2005 Canon LaserBase MF5730 / MF5750 / MF5770 Service & Repair Manual Set

Canon’s MF5700 Series Service Manual, dated May 31, 2005, covers the LaserBase MF5730, MF5750, and MF5770, including fax-equipped and non-fax configurations. This collection also includes the February 23, 2005 parts catalog and five service bulletins covering firmware revisions and production changes.

• Paper handling: Cassette pickup roller, separation pad, feed roller, pickup solenoids, main motor, and gear-unit removal procedures, with paper-jam detection logic.

• Scanner and ADF: Removal procedures for the scanner assembly, ADF unit, CCD unit, and flatbed motor, plus document-feed cleaning and lubrication information.

• Fixing and image formation: Fixing film unit, fixing pressure roller, and transfer charging roller service, with laser/scanner assembly removal and fixing-protection descriptions.

• Control boards and power supplies: SCNT procedures for fax and non-fax units, DCNT and NCU board removal, and power-supply and high-voltage PCB replacement.

• Service diagnostics: Service Soft Switch Settings, DRAM checks, print-pattern tests, modem transmission tests, sensor-status checks, and operation-panel testing.

• Parts and illustrations: More than 200 technical illustrations, including exploded assembly views, sensor and PCB location diagrams, and parts-number indexes.

This documentation is suited to service technicians familiar with multifunction laser printers and fault isolation at board and sensor level.

Paper Path, Scanner, and Fixing Service

The Pickup and Feed System diagram traces cassette and manual-feed operation through the transfer and fixing assemblies. Separate explanations distinguish pickup delay, stationary, delivery, wrap, and cover-open jams.

Disassembly coverage extends from outer covers and frame components to the gear unit and paper-feed mechanisms. Scanner procedures identify the CCD drive belt, flatbed motor, cable connections, and grounding hardware involved in assembly removal.

The Laser Exposure and Fixing Unit drawings explain the optical path and on-demand fixing mechanism. Fixing protection covers CPU monitoring, the heater safety circuit, and the thermal fuse. Laser/scanner service covers assembly replacement; its internal optical components are not designed for field disassembly.

Work around laser assemblies, high-voltage power supplies, and hot fixing components requires the precautions described in the manual.

Electrical Diagnosis and Fax Service

The Arrangement of Sensors and Switches and Arrangement of PCBs diagrams identify the components used in the troubleshooting sections. Connector references link fault checks to the SCNT, DCNT, power-supply, and laser/scanner assemblies.

Test Mode provides live sensor states and current jam-code indications. Black and Endurance print patterns help distinguish printer-section defects from scanning faults before components are selected for replacement.

Fax coverage includes the Conexant FM336Plus modem, transmission protocols, frequency tests, G3 and V.34 signal tests, and NCU line-signal reception checks. Service data includes country-specific defaults, initialization options, and selected soft-switch explanations.

The error-code section covers product-specific remedies, including E000 fixing failures and E100 laser/scanner failures. Other fax error remedies and inherited service-data explanations refer to the separate G3/G4 Facsimile Error Code List and G3 Facsimile Service Data Handbook.

Cleaning, Lubrication, and Handling Cautions

Cleaning tables connect image defects and feeding symptoms with the affected assemblies. Lubrication drawings identify application points and distinguish MOLYKOTE EM-50L, EMD-110, MOLYKOTE 41, and IF-20; the service-material list supplies their ordering references.

The cassette-sensor bulletin explains how loading paper from the rear with the cassette installed can bend the sensor-flag shaft and cause incorrect paper detection. The image-formation section also warns that strong light exposure can produce photo memory on the photosensitive drum, causing white spots or black lines.

Firmware Bulletins and Parts Identification

The SCNT bulletins document WLaa-55-08 and WLaa-56-02 revisions, including changes related to scanning, interrupted printing, and fax reception. They reference Service Support Tool and Canon MF Version Up Tool; firmware files and update software are not included in this PDF.

The parts catalog uses an Assembly Location Diagram, exploded views, quantities, and regional remarks to support parts identification. Its coverage also includes MF5630 and MF5650 parts; the main service manual covers the MF5700 models listed above.

A Preview of Recurring Image-Defect References

The cleaning chart provides these examples from the manual’s component-specific service information.

White spots recurring at about 46 mm are listed under the transfer charging roller. Image soiling at about 57 mm is associated with the fixing film, while traces on the back of the paper at about 64 mm are listed under the fixing pressure roller.

Searchable PDF, Bookmarks, and Included Publications

Search and diagram detail: PDF text is searchable across the service manual, bulletins, and parts catalog. Bookmarks link to chapters and parts figures, although two parent entries have no direct destination. Small diagram labels remain readable when enlarged. Maintenance page 4-8 appears at PDF p. 182, outside its chapter sequence.

The collection is supplied as one printable, English-language, 250-page PDF.

Covers, contents pages, seven blank pages, and publisher end pages are already included in these counts.
