2003 Pontiac Grand Prix Service Manual

This manual covers 1997-2003 Pontiac Grand Prix models, detailing ABS system diagnostics, component replacement, and repair procedures with specific fastener tightening specifications. Ref: G01490614

4.8starstarstarstarstar_half(4)
Pontiac Car manual preview - 2003 Pontiac Grand Prix Service Manual
$18.50 (incl. VAT) Original OEM Factory Manuals & Data Instant Download / No Shipping Fees
1 copies sold
OR BUY NOW
verified_user
Lifetime Access
Re-download anytime
flash_on
Instant Download
Get it immediately
lock
Secure Payment
PayPal
Technical Safety Notice
keyboard_arrow_down

This official OEM document is intended for professional technicians and skilled operators. Performing service on mechanical equipment involves inherent risks. By purchasing, you acknowledge that RepairLoader provides original manufacturer data for informational purposes. Always prioritize safety: use correct tools, wear protective gear, and consult a certified professional if you are uncertain of any procedure.

Pontiac Models Covered & Key Technical Specifications

Models: 2003 Pontiac Grand Prix GTP
Sub-models / Variants: 3.8L Engine (L36, L67)
Build Years: 2003
Technical Data:

  • Brake pipe fitting torque: 15 N·m (11 lb ft)
  • Brake pressure modulator valve bracket nut torque: 10 N·m (7 lb ft) to 12 N·m (8 lb ft)
  • Electronic brake control module (EBCM) bolt/screw torque: 2.9 N·m (26 lb in)
  • BPMV bracket nut torque: 10 N·m (7 lb ft) to 12 N·m (8 lb ft)
  • Wheel speed sensor resistance: 800–1600 ohms
Technical Specifications
keyboard_arrow_down
Document Number / Seller:
28896 / Joseph Wilson
File Size:
525.53 MB
File Type:
ZIP
Language:
English
Printable:
Yes
Category:
Car
Last updated / verified
May 17, 2025

Pontiac Manual Features & Content Preview

2003 Pontiac Grand Prix ABS Service Documentation

  • Covers the 2003 Pontiac Grand Prix GTP with specific focus on the Antilock Brake System and Traction Control diagnostics
  • Official General Motors publication, original factory-issued 2003 Brakes manual content
  • Contains 61 technical diagrams including wiring schematics, connector pinouts, and component location views
  • Indexed PDF search covers every chapter and appendix
  • Delivered as a direct download the moment payment clears
  • This specific edition provides the precise torque specifications for EBCM and BPMV mounting hardware required to maintain system integrity during brake repairs

Antilock Brake System Diagnostic Scope

This 2003 Pontiac Grand Prix service manual focuses on the diagnostics and component replacement for the vehicle Antilock Brake System. It provides technical logic for the Diagnostic System Check, detailing interpret scan tool data lists, including parameters for wheel speed, requested engine torque, and pump motor status. The content provides critical identification for electronic brake control module and brake pressure modulator valve diagnostic trouble codes, covering circuit malfunctions from C0035 through C0896.

Technical Data and Schematic Preview

This documentation lists key fastener tightening values, such as the 15 N·m torque specification for brake pipe fittings at the BPMV. Electrical references are documented, including the EBCM connector pinout table identifying 30-way F GT mixed series connections. The manual defines the conditions for setting DTCs, such as the 100-cycle clear logic for history codes. Each schematic section includes specific icon definitions and troubleshooting test descriptions for intermittent connection identification. This is an official 100-page OEM factory publication documenting 2003 Pontiac Grand Prix GTP antilock brake and traction control system repair and diagnostic procedures for the 3.8L L36 and L67 engine variants.

Manual FAQ, Purchase & Download Details

Can I find technical reference tables that summarize the fastener tightening specifications for the antilock brake system components? keyboard_arrow_down

Yes, the manual includes a dedicated specification section that lists the required tightening torque values for various hardware applications. This table organizes the data in both metric and English units for easy reference.

Which specific components are included in the fastener tightening specification tables? keyboard_arrow_down

Tightening specification tables cover various components such as brake pipe fittings, the brake pressure modulator valve bracket nut, and the electronic brake control module torque bolts.

What information is shown in the exploded views and component breakdown diagrams for the engine compartment bulkhead? keyboard_arrow_down

Component locator section contains detailed illustrations of the upper left side of the engine compartment bulkhead. These diagrams identify the locations of the cruise control module connector, the electronic brake control module, and the brake fluid level switch.

Does this document include wiring schematics for the electronic brake control module, power systems, and wheel speed sensors? keyboard_arrow_down

Manual contains a comprehensive set of schematic and routing diagrams covering the power, ground, and communication circuits for the antilock brake system, traction control, and steering components.
