Hyundai H1 2002 Service Manual Set (P/N A4AE-EG17B)

The Shop Manual provides component procedures, while the electrical volume links circuit paths to connectors and harness locations. The body volume addresses structural collision work beyond the trim and body-component service in the Shop Manual.

Coverage notes: The Body Repair Manual is an earlier publication, so its construction details must match the vehicle being repaired. Common-rail circuits are included in the electrical volume; the engine-mechanical chapters cover the 2.4-liter I4 gasoline engine and 2.5 TCI diesel.

PDF Search, Navigation, and File Layout

Text search and diagram labels: The Shop Manual and electrical PDFs do not support text search. The Body Repair Manual has searchable text but no embedded bookmarks. The other files include bookmarks, with some incorrect targets, including the ABS/SRS entries and the main transmission link. Small wiring labels require zooming; the checked connector numbers and wire codes remain readable when enlarged.

The ZIP contains 26 printable PDFs totaling 1,667 pages: 19 Shop Manual files, six electrical files, and one Body Repair Manual. The totals include both separate one-page contents/foreword files, chapter dividers, and blank or memo pages.

Mechanical Service, Electrical Diagnosis, and Body Repair

These selected content highlights show the main repair areas rather than the complete contents. Other examples include diesel glow-system checks and rear suspension procedures for leaf- and coil-spring configurations.

• Engine repair: Step-by-step engine removal, internal inspection, cylinder-head overhaul, valve work, timing-belt installation, cooling, lubrication, intake, exhaust, turbocharger, and EGR procedures.

• Fuel and emissions: Gasoline MFI, conventional diesel, and COVEC-F diagnosis, including sensor and actuator tests, DTC charts, injection-pump work, and emissions-control checks.

• Transmission and axles: Manual and automatic transmission disassembly and reassembly, clutch service, transfer-case diagnosis, propeller shafts, hubs, bearings, and differential setup.

• Brakes, steering, and restraints: Brake and ABS fault tracing, suspension inspection, power-steering service, and SRS diagnosis with component procedures and tightening specifications.

• Body and interior: Hood, fender, bumper, door, glass, sunroof, seat, and trim service, plus structural measurements, panel replacement, welding, sealing, and corrosion protection.

• Electrical systems: Starting, charging, engine management, lighting, audio, instruments, ETACS, power accessories, wipers, rear defogger, immobilizer, and warning-system diagnosis.

• Heating and air conditioning: Refrigerant-system testing and service, compressor work, vacuum controls, and front and rear heater, evaporator, and blower procedures.

Written for authorized Hyundai dealer service technicians, this set is best suited to experienced professional repairers with the diagnostic, measuring, lifting, welding, and special-tool capability assumed by the factory procedures.

Engine, Fuel, and Drivetrain Detail

The Shop Manual is organized by Hyundai group codes, from General Information through HVAC. Service standards, wear limits, lubricant requirements, tightening-torque charts, troubleshooting tables, and special-tool references appear with the relevant assemblies.

Separate gasoline, COVEC-F, and conventional diesel fuel sections distinguish electronic fault diagnosis from mechanical injection-pump inspection and timing work. Transmission material extends to clutch packs, planetary assemblies, valve bodies, and manual gearbox internals.

The engine, drivetrain, body length, and equipment distinctions help repairers select the applicable component data and procedures before dismantling an assembly.

Circuit Tracing and Connector Identification

The ETM's five-part structure combines system schematics, component-location indexes, illustrated locations, connector configurations, and harness layouts. COVEC-F, MPI, and common-rail engine-control diagrams appear alongside ABS, SRS, and transfer-case control circuits.

Power-window wiring, connector cavity faces, and main, instrument, engine, frame, and door harness routing support tracing between the schematic and the vehicle. Body-electrical coverage adds H220, H240, and H280 audio units, multifunction-switch checks, lighting loads, relays, fuses, gauges, locks, and mirrors.

Connector numbering is opposite the 1999 convention, making the terminal-side views important when identifying a test cavity. The ETM also warns that test lamps can damage solid-state modules in electronic circuits.

Body Components and Structural Collision Work

Component procedures distinguish front and sliding doors, lift-up and twin-swing tailgates, windshield, delta and quarter glass, seats, dashboard, console, headliner, and pillar trim.

Structural drawings show 2WD and 4WD front sidemembers, short- and long-body rear structures, and underbody and upper-body measuring points. Radiator-support and pillar replacement views identify weld and sectioning locations; sealing, cavity-wax, and undercoating maps address the repaired areas.

Cutting outside the illustrated structural sectioning locations can compromise the body's original strength and geometry.

SRS diagnosis includes checks before battery disconnection. The restraint and body-repair chapters also specify isolation, waiting-time, lifting, welding, and module-protection precautions.

A Preview of Thermostat Inspection Data

For the 2.4-liter gasoline engine, the thermostat inspection section specifies an opening temperature of 80–84°C and a full-opening temperature of 95°C. Both values accompany the illustrated cooling-system inspection material.
