Massey Ferguson 5400 series, 5425, 5435, 5445, 5455, 5460, 5465, 5470, 5475, 5480 tractor repair manual

Price: 24.99 USD
Lifetime Guarantee
File specifications File size: 49.78 MB File ending in: pdf
To make it easier for you to choose the right manual, we have compiled various information for you below, such as model designations, types, and production years. The manual is valid for the following models: 5400, Massey Ferguson 5400 / Massey Ferguson Corporation, built in Beauvais, France Massey Ferguson 5425 - Year: 2003-2008 Massey Ferguson 5435 - Year: 2003-2008 Massey Ferguson 5445 - Year: 2003-2008 Massey Ferguson 5455 - Year: 2003-2008 Massey Ferguson 5460 - Year: 2003-2008 Massey Ferguson 5465 - Year: 2003-2008 Massey Ferguson 5470 - Year: 2003-2008 Massey Ferguson 5475 - Year: 2003-2008 Massey Ferguson 5480 - Year: 2003-2008 Engines: 82 hp to 135 hp Massey Ferguson 5425 engine: 4 cyl./4.4 liter, 82(60.4), 86(63.3), Engine specs: Perkins 1104, turbocharged diesel, 4-cylinder, liquid-cooled vertical, 268 ci, 4.4 L, 4.134x5.00 inches, 105 x 127 mm, 80 hp, 59.7 kW, direct injection, 18.2:1. Massey Ferguson 5435 engine: 4 cyl./4.4 liter, 92(67.7), 96(70.7), Engine specs: see above, 268.5 ci, 4.4 L, 4.134x5.00 inches, 105 x 127 mm, 75 hp, 55.9 kW, 19.3:1. Massey Ferguson 5445 engine: 4 cyl./4.4 liter, 95(69.9), 100(73.6), Engine specs: Massey Ferguson 5455 engine: 4 cyl./4.4 liter, 105(77.3), 112(82.4), Engine specs: see above, 16.2:1. Massey Ferguson 5460 engine: 4 cyl./4.4 liter, 115 (85), 125 (92), 135 (99) Engine specs: Perkins 1104, turbocharged diesel, 4-cylinder, liquid-cooled vertical, 268 ci, 4.4 L, 4.134x5.00 inches, 105 x 127 mm, 105 hp, 78.3 kW, 17.5:1, Massey Ferguson 5465 engine: 6 cyl./6.6 liter, 120 (88), 130 (96), 140 (103) Engine specs: see above, 75 hp, 55.9 kW, 19.3:1. Massey Ferguson 5470 engine: 4 cyl./4.4 liter, 125 (92), 135 (99), 145 (106) Engine specs: ..., see above, 18.5:1 Massey Ferguson 5475 engine: 6 cyl./6.6 liter, 135 (99), 145 (106), 155 (114) Engine specs: Perkins 1106, turbocharged diesel, 6-cylinder, liquid-cooled, 402 ci, 6.6 L, 4.134x5.00 inches, 105 x 127 mm, 135 hp, 100.7 kW, 16.2:1 Massey Ferguson 5480 engine: 4 cyl./4.4 liter, 135 (99), 145 (106), 155 (114) Engine specs: 49CTA, turbocharged diesel, 4-cylinder, liquid-cooled, 299 ci, 4.9 L, 4.252x5.276 inches, 108 x 134 mm, 140 hp, 104.4 kW, 17.5:1 Production year(s): 2003, 2004, 2005, 2006, 2007, 2008 Pages: 886 Manual Language: English Delivery: Download link will appear on the checkout page after your payment is complete. # ³ "OEM Massey Ferguson Agricultural Tractor: Download Parts List and Manual for 5400 Series and Variants" Welcome to our comprehensive guide on the Massey Ferguson 5400 series agricultural tractors, including the 5425, 5435, 5445, 5455, 5460, 5465, 5470, 5475, and 5480 models. These tractors are known for their power, reliability, and versatility, making them popular choices among farmers and agricultural enthusiasts. In this guide, we'll provide you with detailed engine specifications, key facts, maintenance tips, popular modifications, compatible accessories, owner reviews, and common repair needs for the Massey Ferguson 5400 series. Whether you're a seasoned tractor owner or a prospective buyer, this comprehensive manual will equip you with the knowledge to maintain and optimize the performance of your Massey Ferguson tractor. Engine Specifications / Technical Data: • Model: Massey Ferguson 5425 Engine: AGCO Power, 3.3L, 4-cylinder turbocharged diesel Rated Engine Power: 75 horsepower PTO Power: 68 horsepower Transmission: 12 forward and 12 reverse gears Hydraulic System: Open center with dual remote valves Rear Lift Capacity: Up to 4,630 lbs (2,100 kg) • Model: Massey Ferguson 5435 Engine: AGCO Power, 3.3L, 4-cylinder turbocharged diesel Rated Engine Power: 85 horsepower PTO Power: 75 horsepower Transmission: 12 forward and 12 reverse gears Hydraulic System: Open center with dual remote valves Rear Lift Capacity: Up to 4,850 lbs (2,200 kg) • Model: Massey Ferguson 5445 Engine: AGCO Power, 4.4L, 4-cylinder turbocharged diesel Rated Engine Power: 95 horsepower PTO Power: 82 horsepower Transmission: 12 forward and 12 reverse gears Hydraulic System: Open center with dual remote valves Rear Lift Capacity: Up to 5,070 lbs (2,300 kg) • Model: Massey Ferguson 5455 Engine: AGCO Power, 4.4L, 4-cylinder turbocharged diesel Rated Engine Power: 105 horsepower PTO Power: 92 horsepower Transmission: 12 forward and 12 reverse gears Hydraulic System: Open center with dual remote valves Rear Lift Capacity: Up to 5,070 lbs (2,300 kg) • Model: Massey Ferguson 5460 Engine: AGCO Power, 4.4L, 4-cylinder turbocharged diesel Rated Engine Power: 110 horsepower PTO Power: 95 horsepower Transmission: 12 forward and 12 reverse gears Hydraulic System: Open center with dual remote valves Rear Lift Capacity: Up to 5,070 lbs (2,300 kg) • Model: Massey Ferguson 5465 Engine: AGCO Power, 4.4L, 4-cylinder turbocharged diesel Rated Engine Power: 120 horsepower PTO Power: 105 horsepower Transmission: 12 forward and 12 reverse gears Hydraulic System: Open center with dual remote valves Rear Lift Capacity: Up to 5,070 lbs (2,300 kg) • Model: Massey Ferguson 5470 Engine: AGCO Power, 4.4L, 4-cylinder turbocharged diesel Rated Engine Power: 130 horsepower PTO Power: 115 horsepower Transmission: 16 forward and 16 reverse gears Hydraulic System: Open center with dual remote valves Rear Lift Capacity: Up to 5,070 lbs (2,300 kg) • Model: Massey Ferguson 5475 Engine: AGCO Power, 4.9L, 4-cylinder turbocharged diesel Rated Engine Power: 140 horsepower PTO Power: 120 horsepower Transmission: 16 forward and 16 reverse gears Hydraulic System: Open center with dual remote valves Rear Lift Capacity: Up to 5,070 lbs (2,300 kg) • Model: Massey Ferguson 5480 Engine: AGCO Power, 4.9L, 4-cylinder turbocharged diesel Rated Engine Power: 150 horsepower PTO Power: 130 horsepower Transmission: 16 forward and 16 reverse gears Hydraulic System: Open center with dual remote valves Rear Lift Capacity: Up to 5,070 lbs (2,300 kg) Facts and Details: - The Massey Ferguson 5400 series tractors are designed to deliver impressive power and performance for various farming tasks. - These tractors feature advanced AGCO Power diesel engines known for their fuel efficiency and durability. - The 5400 series tractors are equipped with user-friendly transmissions, offering multiple gears for smooth shifting and optimal speed control. - A robust hydraulic system with dual remote valves provides excellent lifting capacity for various implements and attachments. - The tractors' ergonomic operator stations offer comfort and convenience during long hours of operation. - The rear lift capacity of up to 5,070 lbs (2,300 kg) allows for handling heavy loads and implements with ease. - The 5400 series tractors offer excellent visibility, allowing operators to maneuver with precision in tight spaces. - These tractors come with a variety of optional features, including cabin suspension, front-end loaders, and additional lighting options. - The 5400 series tractors are known for their reliability and low maintenance requirements, contributing to overall cost-effectiveness. - With their versatile design and wide range of attachments, these tractors can efficiently perform tasks such as plowing, planting, harvesting, and material handling. Maintenance Intervals, General Maintenance Tips, and Common Issues: ► Engine Oil and Filter Change: Every 100 to 150 hours of operation or per manufacturer's recommendations. ► Hydraulic Fluid and Filter Change: Every 500 hours or per manufacturer's guidelines. ► Air Filter Cleaning/Replacement: Every 200 to 300 hours or as needed to maintain engine performance. ► Fuel Filter Replacement: Every 300 hours or as needed to prevent fuel system issues. ► Greasing and Lubrication: Regularly grease all pivot points and moving parts to reduce wear and friction. ► Belt Inspection and Replacement: Inspect drive belts regularly and replace if worn or damaged. Common Issues and Solutions: * Hydraulic System Leaks: Inspect hydraulic hoses and connections for leaks and replace any damaged components. * Engine Overheating: Ensure proper coolant levels and clean the radiator and cooling system to prevent overheating. * Transmission Slippage: Check and adjust transmission fluid levels and inspect for any signs of wear on clutch components. * Electrical Issues: Regularly check battery connections and wiring for corrosion or damage. * Steering Problems: Check the power steering fluid levels and inspect the steering linkage for any wear or damage. Five Tips for Effective Maintenance: ✔ Follow the Manufacturer's Recommended Maintenance Schedule. ✔ Regularly Check Fluid Levels and Top Them Up as Needed. ✔ Keep the Engine and Hydraulic System Clean and Properly Maintained. ✔ Grease All Pivot Points and Moving Parts Regularly. ✔ Address Any Performance or Warning Issues Promptly to Prevent Costly Repairs. Popular Tuning Tips and Modifications: + Engine Performance Upgrades: Some tractor enthusiasts opt for engine tuning to increase power and torque output. + Implement Enhancements: Installing specialized attachments for specific tasks, such as front-end loaders, backhoes, or mowers. + Lighting Upgrades: Adding additional lighting to improve visibility during low-light conditions or nighttime operation. + Cab Comfort Upgrades: Customizing the tractor's cabin with better seating, climate control, and entertainment systems. Accessories and Attachments: ■ Front-End Loaders and Attachments ■ Rear Implements (Backhoes, Mowers, Seeders, etc.) ■ Front and Rear Weights for Ballasting ■ Agricultural Tires and Tracks ■ Cab Accessories (Seat Covers, Floor Mats, Climate Control) ■ Additional Lighting (LED Work Lights) ■ Tractor Canopies and Covers ■ Rear Three-Point Hitch Implements ■ Pallet Forks and Bale Spears ■ Front Blade and Snow Removal Attachments ■ Tractor Toolboxes and Storage Solutions Owner Reviews: Strengths: ☺ Powerful and reliable performance for various farming tasks. ☺ Comfortable and ergonomic operator station for long hours of operation. ☺ Versatile design with a wide range of compatible attachments. ☺ Low maintenance requirements and overall cost-effectiveness. ☺ Excellent visibility and maneuverability for precise operation. Weaknesses: ☻ Limited availability of certain parts and accessories in some regions. ☻ Lack of advanced technology and modern features compared to newer models. ☻ Some owners may find the initial investment cost relatively high. The Massey Ferguson 5400 series tractors, including the 5425, 5435, 5445, 5455, 5460, 5465, 5470, 5475, and 5480 models, stand as reliable workhorses that meet the demands of modern farming. With their robust engine performance, versatile attachments, and comfortable operator stations, these tractors are well-suited for a variety of tasks on the farm. Regular maintenance and attention to potential issues are crucial to keeping these tractors in top-notch condition. Whether you're a seasoned farmer or a new tractor owner, this comprehensive guide equips you with the knowledge and resources to optimize your Massey Ferguson tractor's performance and ensure its productivity for years to come. Repairs Needing Frequent Attention and Parts That Often Break: → Hydraulic System Components (Hoses, Valves) → Engine Cooling System (Radiator, Water Pump) → Transmission Clutch and Related Components → Electrical Components (Wiring, Starter, Alternator) → Power Steering System (Steering Pump, Hoses) Get your hands on the comprehensive Massey Ferguson PDF manual, encompassing the detailed shop handbook and maintenance guidelines, by clicking on the green button. Upon completing your payment, you will receive the original Massey Ferguson shop manual and parts list download link on the checkout page, along with a prompt email containing the payment confirmation. §
Price: 24.99 USD
Lifetime Guarantee
