Mitsubishi Fuso 2002 FE/FG Truck Service Manual Set
1,599 Pages • Printable PDF • 50.05 MB • Download
Mitsubishi Models Covered & Key Technical Specifications
Models & Model Codes: Fuso FE639 (FE639C chassis-code example, FE639□6 brake variant), FE640, FE649, FG639, FG649
Sub-models / Variants: Chassis cab, Mixer, Crew cab. The brake section uses FE64□ for FE640 and FE649.
VIN identifiers: Position 5 identifies the model line (A = FE639, B = FE649, G = FG639, H = FE640, K = FE640□W, L = FG649). Position 7 identifies the cab chassis type (1 = Chassis cab, 3 = Mixer).
Model Year: 2002
-
Engine model: 4M50T2 (FE640), 4D34T3 (all others)
-
Engine displacement: 4.899 liters (299 cu. in.) for 4M50T2, 3.907 liters (240 cu. in.) for 4D34T3
-
Engine compression ratio: 17.5:1
-
Max. power output: 175 HP @ 2700 rpm (4M50T2), 145 HP @ 2900 rpm (4D34T3)
-
GVW ratings: 12000 lbs through 14500 lbs
-
Wheelbase options: 2.6 m to 4.39 m
-
Transmission variants: FE639 and FE649 use the M035S5 manual or M035A4 automatic, depending on configuration. FE640 uses the M035A4 automatic. FG639 uses the M035A4 automatic with the TF3 transfer case. FG649 uses the M035S5 manual with the TF3 transfer case.
Mitsubishi Manual Features & Selected Content Preview
| Publication | Pages |
|---|---|
| 2002 Mitsubishi Fuso FE/FG Truck Service Manual, April 2001. Covers FE639, FE640, FE649, FG639, and FG649 and includes the How to Read This Manual guide (Pub. No. TWSE0101-H). | 1,471 |
| Group 27 Rear Axle (P/N TWSE0304-27), FE/FG rear hubs, final drive, and differential | 54 |
| Group 37 Steering (P/N TWSE0304-37), FE/FG power steering | 40 |
| Group 55A Air Conditioner (P/N TWME0103-55A), 2002 FE/FG cab A/C | 34 |
The base manual covers powertrain and chassis work. The later rear axle and steering publications provide separate specifications and procedures for those assemblies, and Group 55A covers the factory cab A/C.
The M035A4 automatic transmission section covers diagnosis, unit removal, and replacement of designated service parts. Its planetary geartrain coverage explains operation.
PDF Search, Bookmarks, and Wiring Detail
Finding procedures and wire labels — Text search works through most of the set. The A/C body pages and many labels within wiring diagrams are available as images. Embedded bookmarks open the main groups and many subsections. Zooming in makes the small pin numbers and wire codes easier to read on dense ABS and transmission diagrams.
The four publications are combined in one printable, 1,599-page PDF. The total includes the cover and section title pages.
Diesel Overhaul, Driveline Service, and Electrical Diagnosis
This selection of workshop procedures is part of a broader service reference that also covers turbo boost testing and leaf-spring service.
- Diesel engine repair — Compression and valve-clearance checks, engine removal, cylinder-head work, timing gears, piston and liner or sleeve service, and crankshaft inspection.
- Clutch and driveline — C4W30 clutch hydraulics, M035S5 internal repair, M035A4 transmission testing, TF3 transfer-case service, and propeller-shaft overhaul and balancing.
- Axles, brakes, and steering — FE and FG hub and axle procedures, differential setup, disc and drum brake service, ABS testing and bleeding, and power-steering performance checks.
- Fuel and electrical diagnosis — MUT-II fault-code and service-data checks, ECU pinouts, connector-face charts, and wiring diagrams for tracing faults through the harness.
- Frame, cab, and climate control — Frame inspection and repair, fixed- and tilt-cab removal, door fitting, and heater and A/C service.
This set is suited to truck technicians familiar with drivetrain overhaul, pressure testing, and MUT-II diagnostics.
Engine and Driveline Repair
The powertrain table and chassis, engine, and powertrain-label references help match parts and procedures to the truck. The table also identifies the P2 and P3 propeller shafts, R033T rear axle, D033H final drive, and modified D1H front drive on FG models.
The 4M50T2 DOHC chapter covers the twin-cam rocker and camshaft-frame layout, balance shafts, cylinder liners, and split crankcase. The 4D34T3 OHV chapter covers the pushrod valve train, cylinder sleeves, and flywheel assemblies with and without flywheel PTO. The 4M50T2 camshaft frame and cylinder head are a factory-machined pair, and the gear-removal procedure calls for a press.
The M035S5 procedures extend to the reverse idler, drive pinion, mainshaft, countershaft, and shift controls. M035A4 diagnosis includes stall, time-lag, line-pressure, and road tests. The service coverage includes fluid, cooler, and control work. The FG transfer chapter covers the front and rear drives.
Axles, Brakes, and Steering
Front axle procedures distinguish FE hub, rotor, and kingpin work from FG hub, drum, drive-shaft, and front differential service. The rear axle material covers final-drive setup and multiplate limited-slip clutch adjustment. The brake group separates FE639□6 disc brake procedures from other FE639 configurations.
Brake service covers the master cylinder, Master Vac booster, vacuum pump, and exhaust brake. The ABS bleeding section explains how early activation can move air into the secondary circuit and how repeated MUT-II actuator cycling can overheat the hydraulic unit. Steering coverage includes FE and FG booster variants, the pump, drag link, and tie rod.
Wiring, Cab, and A/C
The 4M50T2 timing-gear and balance-shaft exploded view shows the assembly layout. Electrical references include the engine ECU pin configuration, automatic transmission wiring diagram, ABS circuit and component locations, 425 Water Temperature Gauge Circuit, and 810 Four-Wheel Drive Circuit. Use the connector-face chart with the circuit pages to match a wire code to its terminal and test point.
The fuel-system groups cover code reading and clearing, 4M50T2 actuator tests, ECU connector checks, and intermittent faults. Group 54 covers starting and preheating, charging and grounds, lighting and warning circuits, PTO, and starter and alternator repair.
Cab procedures include tilt adjustment, mounts, front and crew-cab rear doors, mirrors, wipers, instrument panel, trim, and glass. Group 55A covers refrigeration troubleshooting, post-installation checks, the cooling unit, and compressor and clutch service. The heater group covers hoses, controls, ducts, and the blower.
Major engine, driveline, cab, brake, ABS, and refrigerant work requires suitable equipment and training. Follow the factory safety precautions.
Compression and Shift-Time Specifications at a Glance
For both diesels, the on-vehicle compression tables give 370 psi as the standard and 285 psi as the service limit per cylinder at 200 rpm, with coolant at approximately 167–185°F.
For the M035A4, the time-lag test lists a standard of 0.7 second or less from Neutral to Drive and 1.2 seconds or less from Neutral to Reverse, at idle with fluid at 122–176°F.
The manual also includes maintenance schedules, lubrication charts, torque and capacity tables, lubricant and sealant specifications, wear limits, and electrical test values. Listed tools include belt-tension gauge MH062345, compression adapters MH063434 and MH061460, engine front hanger MH062781, and MUT-II accessories MB991499 and MB991500.
