John Deere Sabre 1948GV/HV, 2148HV, 2354HV, 2554HV (S/N -25001) Technical Manual

Detailed John Deere Sabre 1948GV/HV, 2148HV, 2354HV, 2554HV (S/N -25001) Yard & Garden Technical Manual (546 P.). Covers engine specifications, fuel system, electrical system, gear and hydrostatic power trains, PTO drive, implement lift, and mower decks. Ref: TM1841.

4.5starstarstarstarstar_half(2)
★ REPAIRLOADER SELECT
visibility Preview Available
Sabre John Deere Sabre 1948GV/HV, 2148HV, 2354HV, 2554HV (S/N -25001) Technical Manual manual page preview - page 1 of 324

Sample pages from the John Deere Sabre 1948GV/HV, 2148HV, 2354HV, 2554HV (S/N -25001) Technical Manual manual

Sabre John Deere Sabre 1948GV/HV, 2148HV, 2354HV, 2554HV (S/N -25001) Technical Manual manual preview page 1 - thumbnail
Sabre John Deere Sabre 1948GV/HV, 2148HV, 2354HV, 2554HV (S/N -25001) Technical Manual manual preview page 2 - thumbnail
Sabre John Deere Sabre 1948GV/HV, 2148HV, 2354HV, 2554HV (S/N -25001) Technical Manual manual preview page 3 - thumbnail
info_outline Click thumbnails to preview different pages
$24.30 (incl. VAT) Original OEM Factory Manuals & Data Instant Download / No Shipping Fees
5 copies sold
OR BUY NOW
verified_user
Lifetime Access
Re-download anytime
flash_on
Instant Download
Get it immediately
lock
Secure Payment
PayPal
Technical Safety Notice
keyboard_arrow_down

This official OEM document is intended for professional technicians and skilled operators. Performing service on mechanical equipment involves inherent risks. By purchasing, you acknowledge that RepairLoader provides original manufacturer data for informational purposes. Always prioritize safety: use correct tools, wear protective gear, and consult a certified professional if you are uncertain of any procedure.

Sabre Models Covered & Key Technical Specifications

Models: John Deere Sabre 1948GV, John Deere Sabre 1948HV, John Deere Sabre 2148HV, John Deere Sabre 2354HV, John Deere Sabre 2554HV
Sub-models / Variants: 1948GV, 1948HV, 2148HV, 2354HV, 2554HV
Trade Names: Sabre Yard Tractors, Sabre Garden Tractors
Build Years: 2000
Serial Numbers: S/N -25001
Technical Data:

  • Engine Displacement: 624–725 cm³ (38.1–44.0 cu.in.)
  • Engine Configuration: 4-stroke, 2-cylinder, vertical shaft
  • Horsepower: 14.17 kW (19 hp) to 18.6 kW (25 hp)
  • Fuel Tank Capacity: 11 L (3 U.S. gal)
  • PTO Drive Type: V-Belt
  • Mower Deck Width: 1219–1372 mm (48–54 in.)
  • Turning Radius: 584 mm (23 in.)
Technical Specifications
keyboard_arrow_down
Document Number / Seller:
27480 / Charles Jones
File Size:
37.36 MB
File Type:
PDF
Language:
English
Pages:
324
Printable:
Yes
Category:
Lawn and Garden Tractor
Last updated / verified
Jan 9, 2026

Sabre Manual Features & Content Preview

Technical Scope for the 2000 John Deere Sabre 1948GV/HV, 2148HV, 2354HV, 2554HV

  • Built for owners and technicians servicing the 2000 John Deere Sabre 1948GV/HV, 2148HV, 2354HV, and 2554HV yard and garden tractor series
  • Official John Deere publication P/N TM1841, dated March 2000
  • Includes 12 electrical schematics, 4 troubleshooting flow charts, and torque specification tables for inch and metric hardware
  • Downloads to your account within seconds of checkout
  • Suitable for printing individual sections for shop-floor use
  • Coverage spans tractors with serial numbers up to 25001
  • This 324-page technical manual is the primary reference used by technicians for the CV19 through CV25 Kohler engine platforms documented within the Sabre equipment line

Contents Overview

The 2000 John Deere Sabre technical documentation opens with critical safety information, detailing procedures for handling fuel, chemical products, and high-pressure washing. Detailed chapters follow on system theory, including cooling, lubrication, and fuel systems, alongside governor and ignition system operations. The text provides a deep dive into component locations, system schematics, and diagnostic logic for electrical and engine sub-systems, including the starting, charging, and reverse implement option circuits.

The manual continues with extensive repair and adjustment specifications. These sections detail engine removal and installation, cylinder head service, valve inspections, piston assembly, and crankshaft measurements. A dedicated electrical section organizes wiring harness legends and diagnostic troubleshooting for every sub-circuit, ensuring clear identification of power, ignition, and starter paths throughout the 2000 John Deere Sabre range.

Specification Highlights

Engine displacement is documented from 624 to 725 cm³ across the CV19, CV21, CV23, and CV25 engine models. Engine mounting bolts require a torque of 32 N•m (24 lb-ft). Cylinder head fastener final torque is specified at 40.7 N•m (30 lb-ft). Intake valve clearance is documented at 0.038–0.076 mm in the cylinder head section. how factory workshop documentation is structured provides further context on utilizing this technical data.

Note: This page is a contents overview for the manual. It does not provide repair or diagnostic instructions. An official 324-page John Deere OEM technical manual covering the 2000 John Deere Sabre 1948GV/HV, 2148HV, 2354HV, 2554HV series, documenting engine, drivetrain, and electrical specifications for the S/N -25001 build range.

Document Reference: TM1841, dated 03Mar00
