2005 Yamaha 115C, 115D, 130B, L130B, 140C, L140C, 115U, S115U, P115U, 130U, S130U, L130U Outboard Service Manual Collection (P/N LIT-18616-01–40)

This Yamaha outboard service manual collection combines the 1995 115C/115D, 130B/L130B and 140C/L140C manual, P/N LIT-18616-01-40, with separate V-series, W-series and 115C/130C publications. The first manual also covers the U-series USA/Canada model names listed above.

• Power unit: Removal, crankcase separation, cylinder and piston inspection, crankshaft checks, reed-valve service, and reassembly procedures.

• Fuel and controls: Twin-barrel carburetor overhaul and synchronization, ignition timing, pickup timing, and throttle- and shift-cable adjustment.

• Oil injection: Pump-link adjustment, air bleeding, pump-output testing, and engine and remote oil-tank system checks.

• Lower unit and cooling: Water-pump service, propeller-shaft housing repair, regular- and counterrotation gear service, shimming, and backlash measurement.

• Bracket and trim systems: Cowling and mount service, power trim and tilt pump and ram overhaul, hydraulic pressure testing, and bleeding.

• Electrical diagnosis: CDI and charging-system checks, starter-motor overhaul, trim-control tests, wiring diagrams, and trouble-analysis charts.

Written primarily for Yamaha dealers and trained mechanics, these manuals assume a basic understanding of mechanical and electrical service procedures.

Model Identification and Publication Differences

Model-indication tables connect worldwide designations with USA/Canada names. Publication-specific starting serial numbers distinguish the covered versions, including the regional 100AETO, premixed-fuel variants and oil-injection configurations.

X-series section: The X-labeled cover identifies C115X, 115X, S115X, B115X, 130X, S130X and L130X. Its remaining pages duplicate the W-series manual, including the identification tables and closing LIT-18616-01-92 imprint. This section does not contain a distinct X-series interior.

Carburetors, Oil Injection and Engine Repair

Fuel-line and oil-line layout drawings show hose routing, check-valve direction and remote-tank connections. Carburetor coverage addresses the independent pilot circuits, float inspection and linkage settings rather than treating synchronization as a single idle-speed adjustment.

Oil-injection procedures include pump-link synchronization and discharge measurement. The bleeding and pump-output test sections explain lubrication precautions because incorrect test fueling can cause engine seizure.

Internal engine coverage extends to cylinder-bore measurements, piston-ring clearances, crankshaft runout and bank-specific piston identification. The first publication also identifies crank-disc seal-ring orientation as a breakage risk during crankcase assembly.

Lower-Unit Shimming and Water-Pump Service

Separate regular- and counterrotation sections document the different gear, bearing and propeller-shaft arrangements. Exploded assembly views, shim-selection charts and backlash measurement views support work beyond routine gear-oil changes.

US/Canada and other-market shim-selection procedures help mechanics choose the appropriate measuring setup for the lower unit. Tool references include the backlash indicator YB-06265 / 90890-06706 and propeller-shaft housing puller YB-06207 / 90890-06502.

Cooling-system coverage includes impeller and pump-housing inspection, thermostat testing, water passages and pressure-control valve inspection.

Power Trim, Tilt and Bracket Repairs

The bracket chapters cover mounts, steering components, upper casing and cowling mechanisms. PTT sections extend into the reservoir, gear pump, relief valves, trim and tilt rams, and electric motor, with pressure-test setups and air-bleeding procedures.

Observe the manual’s precautions for flammable fuel vapors, battery acid, raised outboards and trapped hydraulic pressure.

CDI, Charging and Starting-System Diagnosis

Component-location views and wiring diagrams connect the stator assembly, charge and pulser coils, CDI unit, rectifier/regulator and oil-level controls. Trouble-analysis charts address starting faults, poor acceleration, charging problems and trim-system symptoms.

The earlier publication specifies analog-meter checks for certain electronic components; later publications add peak-voltage testing with the specified adapter. Starter and PTT motor sections include armature, brush and commutator inspection, while trim-control coverage includes relay, switch and sensor tests.

A Sample of Engine Inspection and Coil-Test Data

A few examples from the first publication show the inspection detail available. Its cylinder-head warpage limit is 0.1 mm, and maximum connecting-rod axial play is 2.0 mm.

For charge-coil testing, resistance between the black/red and blue leads is specified at 55–83 Ω. These examples are a small selection of the component-specific limits and electrical test data in the collection.

PDF Search, Bookmarks and Included Publications

Search and diagram detail: Text search is available in the final 115C/130C publication; the preceding sections are not text-searchable. Embedded bookmarks provide access to the publication sections and major chapters. Small wiring-diagram labels require zooming.

The download is one printable, English-language PDF with 1,150 pages across the following sections:

Cover and end pages are included in these counts. The X-labeled section comprises its cover and 208 duplicated W-series pages, all already included in the total.
