1983-1987 Honda ATC200X, ATC 200 3-wheeler repair manual

Price: 18.99 USD
Lifetime Guarantee
File specifications File size: 115.98 MB File ending in: zip
To make it easier for you to choose the right manual, we have compiled various information for you below, such as model designations, types, and production years. Overhaul/Fix your ATV/3-wheeler: Get this Honda Motor Co. Ltd ATC200X manual. Manual details, specs and technical data: Production year(s): 1983, 1984, 1985, 1986, 1987 The following models are included in this manual: ATC 200X / Honda Motor Co. Ltd Manual/e-book format: PDF / .zip / .exe Manual Language: English # ³ "Get Your 1983-1987 Honda ATC200X/ATC 200 3-Wheeler Manual and Parts List Now" Are you a proud owner of a 1983-1987 Honda ATC200X/ATC 200 3-wheeler and in need of a reliable manual and parts list? Look no further! Our PDF version of the original OEM manual has been used by certified professional mechanics and dealership technicians for service, maintenance, and repairs. 25 engine specs/technical specifications for the 1983-1987 Honda ATC200X, ATC 200 3-wheeler: • Engine type: air-cooled, 4-stroke, single-cylinder • Displacement: 192 cc • Bore x stroke: 65.5 mm x 57.8 mm • Compression ratio: 9.2:1 • Maximum power: 16 hp @ 8,500 rpm • Maximum torque: 10.3 lb-ft @ 6,000 rpm • Ignition system: CDI (capacitor discharge ignition) • Fuel system: carburetor, 26 mm • Lubrication system: wet sump, gear pump • Starter system: kick-start • Transmission: 5-speed manual with reverse • Final drive: chain • Suspension (front): independent, double-wishbone, coil spring, hydraulic shock absorber • Suspension (rear): swingarm, mono-shock, hydraulic shock absorber • Brakes (front): hydraulic disc • Brakes (rear): mechanical drum • Tires (front): AT21x8-9 • Tires (rear): AT22x11-8 • Wheelbase: 47.8 inches • Ground clearance: 5.7 inches • Seat height: 30.9 inches • Fuel tank capacity: 2.7 gallons • Overall length: 72.8 inches • Overall width: 43.5 inches • Overall height: 43.7 inches Start your next 1983-1987 Honda ATC200X/ATC 200 3-wheeler repair project with our comprehensive manual and parts list, available for purchase on www.repairloader.com with secure PayPal checkout. Get your hands on our 1983-1987 Honda ATC200X/ATC 200 3-wheeler manual and parts list and gain access to all the information you need for your repairs. After payment, expect to receive an email with all the download information within one minute.
Price: 18.99 USD
Lifetime Guarantee
