Canon imageRUNNER 600 2000 Service & Parts Manual Set (P/N DU7-1100-010)

1,205 Pages • Printable PDF • 43.65 MB • Download

4.6starstarstarstarstar_half(5)
$4.99 Instant Download / No Shipping Fees
or

Credit/debit card, Apple Pay or Google Pay

30-day refunds for defective files or manuals not as described. Refund policy.

print
Save & print
Keep a copy on your device
lock
Secure Payment
Stripe

Canon Models Covered & Key Technical Specifications

Models & Model Codes: imageRUNNER 600 (F13-5631: 120V/60Hz parts-catalog build)

Model Year: 2000

Parts-catalog serial coverage: F13-5631, NLE00001 onward

Service-manual regional serial prefixes: 100V: LLP; 120V (UL): NLE; 120V: NLZ; 230V (AMS): ULE; 230V (FRN): SLE; 230V (UK): QLE; 230V (DL): TLE; 230V (ITA): PLE; 230V (CA): RLE; 230V: PLP

Accessory variants: Side Paper Deck-C1 — A4 (serial prefix ZQY), LTR (serial prefix ZQZ); Network Printer Board-F1 (F61-7403, parts-catalog reference)


  • Copy speed: 60 cpm (copies per minute) at 1-to-n speed

  • Hard disk capacity: 2 GB standard

  • Print resolution: 2,400-equivalent × 600 dpi with the optional printer board; 1,200-equivalent × 600 dpi for the 120V UL model

  • Warm-up time: 5 minutes or less (at 20°C room temperature)

  • Paper capacity: Approximately 4,150 sheets standard, including the multifeeder, up to 7,650 sheets with Side Paper Deck-C1 (80 g/m² paper)

  • Power consumption: 2.0 kW maximum for 100V/20A, 120V and 230V configurations; 1.5 kW maximum for 100V/15A

  • Operating conditions: 15°C to 30°C temperature, 5% to 80% humidity

Canon Manual Features & Selected Content Preview

Publication Pages
Canon imageRUNNER 600 Service Manual — P/N DU7-1100-010, Revision 1, January 2000 875
Canon imageRUNNER 600 Parts Catalog — P/N DU7-3100-000, Revision 0, January 1999 330

The service procedures and illustrated parts reference support repair planning and parts ordering: diagnose the fault, identify the affected assembly, and match the applicable parts and configuration remarks before ordering.

Mechanical repair coverage centers on the copier and Side Paper Deck-C1. The ADF receives installation, I/O, and self-diagnosis coverage. Finisher-D1, Saddle Finisher-D2, saddle-stitcher, folder, and inserter information covers configuration, I/O, and self-diagnosis rather than complete standalone overhaul procedures.

The Service Manual refers readers to the separately issued Copier Basic Series for common copier technology. Optional printer functions receive board-handling and system-integration coverage rather than a separate controller service volume.

PDF Search, Bookmarks, and Diagram Detail

Search and diagram viewing: The service-manual section has searchable text; the parts-catalog section does not support PDF text searches. Embedded bookmarks provide navigation through both publications. Dense circuit-diagram sheets require zooming to read small pin, connector, and signal labels.

Both publications are combined in one printable, 1,205-page PDF. The total includes covers, front matter, blank pages, appendices, and the 18-page multilingual parts-list guide.


Copier Repair, Image Diagnosis, and Parts Identification

These selected content highlights outline the main service areas rather than reproduce the full contents. Further topics include installation of Control Card V and Copy Data Controller-A1.

  • Optical and image-processing service: Scanner drive cable and motor, scanning lamp, mirrors, CCD unit, image processor PCB, and image-server hard disk removal and replacement procedures.

  • Image-formation repair: Potential-system testing, laser and BD units, charging-wire routing and height adjustment, photosensitive drum, process unit, developing assembly, hopper, drum cleaner, and separation-claw drive.

  • Paper handling: Right and left decks, cassettes 3 and 4, and manual-tray pickup through registration, duplexing, reversal delivery, and jam detection.

  • Fixing-system service: Step-by-step procedures for fixing-assembly removal, heater and thermistor replacement, cleaning-belt service, upper and lower rollers, and nip adjustment.

  • Fault diagnosis: Image-fault charts, E-code and malfunction troubleshooting, paper-jam fault isolation, PCB input/output checks, service-mode adjustments, and PG test prints.

  • Illustrated parts reference: Exploded copier assemblies and Network Printer Board-F1 parts, supported by connector lists, a numerical index, and standard-fastener references.

Written for service personnel, this material is best suited to copier technicians familiar with digital-copier fundamentals, electrical testing, and service-mode work.

Image Adjustment and Electronic Replacement Work

The adjustment sections cover scanner-mirror alignment, image position and margins, surface-potential checks, roller and solenoid positioning, and separation pressure.

Replacement requirements: The CCD unit, image processor PCB, MFC PCB, hard disk, and laser unit have component-specific follow-up requirements. These include adjustment-data handling, initialization, or formatting as applicable; the DC controller PCB replacement section calls for no particular follow-up work.

Removal instructions also cover the system motherboard, memory board, and optional printer boards.

Diagnostic use: The Image Adjustment Basic Procedure separates printer-side test-print faults from scanner-side copy faults. This gives technicians a documented way to narrow the diagnostic area before selecting component tests or replacement work.

Electrical Reference and Maintenance Planning

The Wiring Diagram of Major PCBs and General Circuit Diagram are supported by the General Timing Chart, electrical test points, and component-location references. Malfunction troubleshooting extends through E830.

Service Mode documents DISPLAY, I/O, ADJUST, FUNCTION, OPTION, PG test-print, and COUNTER functions. Its diagnostic material covers the copier and the accessory systems identified above.

Service equipment: The appendix identifies the FY9-4008 laser power checker and FY9-2002 digital multimeter, FY9-3040 mirror-positioning tool, FY9-3041 potential-sensor tester electrode, FY9-9196 NA-3 test sheet, and TKN-0093 door switch.

Scheduled-replacement tables, durables data, servicing charts, and specified solvents and lubricants support maintenance planning alongside repair work.

Side Deck Service and Parts Matching

Side Paper Deck-C1 procedures include lifter-cable routing, paper-size changes, and registration adjustment, with related pickup, lifter, and driver-board service information.

Assembly identification: Exploded views such as the Fixing Assembly and System Box Assembly connect illustrated item numbers to OEM part numbers, descriptions, quantities, and serial-number remarks.

The catalog identifies the 120V/60Hz machine build shown in the model box, while individual parts tables distinguish 100/115/120V and 220/240V assemblies where required. Its shared 605/605V/600 family footers should be read alongside that machine identification. In the service specifications, the LEE serial prefix is separately assigned to the GP605V.

Component Handling and Electrical Isolation

Turning the photosensitive drum in the wrong direction after process-unit removal can bend the cleaning blade, while rotating the cleaner’s magnet roller can release toner. Incorrect positioning of the transfer/separation charging-assembly cleaner can damage its home-position microswitch.

Some circuits and heaters can remain energized when only the control-panel power switch is off. Copier repair around the power supply, laser, charging system, and hot fixing assembly requires the isolation and safety precautions stated in the manual.

Examples of Fixing-Nip and Laser Test Specifications

The fixing-nip table specifies a center nip width of 7.3 ± 0.5 mm with the upper and lower rollers sufficiently heated. The difference between the two edge measurements, taken 10 mm from the sheet edges, must be 0.5 mm or less.

For laser A and laser B output checks, the specified multimeter reading through the designated laser power checker is 6–8 mV for each laser.
