2005 Xerox WorkCentre C2424 Copier-Printer Service Manual

Xerox WorkCentre C2424 — Technical Scope and Data

• Covers 2005 Xerox WorkCentre C2424 solid-ink copier-printer, including DN, DP, and DX configuration variants
• Original OEM publication P/N 604E13990, first printing March 2005
• Contains 10 chapters detailing system theory, diagnostic troubleshooting, error codes, and maintenance procedures
• File resolution preserved for clarity when viewing detailed wiring diagrams and exploded-view parts lists
• Accessible from your device as soon as the order is placed
• OCR text layer lets you jump to a torque spec by keyword
• Suitable for printing individual sections for shop-floor use
• This 2005 manual is the primary reference for servicing the first-generation C2424 WorkCentre solid-ink printing systems

System Functionality and Architecture

This Xerox WorkCentre C2424 service publication documents the internal operations and electromechanical systems of the copier-printer. It details the image input terminal subsystems, including the scanner assembly and duplex automatic document feeder, alongside the complex print engine mechanics. The manual explains the interaction between the exit module, electronics module, and main board, providing a foundation for system diagnostics and component verification.

Technical Data and Maintenance Preview

The documentation provides extensive reference material for identifying and resolving mechanical or electronic failures. Key specifications include a peak power consumption of 1250 W and an operating temperature range of 10º–32º C. The printer engine supports 2400 FinePoint print resolution and utilizes a 40 GB hard drive for system operations. The IOT sub-assemblies are fully documented, from the drum assembly and transfix system to the ink loader and purge pump. Detailed wiring diagrams for the internal components are documented in Section 10 to support electrical troubleshooting. The manual documents that what an OEM service publication covers for the Xerox WorkCentre C2424 includes precise alignment procedures for the wiper assembly, head tilt gear, and process gear drive train. An official 432-page Xerox OEM service manual covering the 2005 Xerox WorkCentre C2424, documenting complete system theory, electrical specifications, and component-level diagnostic procedures for the print engine and scanning terminals.

Document Reference: Part Number 604E13990, First Printing March 2005
