Haynes Service & Repair Manual: Yamaha XJ600S Diversion, XJ600S Seca II and XJ600N Motorcycles - Factory-Grade Service & Repair Guide, covers 1992-1999
Product Gallery
Sample pages from the Haynes Service & Repair Manual: Yamaha XJ600S Diversion, XJ600S Seca II and XJ600N Motorcycles - Factory-Grade Service & Repair Guide, covers 1992-1999 manual
Purchase Information
1992-1999 Yamaha XJ600S Diversion, Seca II & XJ600N Haynes Service Manual - Technical Specifications
- Document Number / Seller:
- 23325 / Deborah Lee
- File Size:
- 42.70 MB
- File Type:
- Language:
- English (some of our manuals are multi-language)
- Pages:
- 162
- Printable:
- Yes
- Estimated Download Time:
- 0.87 Minutes
- Delivery Format:
- Digital (PDF) - Instant Access
- Category:
- Motorcycle
- Brand:
- Yamaha
- Reviewed and Approved:
- Dec 25, 2025
Yamaha Models and Parts Covered in this Motorcycle Manual
- Yamaha XJ600S Diversion (1992-1999)
- Yamaha XJ600S Seca II (1992-1999)
- Yamaha XJ600N (1995-1999)
Complete Manual Information
Haynes Service & Repair Manual: Yamaha XJ600S (Diversion / Seca II) & XJ600N (1992-1999)
Maintain, service, and repair your Yamaha middleweight with the absolute authority in DIY guides. This Haynes Service & Repair Manual covers the iconic XJ600 series, including the half-faired Diversion and the "naked" XJ600N. Whether you are performing a simple oil change or a complete engine overhaul, this manual provides the factory-grade information required to get the job done right.
The Yamaha XJ600 series is celebrated for its air-cooled simplicity and "bulletproof" reliability. By using this guide, you ensure that your bike continues to deliver the smooth, all-round performance it was designed for.
Models Covered in This Manual
- Yamaha XJ600S Diversion (UK 1992-1999)
- Yamaha XJ600S Seca II (US 1992-1999)
- Yamaha XJ600N (UK 1995-1999)
Technical Highlights & Model Evolution
The XJ600 series features a 598cc DOHC air-cooled inline-four engine tilted 35 degrees forward to lower the center of gravity. This design allows for straight inlet tracts and downdraft Mikuni carburetors, a technology derived from the high-performance Genesis-engined FZR series.
This manual documents the specific changes throughout the production run:
- 1996 (UK) / 1997 (US) Updates: New style fairing and windshield for the XJ600S, and new rear bodywork for both models (identified by the black fillet between the tank and side cover).
- European Specifics: Detailed info on the oil cooler, electric fuel pump, and throttle position switch (TPS) found on later European models.
- Braking Systems: Comprehensive coverage of both the single front disc and the later twin front disc brake setups.
Expert Guidance for Every Task
- Routine Maintenance: Step-by-step instructions for the 500-mile chain service, 4,000-mile oil changes, and critical valve clearance adjustments (every 16,000 miles).
- Engine & Transmission: Complete teardown and rebuild procedures for the six-speed constant-mesh gearbox and the rubber-mounted engine.
- Fuel System: Detailed carburetor synchronization using vacuum gauges and float level adjustments.
- Chassis & Suspension: Servicing the 38mm telescopic front forks (including oil level measurements) and the rear Monoshock linkage.
- Wiring Diagrams: Full-color schematics to help you troubleshoot electrical issues quickly.
Identification & Technical Data
To ensure you are ordering the correct parts, this manual explains exactly where to find your motorcycle's identification numbers:
- Frame Serial Number: Stamped into the steering head and printed on a label on the right front portion of the frame.
- Engine Number: Stamped into the right upper side of the crankcase.
- Carburetor ID: Essential for precise tuning and jetting.
Product Specifications
- Author: Alan Ahlstrand and John H. Haynes
- Publisher: Haynes Publishing
- ISBN: 1 85960 551 6
- Engine Specs: 598.8cc, Bore 58.5mm, Stroke 55.7mm, Compression 10:1.
- Torque Settings: Full list included (e.g., Oil drain plug: 43 Nm / 31 ft-lbs).
Stop relying on guesswork or generic online forum advice. This Haynes manual is based on a complete teardown and rebuild of the XJ600 in the Haynes workshop, providing you with "factory-grade" knowledge and the confidence to handle any repair yourself. Save on dealer labor costs and keep your Yamaha XJ600 in peak condition for years to come!
