Yamaha TDM900(S) 2004 Service & Repair Manual Set (P/N 5PS1-AE1)

681 Pages • ZIP Download: 4 Printable PDFs • 18.35 MB

5.0starstarstarstarstar(1)
$17.15 Instant Download / No Shipping Fees
or

Credit/debit card, Apple Pay or Google Pay

30-day refunds for defective files or manuals not as described. Refund policy.

print
Save & print
Keep a copy on your device
lock
Secure Payment
Stripe

Yamaha Models Covered & Key Technical Specifications

Models: TDM900(S), TDM900(R), TDM900(P), TDM900A(T)

Models & Model Codes:

TDM900(S) — 5PS6 (EUR), 5PS7 (OCE)

TDM900(R) — 5PS4 (EUR), 5PS5 (OCE)

TDM900(P) — 5PS1 (EUR), 5PS2 (OCE)

TDM900A(T) — 2B01 (EUR)

Trade Names: TDM900

Model Years: 2002–2004 (2002, 2003, 2004)


  • Engine: Liquid-cooled 4-stroke

  • Fuel System: Electronic Fuel Injection (FI) with 38EIS Mikuni throttle bodies

  • Idle Speed: 1,100–1,200 r/min

  • Front Suspension Travel: 150 mm

  • Front Fork Oil Quantity: 545 cm3 per fork leg (TDM900(S))

  • Front Tire Size: 120/70ZR 18 M/C

  • Rear Tire Size: 160/60ZR 17 M/C

  • Electrical System Voltage: 12 V DC

  • Fuel Pressure Relief Setting: 441–637 kPa

Yamaha Manual Features & Selected Content Preview

Publication Pages
TDM900(P) 2002 Service Manual — P/N 5PS1-AE1 475
TDM900(R) 2003 Supplementary Service Manual — P/N 5PS1-AE2 28
TDM900(S) 2004 Supplementary Service Manual — P/N 5PS1-AE3 41
TDM900A(T) 2005 ABS Supplementary Service Manual — P/N 5PS1-AE4 137

Use the base manual with the applicable model-change supplements. The later books refer back to the base volume and preceding updates rather than repeating every unchanged engine or chassis procedure.

Match the model and regional codes before selecting wiring diagrams, throttle-body data, or brake procedures. The ABS supplement applies to the European 2B01 configuration.

PDF Text Search, Bookmarks, and Wiring Detail

Search and diagram navigation: All four PDFs contain searchable workshop text. The P/R/S covers and some full-page wiring labels are outside text search. The base manual has chapter bookmarks; several supplement bookmarks lead to contents pages rather than the named sections. Small wiring labels require zooming.

The ZIP contains four printable English PDFs totaling 681 pages, including 57 cover, preliminary, chapter-divider, and blank or header-only pages. These pages are already included in the publication totals above.


Engine Repair, FI Diagnosis, and Model-Change Systems

The following selected coverage highlights outline the repair and diagnostic content. Further topics include battery charging checks and headlight-beam adjustment.

  • Engine and transmission: Engine removal, cylinder-head and valve repair, piston inspection, camshaft timing, crankshaft and balancer-shaft work, and transmission inspection.

  • Brakes and chassis: Master-cylinder and caliper service, hydraulic bleeding, front-fork disassembly and seal installation, steering-head work, rear suspension, swingarm, and drive-chain inspection.

  • Cooling system: Radiator checks, thermostat testing, and step-by-step water-pump disassembly, inspection, seal installation, and reassembly.

  • Fuel injection: ECU self-diagnosis, fail-safe fault tracing, throttle-body synchronization, CO adjustment, injector checks, and fuel-pump and pressure-regulator tests.

  • Electrical systems: Ignition, starting, charging, lighting, signaling, and cooling-fan diagnosis, including the revised starting and lighting circuits in the R supplement.

  • Immobilizer: Key ID registration, self-diagnosis indications, circuit checks, troubleshooting charts, and matched-component replacement requirements in the S supplement.

  • ABS: Wheel-sensor and hydraulic-unit checks, bleeding, operation tests, present and stored malfunction diagnosis, code deletion, and post-service trial-run procedures.

These publications were written primarily for Yamaha dealers and qualified mechanics, with basic mechanical knowledge and vehicle-repair techniques assumed.

Internal Engine Repair and Chassis Service

Engine detail: Wet-clutch repair, starter-clutch and generator work, and dry-sump oil-pump service have dedicated exploded assemblies and inspection instructions. Crankshaft sections cover connecting rods, Plastigauge clearance checks, and replacement-bearing selection; transmission sections examine gears, shift forks, and the shift drum.

The valve sections identify compressor 90890-04019 and attachment 90890-04108. Front-fork seal installation uses driver weight 90890-01367 and attachment 90890-01374, alongside the assembly notes and inspection limits.

Model changes: The S supplement revises the front brake pads, master cylinder, and calipers and supplies updated cable-routing drawings. These changes matter when selecting the brake assembly instructions for a particular model.

Fuel Control and Electrical Fault Isolation

The fuel-injection material explains ECU ignition, fuel, and load control, together with the three-way catalytic converter and air-induction system. Diagnostic monitoring connects sensor readings and actuator checks with fault-specific wiring and component inspections.

The fuel-pressure procedure identifies gauge 90890-03153 and adapter 90890-03176. Its pressure-regulator checks relate fuel pressure to intake vacuum, supporting performance verification rather than relying on a fault code alone.

Yamaha’s fuel-pump cautions address impact and sender-base damage; the installation notes also specify a new pump gasket and correct fuel-hose holder placement.

Immobilizer Registration and ABS Service

Immobilizer matching: The replacement-parts matrix links transponder keys, the immobilizer unit, ECU, main switch, and accessory locks. Losing all keys or replacing control components changes the required parts and registration work; an unmatched or unregistered combination can leave the engine disabled.

ABS diagnosis: The TDM900A(T) supplement distinguishes current faults from stored malfunctions and covers the ECU, fail-safe relay, hydraulic-unit solenoids, and motor circuit. Test-coupler adapter 90890-03149 is identified for diagnosis and hydraulic operation checks.

The lever-and-pedal response tests help identify incorrectly connected hydraulic-unit hoses. Wheel-hub contamination can damage the internal sensor rotor and wheel sensor; the press-fitted sensor rotor is replaced with the wheel assembly.

Pressurized fuel, brake fluid, electrical diagnosis, and ABS hydraulic work require proper shop equipment, safe fluid handling, correct bleeding, and functional checks before the motorcycle is returned to service.

Diagrams and Factory Reference Data

Diagram coverage includes engine oil-flow diagrams, cooling-system diagrams, the fuel-injection circuit diagram, air-induction system diagrams, immobilizer system and circuit diagrams, and the ABS connector-location chart.

Regional wiring sheets, component-location views, cable-routing drawings, and exploded assemblies support fault tracing and reassembly. Reference sections supply component-specific torque data, lubrication points, fluid capacities, wear limits, clearances, and electrical test specifications.

Examples of Synchronization and ABS Sensor Test Data

The TDM900(P) throttle-body synchronization procedure specifies intake vacuum of 33.0–36.0 kPa at idle after engine warm-up. The vacuum difference between the two throttle bodies must not exceed 1.33 kPa.

For TDM900A(T), the electrical specifications give 1.2–1.6 kΩ at 20°C for both ABS wheel sensors. The associated service sections provide coupler test connections and sensor-rotor inspection criteria.
