Harley-Davidson Electra Glide / Duo-Glide 1959–1969 Service Manual (P/N 99482-69)

219 Pages • ZIP Download: 1 Printable PDF (English)

4.5starstarstarstarstar_half(2)
$18.55 Instant Download / No Shipping Fees
or

Credit/debit card, Apple Pay or Google Pay

30-day refunds for defective files or manuals not as described. Refund policy.

print
Save & print
Keep a copy on your device
lock
Secure Payment
Stripe

Harley-Davidson Models Covered & Key Technical Specifications

Models: Electra Glide, Duo-Glide

Sub-models / Variants: FL, FLH; Servi-Car coverage limited to selected shared-component sections

Model Years: 1959–1969 (1959, 1960, 1961, 1962, 1963, 1964, 1965, 1966, 1967, 1968, 1969)


  • Engine displacement: 1,207 cc (74 cubic inches)

  • Engine type: 2-cylinder 45-degree V-type, 4-cycle, air-cooled

  • Horsepower: FLH 66.0 HP at 5,600 RPM; FL 57.0 HP at 5,200 RPM

  • Transmission: 4-speed constant mesh (foot or hand shift); optional 3 forward speeds and 1 reverse (hand shift only; dedicated gearcase)

  • Compression ratio: FLH 8 to 1; FL 7.25 to 1

  • Fuel capacity: 3.5 gallons (early models), 5 gallons (1965 and later)

  • Fuel system: Model HD, Model M, and Model DC carburetors; Model MD for Servi-Car only

  • Electrical generator output: Minimum test output at 2,000 RPM: 15 Amps (6-volt standard), 10 Amps (12-volt standard), 20 Amps (fan-cooled)

  • Final drive chain play: 1/2 inch

  • Ignition timing serial break: 1961 Duo-Glide engines prior to Engine No. 61FLH 7987 have no rear-cylinder flywheel timing mark; the manual provides a piston-position timing procedure.

Harley-Davidson Manual Features & Selected Content Preview

Covers 1959–1969 Harley-Davidson Duo-Glide and Electra-Glide models, including FL and FLH specifications and service procedures. This factory service manual carries P/N 99482-69, with individual section revisions extending through 3-69.

PDF Access, Diagram Detail, and Page Contents

Search, navigation, and wiring detail: PDF text search and embedded bookmarks are not available. Navigation uses the printed contents and section page numbers. Small wiring labels require zooming.

The ZIP download contains one printable, English-language 219-page PDF, including one added CD cover, one foreword page, one title page, and eight contents or section-divider pages. Its six divisions cover Product, Chassis, Engine, Transmission, Electrical, and Miscellaneous service.


Engine Overhaul, Chassis Service, and Electrical Testing

The following selected coverage highlights outline the main workshop areas. Other topics include speedometer and tachometer cable service.

  • Engine repair: Cylinder-head and valve service, cylinder refinishing, piston and connecting-rod work, flywheel truing, crankcase bearings, and oil-system testing.

  • Chassis service: Wheel truing, hub bearings, frame alignment checks, Hydra-Glide fork repair, rear suspension, mechanical brakes, and hydraulic brake bleeding.

  • Transmission overhaul: Clutch and gearbox repair, foot- and hand-shift mechanisms, kick starters, electric-starter drives, and mainshaft and countershaft service.

  • Fuel systems: Model HD, Model M, and Model DC carburetor repair, including exploded views, adjustments, leakage checks, and fuel-supply service.

  • Electrical diagnosis: Factory wiring diagrams, generator output tests, ignition timing, regulator checks, and starter-motor repair across the documented electrical configurations.

  • Service references: Maintenance and lubrication charts, fits, clearances, spring loads, bearing dimensions, torque data, fluid capacities, and symptom-based troubleshooting checklists.

The manual introduces construction and basic maintenance and repair for readers, while its major repair methods are written for professional Harley-Davidson mechanics.

Engine and Crankcase Repair

The overhead-valve V-twin chapters distinguish FL and FLH specifications and cover rocker arms, valves and guides, cylinders, pistons, and tappets. Lower-end material addresses the oil pump, cam and breather timing, crankcases, connecting rods, flywheels, and pinion- and sprocket-shaft assemblies.

Bearing design changes: The 1969 sprocket-shaft bearing arrangement differs from 1968-and-earlier construction, with different races, spacers, and retaining components. These distinctions help match the overhaul procedure to the bearing assembly being serviced.

Illustrations include Engine Cutaway (1967 Model Shown) and Sprocket Shaft Bearing Assemblies - Section View. Assembly data covers cylinder-head bolts, flywheel gear-shaft and sprocket-shaft nuts, and crankpin nuts.

The oil-pump section warns that excessive fastener tightening can displace the plastic gaskets, eliminate pump-gear side clearance, and seize or damage the pump.

Wheels, Forks, Brakes, and Chains

Wheel hubs: Separate procedures address the 1966-and-earlier roller-bearing hub and the 1967-and-later ball-bearing design. Solo and sidecar gearing and tire data are included.

The chassis chapters also cover handlebar controls, seat components, and fiberglass body repair. Hydra-Glide Fork - Exploded View supports fork service, with distinctions between non-adjustable forks and adjustable solo/sidecar arrangements.

Brake work: Step-by-step instructions cover hydraulic brake bleeding and master-cylinder disassembly and assembly. Mechanical front-brake service and hydraulic rear and sidecar brake repair are also documented.

Determining Engine Sprocket Spacer Thickness to Secure Chain Alignment accompanies sprocket and chain service. Primary-chain adjustment distinguishes cold and hot conditions; rear-chain requirements are treated separately.

For primary chains used with a tensioner, the manual warns that a repair link can lead to chain failure and crankcase damage.

Frame dimensions support alignment checks; major frame straightening requires dedicated tools and fixtures.

Transmission, Clutch, and Starter Drive

Reverse-gear configuration: The optional reverse arrangement requires the appropriate hand-shift gearcase. It cannot be installed in a foot-shift model or assembled in a four-speed gearcase.

Clutch inspection and adjustment data accompany shifter-linkage, shifter-fork, main-drive-gear oil-seal, and gearcase repair procedures. Mainshaft Assembly - Exploded View shows the internal component arrangement.

The 1965-and-later electric-start material covers the Bendix-type starter drive. A chain-case vacuum check helps locate air leakage after engine or starter-related repair.

Carburetors and Servi-Car Coverage

The Model HD diaphragm carburetor section explains its automatic economizer and accelerator pump, then provides checks for inlet-needle leakage, check-valve operation, and related running faults. Model M and Model DC sections cover their respective adjustment and repair procedures.

Fuel-strainer, air-cleaner, tank, and fuel-supply-valve service are included.

Servi-Car scope: Coverage is limited to selected shared-component sections. The Model MD carburetor subsection specifically applies to 1966-and-later Servi-Car models.

Wiring, Ignition, and Electrical Repair

Separate wiring diagrams cover the 1959, 1960, and 1961–1964 Duo-Glide systems, plus 1965–1967 and 1968–1969 Electra-Glide systems. Examples include 1968-69 Electra-Glide Wiring Diagram.

Electrical repair extends to switches, lamps, standard and fan-cooled generators, regulators, and batteries. Component tests accompany service information for circuit breakers, ignition coils, spark plugs, horns, and starter motors.

Starter variants: Both Delco-Remy and Prestolite starter-motor service are included.

For 1961 Duo-Glide engines prior to Engine No. 61FLH 7987, rear-cylinder timing uses piston position because the flywheel lacks the corresponding timing mark. The manual identifies Spark Timing Gage P/N 95885-61 for this work.

The 1960-and-earlier and 1965-and-later ignition systems use a single set of breaker points with a double-lobe cam. The 1961–1964 arrangement uses two sets of points with a single-lobe cam.

The generator section warns that incorrect polarity can burn relay points, discharge the battery, and damage the generator.

Dedicated Service Tools

Tool references include P/N 96254-50 fork slider bushing tools, P/N 96740-36 connecting-rod lapping arbor, and P/N 96921-52 oil-pressure gauge.

The manual also specifies P/N 96950-68 chain-case vacuum gauge and P/N 95960-41A clutch-hub and chain-housing puller.

Follow the factory tolerances, test limits, and safety procedures, especially during brake service, primary-drive work, and electrical testing.

Examples of Ring-Fit and Chain-Case Test Data

The engine specifications give a piston-ring end gap of 0.010–0.020 in., supported by ring-gap and side-clearance inspection illustrations in the cylinder chapter.

For the 1965-and-later chain housing, the vacuum-check specification is at least 12 in. of water at 1,500 RPM. The accompanying discussion identifies gasket, solenoid, starter-shaft, and hose leakage as possible causes of a lower reading.

Customer Reviews

Read what our customers say about this Harley-Davidson Motorbike manual and share your own experience.

Checkout
Harley-Davidson Electra Glide / Duo-Glide 1959–1969 Service Manual (P/N 99482-69) $18.55
