2013 Nissan Frontier D40 Series Accelerator Control System Service Manual

2013 Nissan Frontier D40 Accelerator and Brake System Documentation

• Covers the 2013 Nissan Frontier D40 series accelerator control and braking systems, including pedal removal, assembly inspection, and hydraulic circuit specifications
• Official Nissan publication, revision date December 2012
• Contains 12 detailed exploded-view component diagrams, 8 electrical pinout and terminal layout tables, and 6 torque-specification tables for critical fastening
• Accessible from your device as soon as the order is placed
• OCR text layer lets you jump to a torque spec by keyword
• This specific edition provides the precise reference values required for D40 chassis brake hydraulic circuit maintenance and accelerator pedal assembly service

System Coverage and Components

This service document outlines the procedures and technical requirements for the 2013 Nissan Frontier D40 accelerator control and brake systems. The coverage spans essential maintenance data for the accelerator pedal assembly, including the removal and installation of the sensor unit. Further chapters provide specifications for the primary and secondary master cylinder circuits, including anti-lock brake system (ABS) actuator integration and routing schematics for the four-channel hydraulic system. The manual details the inspection of brake booster operations, vacuum lines, and check valves, while also documenting the maintenance of disc brake assemblies including caliper, torque member, and pad return spring service.

Specifications and Diagnostic Data

Technical reference values include precise torque settings for brake components and pedal assembly fasteners. The master cylinder union bolt torque is documented at 18.2 N·m (1.9 kg-m, 13 ft-lb). Flare nut M10 connections are specified at 16.2 N·m (1.7 kg-m, 12 ft-lb). The brake pedal free height and stroke parameters for M/T and A/T variants are listed in the inspection tables. The document provides what an OEM service publication covers for these subsystems, ensuring precision during component assembly. Diagnostic information includes consult function mappings for BCM-controlled systems, ensuring that technicians can verify system status during service. All service data shown here is for reference only — qualified technicians and the original OEM documentation remain the authoritative source for any hands-on work. An official 100-page Nissan OEM service manual covering the 2013 Nissan Frontier, documenting brake and accelerator control specifications for the D40-series build.
