1983–1987 Suzuki RG250 Service Manual (P/N P/N 99500-12051-01E, 99500-12061-01E)

451 Pages • 70.82 MB • Printable PDFs (ZIP Download)

4.5starstarstarstarstar_half(4)
visibility Preview Available
$18.00 Original OEM Factory Manuals & Data Instant Download / No Shipping Fees
OR BUY NOW

Cards and eligible digital wallets

verified_user
Lifetime Access
Re-download anytime
flash_on
Instant Download
Get it immediately
lock
Secure Payment
Stripe

Suzuki Models Covered & Key Technical Specifications

Models: RG250, RG250H

Sub-models / Variants: Half Cowling, Full Cowling

Model Years: 1983–1987 (1983, 1984, 1985, 1986, 1987)

Technical Data:

  • Engine type: Two-stroke, water-cooled

  • Engine displacement: 247 cm3

  • Number of cylinders: 2

  • Bore and stroke: 54.0 mm x 54.0 mm

  • Compression ratio: 7.0:1

  • Transmission: 6-speed constant mesh

  • Carburetor: MIKUNI VM28SS, twin

  • Fuel capacity: 17 L (Reserve: 4.7 L)

  • Engine oil capacity: 1.2 L

  • Transmission oil capacity: 850 ml

  • Dry mass: 128 kg (Half cowling), 130 kg (Full cowling)

Technical Specifications
keyboard_arrow_down
Document Number / Seller:
26482 / Carol Torres
File Size:
70.82 MB
File Type:
ZIP
Language:
English
Pages:
451
Printable:
Yes
Category:
Motorbike
Last updated / verified
Aug 31, 2026

Suzuki Manual Features & Content Preview

  • 451-page English OEM PDF set: RG250W Service Manual, publication Part No. 99000-12051-01E (242 PDF pages; second edition, December 1984), plus the RG250 Service Manual, Part No. 99500-12061-01E (209 PDF pages; second edition, October 1990; copyright 1990).
  • Model and variant coverage: RG250W '83-year base procedures, the RG250WE '84-model change section, later RG250 machines in half-cowling and full-cowling form, and the RG250H '87-model service-data supplement.
  • Engine and driveline repair: engine removal and installation, crankcase disassembly and reassembly, cylinder and piston inspection, crankshaft and connecting-rod checks, clutch service, six-speed transmission and shift-fork work, kick-starter and gearshift assemblies, and final installation checks.
  • Fuel, cooling, and electrical systems: carburetor overhaul and adjustment, CCI oil-pump inspection and cable setting, fuel-cock service, radiator and water-pump repair, charging and ignition tests, switches and instruments, plus the later RG250 automatic exhaust-control unit and actuator.
  • Chassis and suspension work: hydraulic front and rear brake repair and bleeding, RG250W anti-dive fork service, later RG250 fork service, steering-stem bearings, wheel and tire work, swingarm inspection, and Full-Floater rear-suspension disassembly and reassembly.
  • Factory reference material: periodic maintenance schedules, symptom-based troubleshooting tables, wiring diagrams, cable/harness/hose routing sheets, exploded assembly views, special-tool part numbers, component-specific torque charts, capacities, inspection limits, adjustment data, and electrical test specifications.

Coverage and Edition Structure

This is a two-publication factory manual set, not one continuous all-years book. Each publication uses nine numbered groups, with Group 9 reserved for the model-specific update. The RG250W manual supplies the full '83-year workshop procedures, then devotes Section 9 to the RG250WE '84-model changes. The update identifies revised piston and cylinder service selection, a redesigned clutch stack with V-rings and a wave washer, changed clutch pushrods, early and late magneto rotors, revised fuel-cock routing, a split water-pump idle-gear arrangement with shim selection, and the added E.A.C.S. air-control and solenoid system.

The '84-model section also separates market-dependent equipment. Its tables and drawings distinguish twin- and single-front-disc arrangements, front-fork and brake-caliper changes, combination-meter and lighting differences, and fairing equipment used for specific E-code markets. This helps prevent choosing a repair procedure or replacement part for the wrong build.

The later RG250 publication shows both half-cowling and full-cowling machines and carries the standard repair procedures in Sections 1 through 8. Section 9 is a differential RG250H '87-model service-data supplement. It does not repeat the teardown chapters: the manual directs the reader back to Sections 1 through 8 except where the '87 data section changes a specification. That scope distinction matters when selecting this set for an RG250H repair.

Workshop Repair Depth

Opening groups cover serial-number locations, cylinder identification, approved fluids, break-in, special materials, and periodic schedules. The engine chapters then follow the shop sequence from removal through internal inspection and reassembly. Coverage reaches the cylinder head, cylinders, pistons and rings, crankshaft, connecting rods, bearings, oil seals, clutch, primary drive, transmission shafts, gears, shift forks, kick starter, gearshift mechanism, generator rotor, and water-pump drive. Inspection tables provide the related wear limits, clearances, runout limits, and service criteria.

The manuals identify carburetor versions and jetting tables, show removal and internal inspection, cover float-height and throttle-cable adjustment, and document CCI oil-pump checking, adjustment, and air removal after system service. Cooling-system material covers the circuit layout, radiator and hose removal, thermostat testing, water-pump seal and gear service, and water-temperature gauge diagnosis.

Electrical repair includes charging-system circuit diagrams and output tests, regulator/rectifier checks, ignition-coil and pickup-coil testing, CDI-related inspection, battery service, lamp and switch continuity tables, instrument-cluster inspection, and wiring diagrams. The later RG250 chapter adds the automatic exhaust-control unit and actuator diagram, operating inspection, cable setting, and actuator checks.

Diagrams, Routing Sheets, and Special Tools

Representative factory illustrations include transmission and crankshaft exploded views; radiator, water-hose, and water-pump layouts; charging and ignition circuits; the automatic exhaust-control unit/actuator schematic; the combination-meter connector view; and cable, main-harness, fuel-line, oil-line, and cooling-hose routing sheets. Troubleshooting tables cover the engine, carburetor, radiator, electrical system, battery, and brakes.

The tool index identifies Suzuki service equipment by part number. Examples include piston pin puller 09910-34510, clutch sleeve-hub holder 09920-53710, rotor holder 09930-40113, steering-stem nut wrench 09940-14911, front-fork oil-seal installer 09940-50112, and front-fork oil-level gauge 09943-74111. The RG250WE magneto-rotor update separately calls out rotor remover 09930-30102 with attachment 09930-30190 for the later rotor design.

The reassembly material flags two easy ways to damage parts. Piston-ring ends must remain indexed at their locating pins and the piston must be installed in the specified orientation; a misplaced ring can catch a cylinder port and score the piston and bore. The brake overhaul chapters warn that high-pressure air can damage caliper pistons and that gasoline or cleaning solvent can harm hydraulic rubber seals and cups.

Support the motorcycle securely before engine, wheel, fork, steering, or rear-suspension removal. Allow the cooling system to cool before opening it, and follow Suzuki's brake-fluid and electrical-safety cautions during repair work.
