1994-1995 Nissan Maxima Automatic Transaxle Service Manual

1994–1995 Nissan Maxima Automatic Transaxle Service Documentation

• Covers 1994–1995 Nissan Maxima models equipped with the RE4F04A or RE4F04V automatic transaxle units
• Official Nissan publication, section AT (Automatic Transaxle), extracted from 1994–1995 service documentation
• Documents electrical pinouts, connector layouts, and diagnostic reference values for 20+ sensors and solenoid circuits
• Includes 15 comprehensive circuit diagrams and 35+ systematic diagnostic flow charts for common A/T faults
• Indexed PDF search covers every chapter and appendix
• Accessible from your device as soon as the order is placed
• Suitable for printing individual sections for shop-floor use
• This 1994–1995 edition provides the factory-authorized troubleshooting architecture for the RE4F04A series transaxle, bridging diagnostic fault codes with physical component inspections

Troubleshooting and Diagnostics

The 1994–1995 Nissan Maxima automatic transaxle service publication provides a deep dive into the A/T control system, focusing on signal processing and sensor-based diagnostic procedures. Major sections detail the hydraulic control circuit, internal shift mechanism, and solenoid operations, providing technicians with the data required for pin-level signal analysis at the A/T control unit.

Following the diagnostic philosophy of the period, the what an OEM service publication covers includes detailed troubleshooting trees for shift timing concerns, lock-up anomalies, and fail-safe mode operations. Diagnostic procedures address specific symptoms such as abnormal shifting into 1st, 2nd, 3rd, or 4th gear, torque converter clutch engagement issues, and engine brake malfunctions during deceleration.

Technical Reference and Specification Highlights

Technical data within the 1994–1995 Nissan Maxima manual provides critical operating thresholds for components like the throttle position sensor, fluid temperature sensor, and various solenoid valves. The manual lists electrical reference values, such as the throttle position sensor signal, which is documented at 0.2–0.6V for fully closed throttle positions. Fluid temperature sensor resistance for the Nissan Maxima is documented at 2.5 kΩ at a cold temperature of 20°C (68°F). The torque converter clutch solenoid valve ground resistance is specified at 10–16 ohms in the electrical components inspection table.

Note: This document is a technical reference for qualified mechanics; it does not replace the need for hands-on experience or adherence to established safety practices when working on high-pressure hydraulic transmission components.
