John Deere 316, 318, 420 garden tractor technical manual

Includes the following models

The following models are covered by this manual:

  • 316, 318, 420, 300 Series / John Deere, built in Horicon, Wisconsin, USA.
  • John Deere 316 (1978-1986)
    • 316 Kohler
    • 316 Onan
  • John Deere 318 (1983-1992)
    • 318 Kohler
    • 318 Onan
  • John Deere 420 (1983-1991)
    • 420 Onan
  • John Deere 316 Garden Tractor (serial numbers: 285,001-999,000)
  • John Deere 318 Garden Tractor (serial numbers: 285,001-999,000)
  • John Deere 420 Garden Tractor (serial numbers: 125,001-999,000)

Engine 316 specs:

  • Onan B43E, gasoline, 2-cylinder, air-cooled, horizontal-shaft opposed twin, 709 cc, 43.3 ci, 3.25x2.62 inches, 83 x 67 mm, 16 hp, 11.9 kW, Idle RPM 1350-3450.
  • Onan P218G, gasoline, 2-cylinder, air-cooled, horizontal-shaft opposed twin, 781 cc, 47.7 ci, 3.25x2.88 inches, 83 x 73 mm, 18 hp, 13.4 kW, 1350-3450, NGK BPR5EFS, Champion RS14YC.

Engine 318 specs:

  • Onan B43G, gasoline, 2-cylinder, 4-valve, air-cooled, horizontal-shaft opposed twin, 709 cc, 43.3 ci, 3.25x2.62 inches, 83 mm x 67 mm, 18 hp, 13.4 kW, 6.5:1, 1350-3450, JD AM38622, NGK BPR5EFS, Motorcraft AGRF32.
  • Onan P218, gasoline, 2-cylinder, 4-valve, air-cooled, horizontal-shaft opposed twin, 781 cc, 781 cc, 47.7 ci, 3.25x2.88 inches, 83 x 73 mm, 18 hp, 13.4 kW, 7:1, 31 lb-ft, 42.0 Nm.

Engine 420 specs:

  • Onan B48G, ..., see above, ..., 20 hp, 14.9 kW, 7.0:1.

Production year(s):

  • 1983, 1984, 1985, 1986, 1987, 1988, 1989, 1990, 1991, 1992.
  • Publication number: TM-1590
  • Serial numbers or parts numbers: 420000, 420001, M00318X420000, M00318X420001

File specifications

File size: 17.52 MB
File ending in: pdf
Language: English
Pages: 440

Printable: Yes
Estimated download time: 0.36 Minutes
The safer, easier way to pay
24.99 $ Instant Download

Description

Table of Contents

  • Introduction
  • Specifications
  • Operating instructions
  • Maintenance guidelines
  • Troubleshooting
  • Wiring diagrams
  • And more

Please note that the following table of contents is a partial overview and does not cover all the sections and topics included in the manual. It provides a glimpse of the manual's content.

This John Deere 316, 318, 420 garden tractor technical manual is essential for mechanics, technicians, and owners as it provides detailed information on specifications, operating instructions, maintenance guidelines, troubleshooting, and wiring diagrams. It serves as a comprehensive guide to understanding and maintaining the garden tractor.

  • The price of this manual, handbooks, and repair guides are set by the seller of the manuals themselves, so it is possible that the same manual is offered at a different price on another page. Please compare prices before deciding to purchase.
  • Comments and ratings from other users at the end of the detail page can make your purchase decision easier. Please leave a review after your purchase to help other users make their purchasing decision.
  • Don't hesitate and download the repair manual you need now. You get a lifetime guarantee for the download, as described in our FAQs https://www.repairloader.com/faq.php.
  • To contact the seller of the manual, please use our contact form https://www.repairloader.com/contact.php and we will forward your request or take care of it directly.
