Yamaha Marine 6/8 HP Outboard Service Manual Set, 1996–2006 (P/N 6H6-28197-Z5-11)
592 Pages • 1 Printable PDF (English) • Download
Yamaha Models Covered & Key Technical Specifications
Models: 6CM, 6CEM, 8CM, 8CEM, F6AMH/F6MH, F8CMH/F8MH, FT8DMH/T8MH, FT8DE/T8ER, FT8DEP/T8PR, FT8DEHP/T8PH
Models & Model Codes:
6CM — 6U/8U: 6H6. 6V/8V: 6M8 (model code), 6H6 (approval code).
6CEM — 6U/8U: 6H6. 6V/8V: 6M8 (model code), 6H6 (approval code).
8CM — 6U/8U: 6G1. 6V/8V: 6N0 (model code), 6G1 (approval code).
8CEM — 6U/8U: 6G1. 6V/8V: 6N0 (model code), 6G1 (approval code).
F6AMH/F6MH — 68R
F8CMH/F8MH — 68T
FT8DMH/T8MH — 69G
FT8DE/T8ER — 69G
FT8DEP/T8PR — 69G
FT8DEHP/T8PH — 69G
Sub-models / Variants: 6MH (USA/Canada, 6CM), 8MH (USA/Canada, 8CM), Short, Long, Ultra-Long (UL) shaft configurations on the two-stroke models, depending on model. F6Z/F8Z: S/L. T8/FT8: L/X, depending on model. The T8PH/T8PR supplement also provides variant data for FT8DMH/T8MH and FT8DE/T8ER.
Model Years: 1996–2006 (1996, 1997, 1998, 1999, 2000, 2001, 2002, 2003, 2004, 2005, 2006)
Serial Numbers:
6U/8U: 6CM (S: 030589~, L: 319132~, UL: 700192~), 6CEM (S: 100787~, L: 401307~), 8CM (S: 056590~, L: 340981~, UL: 702817~), 8CEM (S: 102231~, L: 403196~, UL: 750491~)
6V/8V: 6CM/6MH (S: 003802~, L: 303150~), 6CEM (S: 100101~, L: 400101~), 8CM/8MH (S: 008601~, L: 305566~), 8CEM (S: 100101~, L: 100101~)
F6Z/F8Z: F6AMH/F6MH (S: 000101-, L: 300101-), F8CMH/F8MH (S: 000101-, L: 300101-)
T8/FT8: FT8DMH (L: 350101-, X: 650101-), T8MH (L: 350101-), FT8DE/T8ER (L: 400101-, X: 700101-), FT8DEP/T8PR (L: 500101-, X: 750101-), FT8DEHP/T8PH (L: 550101-, X: 850101-)
-
Engine Type: 2-stroke, 2-cylinder (6U/8U and 6V/8V). 4-stroke, SOHC, 2-cylinder inline (F6Z/F8Z and T8/FT8).
-
Displacement: 165 cc (10.07 cu. in.) for 6U/8U and 6V/8V. 197 cc (11.8 cu. in.) for F6Z/F8Z and T8/FT8.
-
Bore x Stroke: 50 mm x 42 mm (6U/8U and 6V/8V). 56.0 mm x 40.0 mm (F6Z/F8Z and T8/FT8).
-
Compression Ratio: 7.00 (6U/8U and 6V/8V). 8.79 (F6Z/F8Z and T8/FT8).
-
Fuel System: Single Carburetor, Reed Valve, Cross Scavenging (6U/8U and 6V/8V). Single carburetor with choke (F6Z/F8Z and T8/FT8).
-
Ignition System: CDI (Capacitor Discharge Ignition)
-
Gear Shift Position: Forward-Neutral-Reverse
-
Gear Ratio: 13:27 (2.08) for 6U/8U and 6V/8V. 2.08 (27/13, gear/pinion) for F6Z/F8Z. 2.92 (38/13, gear/pinion) for T8/FT8.
-
Gear Type: Straight bevel gear (6U/8U, 6V/8V, and F6Z/F8Z). Spiral bevel gear (T8/FT8).
-
Starting System: Manual (6CM/6MH and 8CM/8MH) or Manual & Electric (6CEM and 8CEM). Manual (F6Z/F8Z and FT8DMH/T8MH). Electric (FT8DE/T8ER, FT8DEP/T8PR, and FT8DEHP/T8PH).
-
Spark Plug: NGK B7HS-10 or BR7HS-10 (6U/8U and 6V/8V). BR6HS-10 (F6Z/F8Z and T8/FT8).
-
Gear Oil Capacity: 160 cm³ (5.4 US oz) for 6U/8U and 6V/8V. 150 cm³ (5.1 US oz) for F6Z/F8Z. 320 cm³ (10.9 US oz) for T8/FT8.
-
Idle Speed: 900 ± 50 rpm (6U/8U and 6V/8V). 1,050 ± 50 rpm (F6Z/F8Z and T8/FT8).
Yamaha Manual Features & Selected Content Preview
| Publication | Pages |
|---|---|
| 6U/8U Service Manual — 6CM, 6CEM, 8CM, and 8CEM two-stroke outboards. First edition, May 1995. P/N 6H6-28197-Z5-11, cover ID LIT-18616-01-34. | 150 |
| 6V/8V Service Manual — 6CM, 6CEM, 8CM, and 8CEM two-stroke outboards with separate starting serial blocks. First edition, July 1996. P/N LIT-18616-01-64. | 150 |
| F6Z/F8Z Service Manual — F6AMH/F6MH and F8CMH/F8MH four-stroke outboards. First edition, April 2000. P/N LIT-18616-02-19, Yamaha manual ID 68T-28197-ZA-11. | 201 |
| T8PH/T8PR Supplementary Service Manual — power-tilt service for T8PH and T8PR, with related FT8/T8 variant data. First edition, October 2000. P/N LIT-18616-02-31, Yamaha cover ID 69G-28197-1A-1X. | 90 |
Use the two-stroke manuals for their respective model and starting serial blocks. Yamaha directs technicians to use the T8PH/T8PR supplement with the F6Z/F8Z base manual for complete service procedures.
Model fit: Match the model code, shaft designation, and starting serial block before choosing a manual. The 1996–2006 listing range covers selected Yamaha 6 and 8 hp outboards, so horsepower and year alone are insufficient to identify the correct procedure.
Bookmarks, Text Search, and Wiring Detail
Chapter access and diagram labels: Embedded bookmarks open chapters in all four publications. Text search is available in the F6Z/F8Z manual and the T8PH/T8PR supplement. The two-stroke manuals have no searchable page text. Small wire codes and connector labels are easier to read when zoomed in.
The set is supplied as one 592-page printable PDF in English. The total includes the four publication covers, two wiring sheets in each four-stroke publication, and one separate library identification sheet.
Powerhead, Gearcase, and Power Tilt Service
These are selected topics from the set. The manuals also cover anode inspection and checks for the four-stroke top cowling drain hole.
-
Two-stroke powerhead: Step-by-step power unit removal and installation, cylinder and piston inspection, crankshaft checks, recoil starter repair, and reed valve service.
-
Four-stroke powerhead: Timing belt and gear alignment, cylinder head and oil pump service, valve guide and seat work, and crankshaft plain bearing clearance checks.
-
Fuel and controls: Carburetor and fuel pump inspection, throttle-link and idle adjustments, ignition timing checks, and four-stroke start-in-gear protection checks.
-
Lower unit: Water pump and impeller service, propeller shaft and bearing housing work, dog clutch and gear inspection, seal replacement, leak testing, and gear backlash measurement.
-
Brackets and power tilt: Steering handle, upper case, swivel and clamp bracket service, plus T8PH/T8PR power-tilt motor, pump, valve, and cylinder repair.
-
Electrical diagnosis: CDI, charge and pulser coil checks, electric starter testing, oil-pressure warning circuits, and troubleshooting charts for starting, misfires, shifting, and charging faults.
Yamaha prepared the base manuals primarily for dealers and trained mechanics with a working knowledge of mechanical and electrical service.
Gearcase Setup and Model-Specific Tests
The T8 supplement gives separate shim-selection procedures for the USA and Canada and for other markets. Those sections help you choose the correct setup before measuring forward and reverse gear backlash. The lower-unit chapters also cover drive shaft, shift cam, and bearing housing work.
The wiring diagrams distinguish 6CM/8CM manual-start from 6CEM/8CEM electric-start circuits. The four-stroke drawings separate the F6MH/F8MH one-lighting-coil and two-lighting-coil systems and the T8PH and T8PR power-tilt wiring. The F6Z/F8Z peak-voltage chart helps trace a no-start or unstable idle to the CDI unit, charge coil, or pulser coil using the related test specifications.
Factory Data and Tooling
The specification sections provide component torque tables, lubricant and capacity data, wear limits, and fuel pump and electrical test values. The F6Z/F8Z manual also includes a bearing selection table keyed to the crankshaft journal marks. Identified Yamaha tools include the YU-91022-B CDI tester, YM-01253/90890-04019 valve spring compressor, 90890-06706 backlash indicator, and YB-06560/90890-06560 power-tilt wrench.
Crankcase Seals and Power Tilt
The F6Z/F8Z manual warns that fitting the oil seals after tightening the crankcase bolts can damage the seals. The T8 supplement warns that fibers from rags or paper can cause power-tilt hydraulic malfunctions. It covers fluid checks, system bleeding, armature tests, and removal and installation of the tilt unit.
Gasoline vapor, rotating and spring-loaded components, electrical testing, and stored hydraulic pressure call for proper marine-shop isolation, ventilation, and personal protection.
Piston and Cold Valve Clearance Examples
For the 6U/8U and 6V/8V two-strokes, the powerhead inspection data gives a standard piston-to-cylinder clearance of 0.040–0.045 mm and a wear limit of 0.095 mm.
For the F6Z/F8Z four-strokes and the T8PH/T8PR supplement, the cold valve clearance check specifies 0.15–0.20 mm for the intake and 0.20–0.25 mm for the exhaust.
