1983-1990 Ford TW-5, TW-15, TW-25, TW-35 Tractor Service Manual

This comprehensive service manual provides detailed diagnostic and maintenance procedures for Ford TW-5, TW-15, TW-25, and TW-35 tractors, covering engine and chassis.

4.6starstarstarstarstar_half(5)
visibility Preview Available
Ford 1983-1990 Ford TW-5, TW-15, TW-25, TW-35 Tractor Service Manual manual page preview - page 1 of 160

Sample pages from the 1983-1990 Ford TW-5, TW-15, TW-25, TW-35 Tractor Service Manual manual

Ford 1983-1990 Ford TW-5, TW-15, TW-25, TW-35 Tractor Service Manual manual preview page 1 - thumbnail
Ford 1983-1990 Ford TW-5, TW-15, TW-25, TW-35 Tractor Service Manual manual preview page 2 - thumbnail
Ford 1983-1990 Ford TW-5, TW-15, TW-25, TW-35 Tractor Service Manual manual preview page 3 - thumbnail
Ford 1983-1990 Ford TW-5, TW-15, TW-25, TW-35 Tractor Service Manual manual preview page 4 - thumbnail
info_outline Click thumbnails to preview different pages
$19.30 (incl. VAT) Original OEM Factory Manuals & Data Instant Download / No Shipping Fees
5 copies sold
OR BUY NOW
verified_user
Lifetime Access
Re-download anytime
flash_on
Instant Download
Get it immediately
lock
Secure Payment
PayPal
Technical Safety Notice
keyboard_arrow_down

This official OEM document is intended for professional technicians and skilled operators. Performing service on mechanical equipment involves inherent risks. By purchasing, you acknowledge that RepairLoader provides original manufacturer data for informational purposes. Always prioritize safety: use correct tools, wear protective gear, and consult a certified professional if you are uncertain of any procedure.

Ford Models Covered & Key Technical Specifications

Models: TW-5, TW-15, TW-25, TW-35
Sub-models / Variants: 2WD, Front Wheel Drive, Dual Power
Build Years: 1983–1990
Technical Data:

  • Engine: 6 Cylinder, Direct Injection Diesel
  • Displacement: 401 cu. in. (6.6 L)
  • Compression Ratio: 16.3:1 (TW-5), 15.6:1 (TW-15, TW-25, TW-35)
  • Forward Speeds: 8 (16 with Dual Power)
  • Reverse Speeds: 2 (4 with Dual Power)
  • Fuel Tank Capacity: 33 U.S. Gals. (TW-5, TW-15), 75 U.S. Gals. (TW-25, TW-35)
Technical Specifications
keyboard_arrow_down
Document Number / Seller:
30273 / Jessica Taylor
File Size:
46.52 MB
File Type:
PDF
Language:
English
Pages:
160
Printable:
Yes
Category:
Tractor
Last updated / verified
Apr 29, 2025

Ford Manual Features & Content Preview

1983–1990 Ford TW-5, TW-15, TW-25, and TW-35 Tractor Service Manual

  • Covers 1983–1990 Ford TW-5, TW-15, TW-25, and TW-35 tractors, including both 2WD and front-wheel-drive variants
  • Original OEM publication, BestManuals.net shop manual re-issue
  • Contains 228 exploded-view diagrams, 3 wiring schematics, and 12 detailed specification tables
  • Delivered as a direct download the moment payment clears
  • Permanent availability in your purchase account — no re-buy required
  • Laid out for standard letter and A4 printing
  • Indexed PDF search covers every chapter and appendix
  • This edition provides the primary technical reference for the 6-cylinder direct injection diesel powertrain and dual power planetary systems used across the TW tractor series

Technical Scope and Data

This Ford TW-5, TW-15, TW-25, and TW-35 service manual documents the complete range of engine, transmission, and hydraulic systems. The technical scope spans cooling system diagnostics, diesel fuel system maintenance, front and rear axle overhaul procedures, and electronic instrument panel calibration. Specifications are provided in both U.S. Customary and Metric units to support international service standards.

Specification Highlights

Documentation includes comprehensive data for engine tune-ups, including 1-5-3-6-2-4 firing order and valve tappet gaps of 0.014–0.016 inches for intake. Cooling system capacities are listed at 21 to 22.75 U.S. quarts depending on heater configuration. The electrical system section covers 12-volt alternator output tests and battery voltage diagnostics. Main bearing running clearance is documented at 0.0022–0.0045 inches. Cylinder head bolt torque values are specified at 160 ft.-lbs. in the final stage.

Manual FAQ, Purchase & Download Details

Is the exploded view for the APL-365 front axle assembly included in the manual? keyboard_arrow_down

Document contains detailed exploded view diagrams for various axle assemblies, including the APL-365 type, which show the component parts and their relative positions.

Can you confirm which tractor models are covered within this service manual? keyboard_arrow_down

Manual is specifically designed for the Ford TW-5, TW-15, TW-25, and TW-35 tractor models. It lists specifications and technical reference data relevant to these four specific variants throughout the document.

Does this publication list the recommended lubricant capacities for the transmission and front wheel drive components? keyboard_arrow_down

Manual includes comprehensive specification tables that list the fluid capacities for the cooling system, crankcase, and front wheel drive differential cases.

Are electrical wiring references and connector pinouts included in the technical documentation? keyboard_arrow_down

Index indicates that the manual covers electrical systems in specific chapters dedicated to components like the alternator, regulator, and electronic instrument panel. These sections reference electrical components and system configurations for the supported tractor models. Please review the detailed index for exact page references regarding electrical schematic layouts.
