Suzuki GSX13000R Hayabusa 2008 Service & Repair Manual (P/N 99500-39350-03E)

• Covers 2008 Suzuki Hayabusa GSX1300R K8 variants E-02, E-19, E-03, E-24, E-28, and California E-33, plus GSX1300RUF K8 (E-19).
• Engine removal and installation, top- and bottom-end disassembly and assembly, camshaft timing, valve-guide replacement, and valve-seat repair are covered.
• Six-speed transmission procedures include countershaft and driveshaft gear disassembly, shift-fork inspection, wet multi-plate clutch service, and hydraulic clutch master-cylinder and release-cylinder repair.
• Electrical circuit inspection procedures support FI fault tracing, user/dealer-mode diagnosis, Suzuki Diagnosis System testing, and separate primary- and secondary-injector circuit checks.
• Fuel and lubrication sections document fuel-pressure, pump-delivery, and oil-pressure testing; cooling-system coverage includes pressure testing and water-pump rebuilding.
• Suspension and steering work includes front fork overhaul, swingarm and cushion-lever bearing replacement, steering-stem bearing service, and steering tension adjustment.
• Brake-system diagnosis extends to front and rear caliper and master-cylinder disassembly, component inspection, reassembly, fluid replacement, and hydraulic bleeding.

K8 Model Coverage and Factory Publication

This 658-page PDF contains Suzuki Motor Corporation’s September 2007 factory service manual, P/N 99500-39350-03E, for the 1340 cc platform. The country-code table lists effective starting frame numbers, distinguishing the E-19 GSX1300R at JS1CK111100100001 onward from the GSX1300RUF at JS1CK211100100001 onward.

Variant-specific material covers the E-33 evaporative-emission system and purge-solenoid testing. Immobilizer operation and antenna service apply to E-02, E-19, and E-24. Throttle-body identification separates the E-33 unit, 15H1, from 15H0 for other markets.

Periodic Maintenance and Engine Repair

This manual covers the periodic service requirements for the GSX1300R. It details intervals for air cleaner element replacement, valve clearance adjustments, fuel line inspections, and cooling system maintenance. The schedule uses miles, kilometers, and months. Lubrication points and drive-chain inspection, adjustment, cleaning, and replacement procedures are also documented.

Internal engine repair coverage includes piston and ring inspection, crankshaft and connecting-rod bearing selection, thrust-clearance adjustment, and crank-balancer assembly. A separate chart identifies components removable with the engine still in the frame. The valve-seat repair section warns that lapping the titanium valves after seat servicing can remove their wear-resistant surface treatment.

FI Diagnosis, Sensor Adjustment, and SDS Procedures

Suzuki Diagnosis System (SDS) procedures cover current and stored diagnostic trouble codes (DTCs), fault-condition data, comparison with saved readings, and history-code clearing. The DTC tables identify C00 as no fault and connect the listed C-codes to their corresponding P-codes. C62/P0443 applies specifically to the E-33 EVAP purge circuit.

Circuit-specific charts also address secondary throttle valve actuator (STVA) and PAIR control solenoid faults. Throttle-body service includes SDS-assisted synchronization, idle speed control (ISC) learned-value reset and opening initialization, throttle position (TP) reset, and TP/secondary throttle position (STP) sensor adjustment.

Separate electrical checks address the drive mode selector, ignition coils, starter interlock, generator, and regulator/rectifier. Special-tool references include the SDS set 09904-41010, mode select switch 09930-82720, and drive-chain cutting and joining tool 09922-22711.

Wiring Diagrams, Service Data, and Chassis Scope

Separate wiring diagrams cover E-02/E-19/E-24, E-03/E-28, and E-33, alongside wiring harness routing and component-location diagrams. The FI System Wiring Diagram and Terminal Alignment of ECM Coupler support electrical diagnosis. Mechanical references include the Camshaft and Sprocket Assembly Diagram, Engine Lubrication Circuit Diagram, and Cooling Circuit Diagram. The EVAP Canister Hose Routing Diagram is specific to E-33.

The publication provides tightening torque values for both chassis and engine fasteners, plus fluid capacities, wear limits, valve-clearance data, and ECM sensor reference values, including ECT sensor resistance data.

Wheel-bearing replacement, wheel balancing, combination-meter testing, lighting service, and exterior-panel removal are covered. Rear shock coverage stops short of internal rebuilding: Suzuki treats the shock as a nonserviceable assembly, with inspection, adjustment, replacement, and disposal procedures instead.

Always verify your measurements against these published OEM parameters before operating the motorcycle, and complete the brake and steering checks specified for the repair.
