Forklift Mitsubishi FG15K, FD15K, FG18K, FD18K, FG20K, FD20K, FG25K, FD25K, FG30K, FD30K, FG35K, FD35K Service Manual

• Covers the Mitsubishi FG15K-FD35K forklift series from 1.5 to 3.5 tons, detailing diesel and gasoline configurations with varying mast types
• Official Mitsubishi publication P/N 99719-53120, serving as the authorized reference for professional fleet maintenance and heavy equipment repair
• Contains 47 detailed exploded-view diagrams for powertrain and electrical assemblies, plus four comprehensive wiring schematics for both fuel types
• Complete 100-page first edition documentation providing the exact assembly tolerances and torque values required for safe mechanical work

Component and System Documentation

This official OEM service manual delivers comprehensive diagnostic routines and structural overviews for the 1.5-3.5 ton FG and FD series. It focuses heavily on mechanical, electrical, and hydraulic assembly standards. You get detailed diagnostic logic for the advanced AC control system, including exact pinout identification for the controller. Does your shop handle intricate electrical issues? The troubleshooting paths map out the entire finger-control joystick system. Each section relies on precise assembly illustrations and breakdown sequences to detail components like the console box, combination meter, and hydraulic transducer array. We know that maintaining heavy machinery involves inherent safety risks. Always secure the chassis properly, release hydraulic pressure, and observe standard workshop safety protocols prior to inspecting these systems. Structural outlines cover the cooling system, front and rear axle groups, and the powershift transmission to ensure every internal part is clearly identified for shop scheduling.

Specification and Reference Data

Specification tables document core performance thresholds across the entire FG15K-FD35K line. The text lists exact fluid capacities for engine oil and coolant networks. Need to adjust the valves? You will find precise clearance specifications for both the OHC gasoline engines and OHV diesel units. Cylinder bore and stroke dimensions are clearly mapped alongside compression ratios for the 4G63, 4G64, S4Q2, and S4S powerplants. When facing electrical faults, technicians can immediately reference voltage values for the controller or decode specific flickering LED patterns tied to individual diagnostic conditions. Maintenance schedules define the required tolerances for the mast, lift chains, and service brakes. This exact data is what streamlines the repair process in any professional workshop environment.
