1969-1978 Honda CB750, CB750F Shop Manual

Shop manual for all 1969-1978 Honda CB750 and CB750F models, covering engine mechanical, chassis, electrical, and periodic maintenance procedures. Ref: Honda CB750 Shop Manual

4.5starstarstarstarstar_half(2)
visibility Preview Available
Honda 1969-1978 Honda CB750, CB750F Shop Manual manual page preview - page 1 of

Sample pages from the 1969-1978 Honda CB750, CB750F Shop Manual manual

Honda 1969-1978 Honda CB750, CB750F Shop Manual manual preview page 1 - thumbnail
Honda 1969-1978 Honda CB750, CB750F Shop Manual manual preview page 2 - thumbnail
Honda 1969-1978 Honda CB750, CB750F Shop Manual manual preview page 3 - thumbnail
Honda 1969-1978 Honda CB750, CB750F Shop Manual manual preview page 5 - thumbnail
info_outline Click thumbnails to preview different pages
$17.96 (incl. VAT) Original OEM Factory Manuals & Data Instant Download / No Shipping Fees
2 copies sold
OR BUY NOW
verified_user
Lifetime Access
Re-download anytime
flash_on
Instant Download
Get it immediately
lock
Secure Payment
PayPal
Technical Safety Notice
keyboard_arrow_down

This official OEM document is intended for professional technicians and skilled operators. Performing service on mechanical equipment involves inherent risks. By purchasing, you acknowledge that RepairLoader provides original manufacturer data for informational purposes. Always prioritize safety: use correct tools, wear protective gear, and consult a certified professional if you are uncertain of any procedure.

Honda Models Covered & Key Technical Specifications

Models: Honda CB750, Honda CB750F
Sub-models / Variants: CB750K1, CB750K2, CB750K3, CB750K4, CB750K5, CB750F1, CB750K6, CB750K7, CB750F, CB750K
Build Years: 1969–1978
Serial Numbers: CB750 1000001–, CB750K1 1055004–, CB750K2 2000001–, CB750K3 2200001–, CB750K4 2341915–, CB750K5 2525947–, CB750F 1000002–, CB750F1 2000003–, CB750K6 2540001–, CB750K7 2700002–, CB750F 2100001–, CB750K 2800001–, CB750F 3100002–
Technical Data:

  • Engine: Air-cooled, 4-stroke, OHC, 4-cylinder in-line
  • Displacement: 736 cc (44.93 cu-in)
  • Compression Ratio: 9.0:1
  • Horsepower: 67 BHP at 8,000 rpm
  • Transmission: 5-speed, constant mesh
  • Starter: Electrical motor and kick starter
  • Ignition: Battery and ignition coil
  • Alternator: Three-phase A.C., 12 V, 0.12 kW at 5,000 rpm
  • Tire Pressure: 28 psi front and rear
Technical Specifications
keyboard_arrow_down
Document Number / Seller:
30839 / Steven Harris
File Size:
22.28 MB
File Type:
ZIP
Language:
English
Printable:
Yes
Category:
Motorcycle
Last updated / verified
Apr 13, 2025

Honda Manual Features & Content Preview

Honda CB750 CB750F 1969–1978 Shop Manual Technical Coverage

  • Covers 1969–1978 Honda CB750 and CB750F motorcycles, including K1 through K7 variants and frame-specific service configurations
  • Official Honda publication dated 1977, documenting factory specifications and technical procedures
  • Contains over 150 detailed figures and exploded-view diagrams covering engine, transmission, clutch, and electrical systems
  • Downloads to your account within seconds of checkout
  • Your order stays downloadable from your account for life
  • Indexed PDF search covers every chapter and appendix
  • Full-text search finds any part number in seconds
  • The 1977 edition is the definitive reference for the CB750 launch series, maintaining alignment with the 1969–1978 production run of 4-cylinder OHC models

Engine and Transmission Walkthrough

The 1969–1978 Honda CB750 shop manual details the maintenance of the 736 cc 4-stroke OHC engine, including dry-sump lubrication, camshaft drive systems, and complex carburetor assembly. The document describes component inspection and service for the clutch pack and the 5-speed constant mesh transmission, providing standard values and serviceable limits for gear backlash, fork clearance, and shaft wear.

Additional chapters cover the charging system, ignition timing, and periodic maintenance, offering insight into the Hitachi alternator, regulator, and ignition coil testing. Readers can access what an OEM service publication covers regarding electrical diagnostics, including battery capacity and charging current test procedures across engine RPM ranges.

Specification Highlights

Detailed tables provide critical reference values for the Honda CB750 series, such as the 12 V electrical system parameters and valve tappet clearances of 0.05 mm intake and 0.08 mm exhaust. Intake valve timing opens at 5° before top dead center, as documented in the engine mechanical data section. The carburetor main jet size is listed as #120, with fuel tank capacity totaling 18 liters. This publication serves as an essential resource for owners and mechanics maintaining the 1969–1978 Honda CB750, providing exhaustive technical data, serial number ranges, and adjustment procedures for the entire 4-cylinder model line.

Manual FAQ, Purchase & Download Details

Can you provide details about the publication data and document information included in this official shop manual? keyboard_arrow_down

Manual is an official Honda publication produced in 1977 and covers the Honda CB750 and CB750F models. It includes a comprehensive foreword and group index for navigating the various technical sections of the document.

Which chapters contain electrical system information such as wiring diagrams and connector references? keyboard_arrow_down

Document includes Group 16 for body electrical and instruments and Group 17 specifically for the wiring diagram reference.

What information regarding exploded views and component breakdown diagrams can be found within the various groups of this manual? keyboard_arrow_down

Manual contains numerous photographs and illustrations throughout the groups to show component locations and assemblies. These visual aids are intended to simplify the identification of parts and system structures. Detailed exploded views and service illustrations are present for major systems like the engine mechanical and transmission sections.

Does the manual contain specification tables for fluid capacities and engine technical data? keyboard_arrow_down

Specification tables are included in Group 1, providing reference data for fuel capacity, oil tank volume, and other dimensions for the covered models.

Are specific frame numbers or model identifiers listed for the various versions of the CB750 covered in this publication? keyboard_arrow_down

Foreword lists initial serial numbers for multiple models, including the CB750, CB750K, and CB750F variants from 1969 through 1978. This information helps users correlate their motorcycle with the corresponding chapters and supplement sections in the manual.
