Canon iR5000 / iR6000 Copier Service Manual, 2000 (P/N FY8-13GS-000)

803 Pages • Printable PDF • 7.21 MB • Download

4.6starstarstarstarstar_half(5)
$4.59 Instant Download / No Shipping Fees
or

Credit/debit card, Apple Pay or Google Pay

30-day refunds for defective files or manuals not as described. Refund policy.

print
Save & print
Keep a copy on your device
lock
Secure Payment
Stripe

Canon Models Covered & Key Technical Specifications

Models: iR5000, iR6000

Sub-models / Variants: 100-V model, 120-V model, 220-V model, 230-V model

Accessories: Finisher-F1, Saddle Finisher-F2, Paper Deck-G1 (A4 and LTR types), Puncher Unit-B1/C1/D1

Copier Serial Prefixes:

100 V (50/60 Hz) — iR5000: LQH, LQJ | iR6000: LQK, LQL

120 V (50/60 Hz) — iR5000: NRF, NRG | iR6000: NRH, NRJ

220 V (60 Hz) — iR5000: PKM | iR6000: PKL

230 V (50/60 Hz) — iR5000: PKK, PKL, QCW, PBZ, SCK, TBZ, UFM | iR6000: PKZ, PLH, QCX, RCY, SCL, TCM, UFN

Accessory Serial Prefixes: Paper Deck-G1 (A4: XCQ, LTR: XCR), Shift Tray-B1 (XCS)

Model Year: 2000


  • Copying speed: 50 copies/min (iR5000), 60 copies/min (iR6000)

  • Reading resolution: 600 x 600 dpi

  • Printing resolution: 1200 x 600 dpi equivalent (copier mode, smoothing on, varies by model), 2400 x 600 dpi equivalent (printer mode)

  • Power consumption: Max 1.3 kW

  • Drum type: Amorphous silicon drum (80-dia.)

  • Hard disk capacity: 6.4 GB or 5.1 GB

  • Maximum paper capacity: 7650 sheets

Canon Manual Features & Selected Content Preview

Canon’s Revision 0 service manual (P/N FY8-13GS-000, July 2000) covers the iR5000 and iR6000 console copiers, with serial-prefix tables for their regional power-supply configurations.

PDF Search, Bookmarks, and Page Count

Navigation and diagram detail: The PDF has searchable text and bookmarks for chapters, service procedures, and appendix diagrams. Zoom in to read small connector numbers, pin numbers, and signal labels in the main circuit diagram.

The manual is delivered as one 803-page PDF, including the original covers, publisher’s pages, and two pages marked blank.


Copier Repair and Fault Diagnosis

Selected service topics are listed below. The manual also covers laser safety and power-saving modes.

  • Controller startup: Boot-ROM checks, system software loading from the hard drive into SDRAM, and wiring and I/O references for the main, DC, and reader controllers.

  • Reader service: Scanning-lamp and scanner-motor removal, drive-cable routing, and positioning of the No. 1 and No. 2 mirror bases.

  • Image formation: Laser scanner, drum and process unit, potential control, and primary, pre-transfer, transfer, and separation charging assemblies.

  • Paper path and fixing: Pickup, registration, feeding belt, and duplex assemblies, plus service procedures for the fixing unit’s cleaning web and separation claws.

  • Installation: Site selection, unpacking, scanner and printer assembly setup, front-deck paper-size configuration, image checks, relocation, and installation of Control Card IV and NE Controller-A1.

  • Diagnostics: Image-adjustment routines, photointerrupter checks, service-mode test prints, and self-diagnosis for image, feeding, and electrical faults.

  • Accessory service: Operating theory, adjustments, and disassembly for Paper Deck-G1 and Shift Tray-B1, with separate circuit diagrams for each.

Canon issued this manual for qualified service personnel working on copier installation, maintenance, diagnosis, and repair.

Image Processing and Board Replacement

The image-processing diagrams trace reader data through scaling, edge emphasis, LUT density conversion, T-BIC error diffusion, and dithering. They also show how the controller handles compression, rotation, and output smoothing.

Board replacement procedures cover counter-memory transfer for the main controller and EEPROM transfer for the DC controller. The HDD replacement section covers formatting and system software installation with Canon’s Service Support Tool.

Reader, Printer, and Paper-Path Adjustments

Reader service includes original-size and home-position sensors, inverter and fuse boards, and the CCD/AP PCB. Adjustment procedures cover scanner image-leading-edge and CCD read-start settings, shading after parts replacement, edge-gain correction, and auto density.

Printer procedures cover charging-wire routing, the potential sensor, the drum cleaner, the developing cylinder and blade, the magnetic seal, and the toner hopper. Paper-path references include deck and cassette registration, roller orientation and pressure, and timing charts for simplex and duplex operation. Fixing-unit service covers both rollers, heaters, thermistors, the thermal switch, delivery rollers, the inlet guide, and solenoid positions.

Troubleshooting and Maintenance

Symptom charts cover density and fogging problems, lines and spots, blank or solid-black prints, image-position faults, heater failures, jams, double feeds, and wrinkles. The surface-potential check helps isolate whether an image fault starts at the drum and its potential-control system or in developing or transfer.

Service-mode references cover DISPLAY, I/O, ADJUST, FUNCTION, OPTION, TEST, and COUNTER, including settings backup. Error-code tables explain detection conditions and likely causes. Maintenance tables list replacement parts, consumables, scheduled service points, and related counters. The appendix lists solvents, oils, and tools such as the NA-3 test sheet (FY9-9196), potential-sensor electrode (FY9-3012), environment-sensor checker (FY9-3014), and tester extension pins (FY9-3038/FY9-3039).

Accessory Repair Scope

Paper Deck-G1 procedures cover compartment removal, lifter-cable routing, paper registration, and deck-driver I/O. Shift Tray-B1 procedures cover the driver PCB, paper detection, limit-sensor adjustment, and tray-drive removal. Copier-side I/O, counters, and self-diagnosis are documented for the finisher and saddle stitcher. Detailed mechanical service for Finisher-F1, Saddle Finisher-F2, Puncher Unit-B1/C1/D1, and DADF-D1 requires the corresponding accessory manuals.

Drum Handling and Electrical Safety

An angled pre-transfer charging assembly can damage the drum surface. Counterclockwise drum movement during removal can disrupt cleaning-blade contact and cause cleaning faults.

Canon calls for checking the Execution/Memory lamp before switching off in printer mode and disconnecting the power plug before internal work. The cassette and drum heaters can remain energized with the main switch off. Switching off during a software download can disable the copier.

Fixing-Roller Nip Check Preview

With both fixing rollers fully heated under Canon’s specified warm-up and test-copy conditions, the center nip width is 7.8 ± 0.5 mm. The two readings taken 10 mm in from the paper edges may differ by no more than 0.5 mm. Both limits are used in the service-mode nip check.

Customer Reviews

Read what our customers say about this Canon Copier manual and share your own experience.

Checkout
Canon iR5000 / iR6000 Copier Service Manual, 2000 (P/N FY8-13GS-000) $4.59
