2007–2009 Kawasaki Versys KLE650 Service Manual (P/N 99924-1369-01, 99912-1469-04)

738 Pages • 16.40 MB • Printable PDFs (ZIP Download)

4.7starstarstarstarstar_half(3)
visibility Preview Available
$17.20 Original OEM Factory Manuals & Data Instant Download / No Shipping Fees
OR BUY NOW

Cards and eligible digital wallets

verified_user
Lifetime Access
Re-download anytime
flash_on
Instant Download
Get it immediately
lock
Secure Payment
Stripe

Kawasaki Models Covered & Key Technical Specifications

Models: Versys KLE650

Sub-models / Variants: KLE650A7F, KLE650B7F

Model Years: 2007–2009 (2007, 2008, 2009)


  • Engine: 4-stroke, DOHC, 2-cylinder, liquid-cooled

  • Displacement: 649 cc

  • Compression Ratio: 10.6 : 1

  • Transmission: 6-speed, constant mesh, return shift

  • Fuel System: DFI (Fuel injection), Keihin TTK38 x 2

  • Front Suspension: Telescopic upside-down fork (150 mm travel)

  • Rear Suspension: Swingarm (uni-trak) (145 mm travel)

  • Battery: 12 V 10 Ah

  • Alternator Rated Output: 8 A/14 V @4000 rpm

Technical Specifications
keyboard_arrow_down
Document Number / Seller:
24777 / Rebecca Morgan
File Size:
16.40 MB
File Type:
ZIP
Language:
English
Pages:
738
Printable:
Yes
Category:
Motorcycle
Last updated / verified
Sep 5, 2026

Kawasaki Manual Features & Content Preview

  • Factory service coverage for 2007 Kawasaki Versys KLE650A7F and KLE650B7F (ABS), paired with a European 2007–2008 KLE650A7F/A8F parts catalog.
  • Covers engine removal and internal repair, including crankcase splitting, camshaft timing, cylinder-head inspection, and valve-seat repair.
  • Digital fuel injection (DFI) procedures address fuel-pump pressure and flow testing, injector signal checks, engine vacuum synchronization, and FI-light self-diagnosis.
  • Wet multi-disc clutch and transmission sections cover disassembly, plate inspection, shaft assembly, and shift-drum and shift-fork wear checks.
  • Brake service extends from caliper and master-cylinder rebuilding to bleeding, ABS fault diagnosis, wheel-rotation sensor testing, and hydraulic-unit replacement.
  • Upside-down telescopic front-fork service includes disassembly and oil-level setting, alongside rear-shock adjustment, swingarm-bearing replacement, and steering-stem service.

738 pages across two PDFs: a 627-page service manual, Part No. 99924-1369-01, first edition August 21, 2006, and a 111-page parts catalog, catalog/microfiche No. 99912-1469-04.

Engine and Drivetrain Documentation

The 649 cc DOHC 2-cylinder engine chapters cover cylinder and piston wear assessment, valve-guide replacement, and color-coded bearing-insert selection for the crankshaft, connecting rods, and balancer. The 6-speed transmission section also documents the positive neutral finder mechanism.

The tensioner section explains how retightening partly loosened mounting bolts can damage the non-return tensioner and camshaft chain.

The liquid-cooling chapter includes pressure testing, thermostat inspection, and water-pump mechanical-seal replacement. The Coolant Flow Chart and Engine Oil Flow Chart show circulation through the cooling and lubrication systems. Oil-pump coverage distinguishes the feed and scavenge rotors and includes oil-pressure and relief-valve checks.

DFI and Electrical Troubleshooting

Dealer Mode 1 and Dealer Mode 2 distinguish current from stored DFI faults. Sensor testing covers the main and subthrottle sensors, inlet-air pressure and temperature sensors, and vehicle-down sensor. European oxygen-sensor and heater diagnostics are identified separately.

The DFI System Wiring Diagram and DFI Diagnosis Flow Chart accompany ECU terminal identification and power-supply checks. Injector bench-test cautions explain how incorrect connections can damage the injector solenoids through excessive current.

For electrical troubleshooting, the manual covers alternator and stator tests, regulator/rectifier diagnosis, ignition stick-coil checks, and starter-motor service. Relay and diode testing supports electrical repair beyond the fuel-injection circuits. Main wiring diagrams distinguish Canada, New Zealand, and Malaysia from other markets, with a separate KLE650B version. Cable, wire, and hose-routing drawings support reassembly.

ABS, Suspension, and Chassis Service

The ABS System Wiring Diagram and ABS Diagnosis Flow Chart support solenoid-valve, pump-motor relay, and power-supply fault isolation. Hydraulic-unit coverage is diagnosis and replacement—not internal repair.

Front-fork specifications distinguish left- and right-leg oil levels and components; rebound adjustment applies to the right leg only. Frame and steering geometry data accompany wheel-alignment and steering-bearing procedures. Frame inspection identifies damage requiring replacement; it is not a frame-straightening chapter.

Specification and Reference Values

Component-specific torque and locking-agent tables accompany exploded assembly views. Reference data covers fluid capacities, inspection limits, and electrical test specifications. Inlet and exhaust valve-clearance adjustment charts support shim selection, while scheduled-maintenance and ignition sections identify the NGK CR9EIA-9 spark plug and its gap-inspection requirements.

Special-tool listings identify Vacuum Gauge 57001-1369 for synchronization and Fork Spring Compressor 57001-1685 for fork service.

Parts Identification and Serial Breaks

The companion catalog provides illustrated parts listings, quantities, model-year applications, and color-specific bodywork references. Its European A-series coverage does not include B-series ABS parts.

Catalog VIN coverage is JKALE650AAA000001–JKALE650AAA018000 for A7F and JKALE650AAA018001 onward for A8F. Separate crankcase listings distinguish engines through ER650AE057323 from ER650AE057324 onward, helping identify the applicable crankcase and oil-pipe parts before ordering.

Because improper maintenance directly impacts vehicle safety and reliability, always verify these factory tolerances carefully and consult a certified technician before undertaking major brake or engine overhauls.
