Ducati S2R 1000 Performance & Maintenance Guide 2006 Factory Edition (P/N 91470611A)

• 541-page PDF: one separate non-factory front cover plus the 540-page bilingual Italian/English Ducati workshop manual for the Monster S2R 1000, M.Y. 2006, Edition 00.
• Covers the 992 cc air-cooled Desmodromic L-twin from complete engine removal through lubrication-system service, timing and valve work, cylinder-head and piston overhaul, crankcase separation, and bottom-end reassembly.
• Follows the dry multi-plate clutch and six-speed gearbox through clutch and primary-drive repair, gear-selector and shaft disassembly, gearbox inspection, backlash checks, shimming, and final positioning checks.
• Details adjustable front-fork overhaul, steering-head service, eccentric rear-hub and swingarm work, rear shock and linkage overhaul, hydraulic brake repair and bleeding, wheel service, and final-drive inspection.
• Includes Magneti Marelli IAW/5AM2 injection-ignition and Ducati DDS diagnosis, with fault retrieval, active tests, TPS reset, cylinder synchronization, timing-belt tension checks, compression and pressure testing, charging-system checks, and immobilizer override.
• Supplies frame and engine torque tables, service limits, clearances, fluids and capacities, suspension settings, electrical test data, a two-page wiring schematic, and 19 photographic harness-routing plates labeled A-H, J-N, P-R, and T-V.

Factory Scope and Model Identification

This is the model-specific factory repair publication for the 2006 Monster S2R 1000, not a generic Monster handbook or an S2R 800 manual. The identification section explains European and U.S. frame and engine stamp formats, including the ZDM 992A2 European and RAB U.S. engine-type examples. Regional content is separated where it matters: the three-way catalytic-converter description applies to EU machines, while the evaporative canister system is identified for U.S. versions.

Ducati states that the manual was prepared for technical personnel at Authorized Service Centers and that its operations require experienced, skilled technicians. Basic technical knowledge is assumed. Repair sequences begin with the assembled motorcycle and generally carry the job through removal, inspection, refitting, and return to the assembled condition; scheduled maintenance and pre-delivery checks are covered as well.

Engine, Drivetrain, and Chassis Repair Depth

The engine chapters document the oil pump, oil cooler, and breather system; Desmodromic opening and closing rocker clearances; engine timing; belt tensioners and pulleys; camshafts; valves, guides, and seats; cylinders and pistons; and head removal and overhaul. Bottom-end work extends to the flywheel-generator assembly, starter drive, crankcase opening and closing, main bearings, shaft and gearbox-drum shimming, crankshaft and connecting-rod inspection, and final gearbox positioning.

Chassis procedures cover wheel and bearing overhaul, adjustable fork disassembly and seal service, steering-head bearings, frame inspection, the single-sided swingarm and eccentric hub, swingarm endfloat, rear shock and rocker/tie-rod service, sprocket replacement, and O-ring chain care. Brake and clutch sections include hydraulic circuit draining, filling, bleeding, hose routing, master/slave cylinder work, caliper service, and wear inspection.

Diagnostics, Diagrams, and Shop Data

The DDS material goes well beyond a list of fault codes. It covers stored-fault reading and deletion, live engine parameters, active operation of the fuel pump, coils, injectors, and tachometer, guided diagnosis, CO adjustment, road-test data recording, and measurement-module use. Notable visuals include the two-page main wiring diagram, the 19 photographic harness-routing plates, the fuel-system diagram, injection sensor-position diagram, timing diagram, and engine lubrication-system layout. Exploded assembly views open the component repair chapters.

The service-tool catalog identifies factory equipment by part number, including DDS kit 97900.0215, timing check tool 88713.0123, crankshaft holding tool 88713.2011, clutch-center wrench 88713.2133, and fork-seal installer 88713.1096. Reference data covers component-specific torque settings, approved fluids, valve and timing specifications, cylinder/piston and connecting-rod limits, gearbox clearances, suspension baseline settings, brake wear limits, and electrical checks.

Repair Cautions and Scope Limits

The timing chapter warns that reusing the self-locking sprocket ring nuts can allow the pulleys to loosen and cause serious engine damage. During fork overhaul, forcing the inner and outer tubes with tools can damage the oil seals and bushings.

Some basic workshop knowledge is intentionally omitted, and certain component-installation details are left to the Ducati spare-parts catalog; the manual also directs technicians to current Technical Bulletins for updated procedures. Engine removal, fuel-pressure testing, and brake or clutch hydraulic work require the specified support equipment, test gear, and safe handling practices.
