cleaning, disassembly, inspection, and reassembly. Accelerator Pump and Float and Jets views show the diaphragm, float valve, jets, and related components.
Pilot-screw idle-drop setup and high-altitude adjustment have dedicated procedures. Separate float-pin notes distinguish ’99–’00 and after-’00 carburetors.
The lubrication chapter covers oil-pump disassembly and wear inspection, relief-valve checks, and strainer cleaning. The Oil Pump & Strainer illustration accompanies this work, with separate inspection and removal information for the oil cooler, tank, and pipes.
Suspension Bearings and Brake Components
Chassis procedures address wheel-hub bearings, steering-shaft bearings and bushings, tie-rods, rear axle bearings, suspension-arm pivots, shock linkage, and swingarm pivots. Shock-absorber coverage includes removal, inspection, and pivot-bearing service; damaged damper assemblies are replaced.
Brake chapters distinguish front and rear master cylinders and calipers, including internal inspection and reassembly. Cable-lock parking-brake components and brake-pedal service are covered alongside the hydraulic procedures.
Starting, Charging, and Ignition Faults
System sections combine service information, illustrations, and troubleshooting before the detailed procedures. Fuel-system charts separate no-start, lean-mixture, rich-mixture, backfire, and acceleration complaints; the main troubleshooting section addresses hard starting, power loss, poor low- or high-speed operation, and handling problems. This structure helps identify the relevant tests before choosing a repair procedure.
Charging diagnosis includes battery-condition, current-leakage, charging-voltage, regulator/rectifier, and alternator charging-coil checks.
Ignition testing covers the ignition coil, exciter coil, pulse generator, and ignition control module (ICM). Comparing readings at the ICM connectors with readings at the source connectors helps distinguish wiring faults from component faults.
Starter-relay, clutch-diode, and switch continuity tests accompany the Wiring Diagram and separate ignition-system and electric-starter schematics. The ignition section cautions that connecting or disconnecting terminals while current is present can damage electrical components.
Maintenance References and Special Tools
The maintenance chapter also covers brake wear and hydraulic-system checks, clutch and brake-lock adjustment, suspension and steering-shaft-holder bearing inspection, and fastener checks.
Reference tables supply component torque specifications, capacities, clearances, service limits, wear measurements, lubrication and sealant locations, and electrical test standards. Cable & Harness Routing views support cable, hose, and wiring installation.
Honda’s tool index identifies valve-spring and valve-seat equipment, the pilot-screw wrench, compression-gauge attachment, bearing pullers and removers, axle and bearing lock-nut wrenches, and crankcase assembly equipment. The 07965-VM00100 assembly collar is a service tool.
Review the section-specific safety information before engine-running tests, fuel or brake service, battery charging, and electrical diagnosis.
A Preview of Valve and Carburetor Inspection Data
For valve-clearance inspection with the engine cold, below 35°C/95°F, the maintenance chapter specifies 0.10 mm intake clearance and 0.12 mm exhaust clearance.
The fuel chapter specifies an 18.5 mm carburetor float level with the float valve seated and the float arm just touching it. The float is not adjustable.
