Mazda 6 2002–2004 Workshop Manual (P/N 1730-1E-02C)

1,187 Pages • ZIP Download: 1 Printable PDF • 15.63 MB

4.7starstarstarstarstar_half(3)
$16.49 Instant Download / No Shipping Fees
or

Credit/debit card, Apple Pay or Google Pay

30-day refunds for defective files or manuals not as described. Refund policy.

print
Save & print
Keep a copy on your device
lock
Secure Payment
Stripe

Mazda Models Covered & Key Technical Specifications

Models: Mazda6 (L8, LF and L3 engines; G35M-R manual transaxle; FN4A-EL automatic transaxle)

Sub-models / Variants: European L.H.D., U.K. specs, GCC specs; 4-door sedan (4SD), 5-door hatchback (5HB)

Model Years: 2002–2004 (2002, 2003, 2004, 2005, 2006)

Serial Numbers: European L.H.D.: JMZ GG1232*# 100001–, JMZ GG1282*# 100001–, JMZ GG1432*# 100001–, JMZ GG1482*# 100001–, JMZ GG12F2*# 100001–, JMZ GG12F5*# 100001–, JMZ GG14F2*# 100001–, JMZ GG14F5*# 100001–

U.K. specs: JMZ GG12820# 100001–, JMZ GG14320# 100001–, JMZ GG14820# 100001–, JMZ GG12F20# 100001–, JMZ GG12F50# 100001–, JMZ GG14F20# 100001–, JMZ GG14F50# 100001–

GCC specs: JM7 GG32F**# 100001–, JM7 GG34F**# 100001–, JM7 GG42F**# 100001–, JM7 GG44F**# 100001–


  • Idle Engine Speed: 650–750 RPM (L8 and LF/ATX); 600–700 RPM (LF/MTX and L3), engine warm and without accessory loads

  • Engine Oil Capacity: 4.6 L (L8/LF, dry engine); 4.2 L (L3, dry engine); 4.3 L (L8/LF, oil and filter replacement); 3.5 L (L3, oil and filter replacement)

  • Transmission Fluid Capacity: approximately 2.87 L (G35M-R manual transaxle)

  • Oil Pressure (L8/LF): 234–521 kPa (33.9–75.5 psi) at 3,000 RPM, oil temperature 100°C

  • Oil Pressure (L3): 395–649 kPa (57.3–94.1 psi) at 3,000 RPM, oil temperature 100°C

  • Cylinder Head Bolt Torque: five stages — 5.0 N-m; 13–17 N-m; 44–46 N-m; 88°–92°; 88°–92°

  • Radiator Pressure Specification: 127 kPa (18 psi)

Mazda Manual Features & Selected Content Preview

Mazda Motor Corporation’s Mazda6 Workshop Manual, P/N 1730-1E-02C, covers on-vehicle service and diagnosis for European L.H.D., U.K. and GCC specifications with L8, LF and L3 engines. Printed in the Netherlands in March 2002, this edition uses the VIN application ranges shown above to identify the covered vehicles.

PDF Bookmarks and Wiring Detail

Navigation and text handling: Embedded section bookmarks provide chapter access. Text search and copying can be unreliable because of the PDF’s character encoding. Small labels in the ABS/TCS and DSC wiring diagrams require zooming for comfortable reading.

The ZIP download contains one printable 1,187-page PDF. This total includes three introductory pages containing the foreword, application information and safety notice, plus one nearly blank section page.


Engine, Transaxle and Chassis Service

The following is a selection of the covered work, rather than a complete contents list. Other topics include power-window troubleshooting and door-glass removal.

  • Engine repair: Step-by-step procedures for timing-chain service, cylinder-head-gasket replacement and engine removal, plus valve-clearance adjustment and compression testing.

  • Lubrication and cooling: Oil-pressure inspection, oil-pump replacement, coolant leak testing, thermostat inspection, and radiator, water-pump and cooling-fan service.

  • Fuel and engine controls: Fuel-pressure and injector checks, EVAP/EGR inspection, PCM configuration, DTC troubleshooting and symptom-based engine diagnosis.

  • Clutch and transaxles: Clutch hydraulic and friction-component service, G35M-R removal and installation, and FN4A-EL testing, valve-body removal and installation.

  • Axles, steering and suspension: Front and rear hub service, drive-shaft repair, engine-speed-sensing power-steering diagnosis, and front and rear wheel alignment.

  • Brake systems: Conventional hydraulic brake service, ABS/TCS and DSC diagnosis, HU/CM configuration, wheel-speed-sensor checks and combine-sensor initialization.

  • Electrical and climate systems: Starting, charging and ignition tests; instrument-cluster, immobilizer, SRS and lighting diagnosis; audio/navigation service and air-conditioning troubleshooting.

Developed with Mazda-trained technicians in mind, the manual assumes general workshop safety knowledge and access to the measuring equipment and special service tools required for the work.

Engine Service and Fault Isolation

L3 valve timing: The variable valve timing actuator and oil control valve have dedicated inspection and replacement procedures. The actuator incorporates its camshaft sprocket; attempting to dismantle this precision assembly can damage it.

Oil-pressure inspection specifies gauge 49 0187 280A. Component-location illustrations, tightening data and inspection limits accompany the mechanical service procedures.

Diagnostic workflow: WDS or equivalent supports DTC retrieval and clearing, freeze-frame review, PID monitoring, readiness tests and module configuration. The diagnostic introduction separates faults with stored codes from symptoms without codes, helping technicians select the appropriate test path before replacing components.

The Vacuum Hose Routing Diagram and Quick Diagnostic Chart support checks involving air supply, engine controls and running complaints.

Clutch and Transaxle Work

The G35M-R section covers oil service, differential oil seals, shift mechanisms and transaxle removal and installation. All-season lubricant specifications identify SAE 75W-90; the FN4A-EL uses ATF M-V.

Automatic-transaxle diagnosis includes line-pressure, stall, time-lag and road tests, with a Shift Diagram for evaluating shift behavior. Specified equipment includes pressure-gauge set 49 0378 400C and clutch-disc centering tool 49 SE01 310A.

Mazda cautions that using an impact wrench on the FN4A-EL manual-shaft nut can damage the transaxle.

Steering, Brakes and Stability Control

Steering coverage extends to gear-and-linkage disassembly, inspection and assembly, pump service and hydraulic pressure testing. Tool references include power-steering gauge set 49 1232 670B and brake pressure-gauge set 49 U043 0A0A.

The ABS (ABS/TCS) System Wiring Diagram and DSC System Wiring Diagram accompany diagnostic procedures. HU/CM configuration and combine-sensor initialization address electronic setup associated with component replacement.

Body Electrical and Air Conditioning

Instrument-cluster configuration, immobilizer and theft-deterrent diagnosis, cruise control, air-bag diagnostics and discharge-headlight auto leveling have dedicated coverage. Audio/navigation procedures include component removal and electrical checks.

Climate-control sections cover on-board diagnosis, refrigerant recovery and charging, pressure checks, and compressor and control-component service. The special-tool list identifies gas charge set 49 C061 0A0B.

Moisture or foreign material entering refrigerant connections can impair cooling and cause abnormal noise. Incorrect refrigerant charging can also damage refrigeration-cycle components.

Workshop Scope and Related Publications

This volume concentrates on on-vehicle diagnosis, inspection, adjustment, removal and installation, with the component repairs described in its individual sections.

Mazda lists separate publications for internal L8/LF/L3 engine work, G35M-R and FN4A-EL overhaul, the FN4A-EL supplement, complete vehicle wiring diagrams and bodyshop repair. Those related books are separate from this download.

Hot coolant, fuel and brake hydraulics, R-134a refrigerant, SRS components and discharge headlights require the factory safety precautions. Improper service can damage components or leave the vehicle unsafe.

A Preview of Cooling, Steering and A/C Specifications

Cooling-system data specifies a capacity of 7.5 L and a radiator-cap opening pressure of 113–142 kPa. Cap opening pressure is a separate specification from the cooling-system leakage-test pressure.

Power-steering pressure tests specify 10.80–11.29 MPa for the pump and gear housing at 1,000–1,500 rpm under the respective factory test conditions.

R-134a refrigerant charge varies with driving position: 470 g for L.H.D. vehicles and 430 g for R.H.D. vehicles.
