2007 KTM 450 SX-F, 505 SX-F & 450 SXS-F Service & Repair Manual (P/N 3.206.029-E)

This KTM repair manual covers the 2007 450 SX-F, 505 SX-F, and 450 SXS-F. Publication P/N 3.206.029-E, edition 10/2006, documents engine overhaul, carburetor service, electrical diagnosis, and selected chassis maintenance.

• Engine overhaul: Engine removal and installation, crankcase separation, crankshaft and piston inspection, cylinder-head service, valve-clearance adjustment, and camshaft timing.

• Clutch and transmission: Clutch wear checks, mainshaft and countershaft assembly, shift-mechanism inspection, starter-drive checks, and freewheel-hub service.

• Lubrication and cooling: Oil and filter changes, oil-pressure testing, oil-pump inspection, bypass-valve checks, water-pump service, and coolant replacement.

• Carburetor service: Keihin FCR-MX disassembly and assembly, float-height checks, accelerator-pump adjustment, throttle-position-sensor testing, and idle-mixture adjustment.

• Electrical diagnosis: Ignition-coil, pulse-generator, stator, starter-relay, and charging-system tests, supported by wiring diagrams and static peak-voltage measurements.

• Chassis and maintenance: Hydraulic-clutch bleeding, front and rear brake-fluid replacement, suspension setup tables, chassis tightening torques, and periodic maintenance schedules.

Written for qualified, professionally trained mechanics, this manual assumes knowledge of general workshop procedures and standard workshop safety practices.

Engine, Clutch, and Transmission Repair

The engine chapters cover internal inspection and reassembly, including crankshaft endplay, cylinder and piston size groups, camshaft-bearing clearance, automatic decompression, and valve-shim selection. Cylinder-head mounting specifications include a multi-stage torque-and-angle sequence.

Engine-case illustrations show bearing and seal placement. The Engine oil circuit drawing traces the pumps, metering jets, and transmission lubrication, while the lubrication section covers inspection of the oil-pump rotors and housings.

Clutch and Shift mechanism exploded views accompany component wear checks and transmission assembly information. Individual service sections also address the balancer gear, clutch cover, timing train, and starter freewheel hub.

Camshaft installation identifies adjusting bearing bridge 773.29.050.000 and timing-chain-tensioner unlatcher 773.29.051.000. The tensioner section explains how incorrect preparation can allow the chain to skip and cause engine damage.

Keihin Carburetors and Starting Faults

Fuel-system coverage is for Keihin FCR-MX carburetors: 4125G on the 450 SX-F and 450 SXS-F, and 4125H on the 505 SX-F. The specification tables distinguish their jetting and needle settings.

The carburetor exploded view accompanies checks for the choke slide, needle jet, float needle valve, and accelerator-pump diaphragm. Throttle-sensor tests and idle-adjustment procedures support diagnosis of starting and running problems.

Symptom/cause/remedy tables connect hard starting, poor idle, loss of power, overheating, and excessive oil consumption to the relevant checks. These references help narrow a complaint to its fuel, ignition, valve-clearance, cooling, or lubrication causes before replacement parts are selected.

Ignition and Charging Tests

The electrical chapter includes resistance measurements, static ignition and generator tests, charging-voltage checks, and battery-current-loss checks. Its annotated Wiring diagram identifies measurement points for the pickup, ignition coil, and generator.

The CDI section reserves unit testing for an ignition test bench and warns that conventional measuring equipment can damage its electronics. Performance and soft ignition-curve selection are also explained.

Brake, Clutch, and Chassis Reference

Hydraulic-clutch fluid checks and bleeding are treated separately from front and rear brake-fluid replacement. Chassis reference tables distinguish SX-F and SXS-F fork and shock settings and provide brake-disc wear limits and tightening torques. Suspension material consists of setup data and scheduled inspections.

Maintenance charts use operating hours and fuel consumption to separate workshop service from rider checks. Consult a certified technician before brake-system service.

A Preview of Valve-Clearance and Oil-Pressure Data

These values are a small sample of the inspection specifications included in the engine-service sections.

For all three models, cold valve clearance is 0.10–0.15 mm at the intake and 0.15–0.20 mm at the exhaust.

The oil-pressure test specifies at least 1.0 bar at 1,600 rpm with the engine oil at approximately 100°C. Bypass-valve guidance also explains how spring length and seal-ring thickness affect opening pressure.

Searchable Service Text and Wiring Diagram Detail

Text search and diagram navigation: The service chapters contain searchable text and embedded chapter and procedure bookmarks. Some rotated wiring labels do not respond to normal text searches. Small wire-color labels are readable when the diagrams are rotated and enlarged.

Supplied as one printable, 132-page PDF download. The total includes the cover, a binder-spine sheet, four pages of front matter, and 22 blank pages. The repair text is in English, with a multilingual wiring glossary.
