1985-1993 Yamaha VMX12 service manual Preview image 1
1985-1993 Yamaha VMX12 service manual Preview image 2
1985-1993 Yamaha VMX12 service manual Preview image 3
1985-1993 Yamaha VMX12 service manual Preview image 4
1985-1993 Yamaha VMX12 service manual Preview image 5
1985-1993 Yamaha VMX12 service manual Preview image 6

1985-1993 Yamaha VMX12 service manual

Models covered in this manual:

VMX12 / Yamaha Motor Corporation, Ltd

  • VMX12N-S-U-E (1985-1993)
  • VMX12NC-SC-UC-EC (1985-1993)

Production year(s): 1985, 1986, 1987, 1988, 1989, 1990, 1991, 1992, 1993

File specifications

File size: 30.84 MB
File type: PDF
Language: English (some of our manuals are multi-language)
Number of pages: 384

Printable: Yes
Estimated download time: 0.63 Minutes
$18.99 Instant Download

Pay with Bitcoin

Product Information

Table of Contents

General Information

  1. General Information
    • Introduction
    • Specifications
    • General Torque Specifications
    • Special Tools
    • Cable Routing

Periodic Inspections and Adjustments

  1. Periodic Inspections and Adjustments
    • Maintenance Schedule
    • Engine Oil and Filter
    • Air Filter
    • Fuel System
    • Cooling System
    • Drive Chain
    • Brakes
    • Tires
    • Steering System
    • Suspension
    • Battery
    • Lights and Signals

Engine

  1. Engine Overhaul

    • Engine Removal and Installation
    • Cylinder Head and Valves
    • Cylinder and Piston
    • Crankshaft and Crankcase
    • Lubrication System
    • Cooling System
  2. Fuel System

    • Carburetor
    • Fuel Tank and Fuel Pump
    • Fuel Line Inspection and Replacement

Chassis

  1. Chassis
    • Frame
    • Front Forks
    • Rear Suspension
    • Wheels and Tires
    • Swingarm
    • Handlebar and Steering Head

Electrical

  1. Electrical System
    • Wiring Diagram
    • Battery and Charging System
    • Ignition System
    • Starting System
    • Lighting System
    • Switches
    • Fuses and Relays

Drive System

  1. Drive System
    • Clutch
    • Transmission
    • Drive Shaft and Final Drive

Troubleshooting

  1. Troubleshooting
    • Engine Troubleshooting
    • Electrical Troubleshooting
    • Chassis Troubleshooting

Appendices

  1. Appendices
    • Technical Data
    • Conversion Tables
    • Glossary of Terms
