2008 Kawasaki Teryx 750 4x4 UTV Factory Service Manual (P/N 99924-1397-02)

This factory service manual covers 2008 Kawasaki Teryx 750 4x4 recreational utility vehicles, including the base KRF750A8F and KRF750B8F camouflage variants, with the liquid-cooled, carbureted 749 cm³ V2-cylinder engine.

Text search and wiring navigation: Service text and specification tables are searchable. Embedded bookmarks cover all 17 chapters and link directly to the main wiring diagram. Text embedded in diagram images is not searchable, and small wiring labels require zooming.

• Engine repair: Engine removal and installation, cylinder-head overhaul, valve clearance adjustment, crankcase separation, crankshaft inspection, and transmission disassembly.

• Fuel system: Keihin CVKR34 carburetor overhaul and synchronization, fuel-level inspection, throttle and choke cable adjustment, and fuel-pump checks.

• Cooling and lubrication: Cooling-system pressure tests, thermostat inspection, water-pump seal replacement, oil-pressure measurement, and oil-pump service.

• CVT service: Drive belt deflection checks, drive and driven pulley disassembly, wear inspection, and engine-brake actuator checks.

• Final drives: Front and rear final gear case repair, bevel-gear backlash adjustment, tooth-contact checks, and limited-slip differential testing.

• Brakes and chassis: Brake line air bleeding, caliper and master-cylinder service, rear wet-brake inspection, double-wishbone suspension, steering, and wheel and tire procedures.

• Electrical diagnosis: Wiring diagrams, ignition and charging tests, starter-motor repair, and diagnostic procedures for the engine-brake actuator control system.

Written primarily for trained mechanics in a properly equipped shop, the manual also addresses owners with basic mechanical knowledge and familiarity with tools and workshop procedures for basic maintenance and repair.

Engine Repair, Timing, and Wear Limits

The engine top end section covers valve-seat work, cylinder and piston inspection, and Kawasaki Automatic Compression Release (KACR) diagnosis. Exploded-view diagrams, torque tables, and wear measurement guidelines support assembly checks; periodic maintenance charts give fluid service intervals.

The cam-chain procedures include a specific caution: retightening a partially loosened non-return tensioner can damage the tensioner and cam chain.

Front and Rear Carburetor Settings

Front and rear carburetor settings are identified separately, including jet needles, main jets, and fuel levels. This distinction helps match parts and adjustment data to the correct carburetor before a fuel-system repair.

Cooling and Engine Lubrication

The Coolant Flow Chart and Engine Oil Flow Chart show the circulation paths alongside pressure-test and component-inspection procedures. Water-pump service includes a warning that blocking the inspection hole with the oil seal can allow coolant into the crankcase.

CVT, Transmission, and Final Drive Repair

The continuously variable transmission procedures extend to pulley rebuilding and spacer adjustment. Tool references include the Belt Deflection Gauge (57001-1713) and Actuator Lever Measurement Tool (57001-1499), with color-coded selection data for drive pulley covers and engine-brake actuator levers.

Final-drive sections include shim-selection tables for gear backlash and tooth contact. The 2WD/4WD system is covered through vacuum-actuator inspection and solenoid-valve tests, while internal transmission work includes shift-fork and gear inspection.

Brake, Suspension, and Steering Work

Rear enclosed wet multi-plate brake service is covered with the rear final gear case procedures. Chassis sections address suspension-arm bushings, ball joints, wheel bearings, and toe-in. Internal steering-gear overhaul is not covered; the manual specifies replacement of the assembly.

Electrical Fault Isolation

The Ignition System Troubleshooting flowchart links a no-spark complaint to component tests. The Actuator Control System Circuit supports engine-brake control diagnosis, and the Carburetor Heater System Circuit covers the heater and air-temperature sensor.

Cable, Wire, and Hose Routing views show harness and hose placement during reassembly. Observe the manual’s electrical-isolation precautions around the radiator fan: it can start with the ignition switched off.

Printable PDF and Included Pages

One printable English-language PDF contains 573 pages: one cover, four introductory pages, 526 service-chapter pages, and a 42-page appendix. The 526-page service section includes one placeholder marked “Dummy Page”; all listed pages are already included in the total.
