Case International 1190/1194, 1290/1294, 1390/1394, 1490/1494, 1594 & 1690 Tractor Shop Manual (1980–1985)

Case International (David Brown) shop manual for the 1980–1985 1190, 1194, 1290, 1294, 1390, 1394, 1490, 1494, 1594, and 1690 tractors. Model-specific sections distinguish the applicable engine, clutch, transmission, axle, and hydraulic configurations.

PDF Page Access and Diagram Detail

Text search and page navigation: Manual text is not searchable. Embedded bookmarks provide numbered page access rather than topic-based navigation. Zoom is needed for small labels in the hydraulic schematics and electrical test drawings.

Supplied as one printable, English-language, 110-page PDF, including the cover and two index pages. File size: 74.22 MB.

Engine, Drivetrain, and Selectamatic Repair Coverage

These selected workshop topics outline the manual’s coverage rather than reproduce its complete index. Further sections address cab removal and the Thermostart cold-start system.

• Engine and cooling: Engine removal, cylinder-head service, timing gears, piston and crankshaft inspection, oil-pump overhaul, thermostat testing, and water-pump repair.

• Diesel fuel and turbochargers: Injection-pump removal and timing, injector testing and overhaul, fuel-system bleeding, and Holset and Schwitzer turbocharger service.

• Clutches, transmissions, and PTO: Tractor splitting, continuous and independent PTO clutch overhaul, Synchromesh repair, Power Shift planetary overhaul, and PTO assembly service.

• Axles and final drives: David Brown and Carraro front drive axle overhaul, transfer gearboxes, differential adjustment, bearing preload, and rear final-drive repair.

• Steering and brakes: Hydrostatic steering pressure tests, pump and valve overhaul, cylinder service, drum and multi-disc brake repair, and hydraulic bleeding.

• Selectamatic hydraulics: Lift-system troubleshooting, pressure checks, pump overhaul, control-valve adjustment, rockshaft repair, and draft-sensing linkage service.

• Electrical diagnosis: Lucas and Delco alternator tests, Lucas and Bosch starter overhaul, wiring fault checks, warning-light diagnosis, and cab accessory circuit testing.

Written for experienced mechanics, the manual includes procedures that call for splitting stands, lifting equipment, pressure gauges, and dedicated clutch fixtures.

Engine Overhaul and Fuel-System Testing

The engine sections provide model-specific cylinder-head tightening sequences, timing-gear illustrations, crankshaft inspection limits, and main-bearing installation data. Holset and Schwitzer turbocharger coverage extends to internal inspection and reassembly, with sectional views and explanations of lubrication-related failures.

Injection-pump procedures cover removal, installation, drive arrangements, and timing. Injector nozzles receive separate opening-pressure, leakage, and spray-pattern tests, followed by overhaul instructions requiring dedicated test equipment.

Clutch Fixtures and Power Shift Service

Borg and Beck continuous and independent clutch assemblies and Laycock dual clutches have separate overhaul instructions. Dimensioned clutch pilot-shaft drawings and a connector-plate drawing for Power Shift removal support tool preparation before major drivetrain work.

Power Shift coverage distinguishes front and rear sequence valves with different pressure settings. It also addresses planetary clutch packs, the range gearbox, and brake-band adjustment associated with delayed downshifts or poor holding on overrun.

The PTO installation instructions warn that pulling the assembly into position with mounting bolts can damage the engine crankshaft thrust surfaces.

Axle Variants, Steering, and Brakes

David Brown and Carraro AE1, AE2, AE3, and Type 709/19 axle procedures distinguish bearing-preload, pinion-protrusion, and differential adjustments. The component-specific P.I.N. breaks help match the installed configuration to the appropriate service information.

Illustrations include dimensioned trunnion-bushing placement, differential setting-tool views, and brake component layouts. Hydrostatic steering coverage includes valve timing; the manual warns that incorrect rotor timing can reverse the tractor’s steering response.

Brake sections distinguish shoe-and-drum assemblies from multi-disc units, with separate actuator, master-cylinder, wheel-cylinder, adjustment, and bleeding procedures.

Hydraulic Fault Tracing and Electrical Checks

Selectamatic troubleshooting separates failure to lift, hold a load, lower, or maintain depth control. Hydraulic schematics distinguish rear-mounted pumps, single front-mounted pumps, and tandem front-mounted pumps, allowing mechanics to follow the corresponding oil-routing arrangement.

Pump, remote-valve, combining-valve, and rockshaft sections extend the coverage beyond basic pressure checks. Draft-sensing adjustments include the Model 1594 lower-link sensing arrangement.

Electrical testing covers alternator output, regulator bypass, windings, and diodes, supported by test-connection drawings. Starter and accessory sections address solenoids, warning lights, wipers, blower motors, and the air-conditioning compressor clutch circuit.

Working with heavy tractor drivetrains and high-pressure hydraulics involves significant physical risks. Always verify shop safety protocols, relieve system pressure, and use properly rated support stands before beginning any teardown.

Cylinder-Head and Injector Specification Examples

For the 1594 and 1690, cylinder-head installation specifies tightening in stages to a final 135 N·m (100 ft-lb), alongside a dedicated tightening-sequence drawing and washer-orientation details.

Injector testing distinguishes opening pressures of 18,750 kPa (2,720 psi) for new injectors and 17,650 kPa (2,560 psi) for used injectors. An overhauled injector fitted with a new pressure spring uses the new-injector specification.
