2006 Yamaha V-Star 1300 XVS13AW(C)/XVS13CTW(C) Service Manual (P/N LIT-11616-20-42)

This Yamaha workshop manual covers the 2006 XVS13AW(C) and XVS13CTW(C) V-Star 1300 cruiser and touring models. It is the first edition, August 2006, P/N LIT-11616-20-42, with cover code 3D8-28197-10.

Supplied as one 421-page PDF in English.

• Engine repair: Engine removal, cylinder-head and valve service, camshaft timing, piston and cylinder inspection, crankcase separation, and crankshaft bearing checks.

• Clutch and transmission: Wet-clutch disassembly, transmission gear and shaft inspection, shift-drum and shift-fork checks, balancer gears, and starter-clutch service.

• Chassis and brakes: Front fork overhauls, steering-head adjustment, brake caliper and master-cylinder repair, hydraulic bleeding, swingarm service, and drive-belt adjustment.

• Cooling and lubrication: Radiator and thermostat testing, water-pump seal replacement, oil-pump inspection, lubrication charts, and cooling-system diagrams.

• Fuel system: Throttle-body synchronization, fuel-pressure testing, injector inspection, throttle-position sensor adjustment, and California evaporative-emissions components.

• Electrical diagnosis: ECU self-diagnostics, sensor and actuator tests, starting and charging fault tracing, system circuit diagrams, and the color wiring diagram.

Written primarily for Yamaha dealers and qualified mechanics, this manual assumes a working knowledge of motorcycle mechanics and repair techniques.

Engine and Transmission Repair

The engine section covers the 1304cc SOHC V-twin from removal through disassembly and assembly. Cylinder-head work includes valve-guide replacement and valve-seat inspection, with separate front- and rear-cylinder camshaft alignment references. Periodic maintenance covers valve-clearance adjustment, ignition-timing checks, and compression testing.

Crankshaft procedures include connecting-rod bearing selection and clearance checks. The manual explains how interchanging connecting rods and big-end bearings can create incorrect clearances and damage the engine.

Clutch coverage addresses friction plates, the spring plate, and the built-in damper. Transmission procedures extend to gear engagement, shaft runout, and shift-fork installation. Component torque tables, tightening sequences, valve-clearance specifications, fluid capacities, and wear limits accompany the repair procedures.

Fuel Injection and Fault Diagnosis

The fuel sections distinguish USA/Canada throttle bodies from California versions and show California canister hose routing. Fuel-pump removal, sub-fuel-tank service, rollover-valve checks, and injector inspection are documented. Throttle bodies are treated as assemblies, with an explicit restriction against disassembly.

Meter-based diagnosis: The ECU self-diagnostic function and multi-function meter provide access to fault codes, sensor readings, actuator tests, and stored fault history. Fault tables connect symptoms with wiring, connector, sensor, and hose checks, helping distinguish a failed sensor from a connection or hose problem before parts are replaced.

Testing covers the ISC (idle speed control) unit, ignition coils, oxygen sensor, lean angle sensor, and front and rear intake air pressure sensors. Speed-sensor, fuel-sender, oil-level switch, and turn-signal relay checks support diagnosis of instrument and warning-light faults.

Cooling and Lubrication Systems

Radiator-cap pressure testing, thermostat operation, and water-pump inspection are covered alongside oil-pump rotor measurements and relief-valve checks. Water-pump assembly identifies the YM-33221-A seal installer. The Engine Oil Lubrication Chart and Cooling System Diagrams show passage and component relationships.

Brakes, Suspension, and Belt Drive

Front fork procedures cover bushings, seals, damper rods, and oil-level setting. Rear shock coverage addresses removal, inspection, preload adjustment, and linkage service; it does not provide an internal rebuild procedure for the nitrogen-charged shock.

Drive-belt service specifies the YM-03170 tension gauge and explains how excessive bending or twisting can damage the belt. XVS13CT touring equipment has separate removal diagrams for the windshield, sidebags, and backrest.

Before starting any job, ensure your workspace is secure, support the motorcycle safely, and verify you have the right specialty tools on hand.

Electrical Repair and Workshop Illustrations

Starter-motor disassembly includes brush and armature checks. Stator-coil and rectifier/regulator coverage concerns electrical testing and replacement. ECU and meter coverage is limited to circuit diagnosis and assembly replacement.

The Fuel Injection System circuit diagram and Starting Circuit Cut-off System Operation schematic support fault tracing. Exploded diagrams and job instruction charts accompany removal and assembly work, while Cable Routing diagrams identify harness, cable, and hose placement. The final troubleshooting chapter also covers mechanical symptoms such as shifting faults, clutch drag, and overheating.

File Format and Readability

The page total includes eight front-matter pages, four additional blank pages, a wiring-diagram legend, the publisher's back cover, and a one-page color wiring diagram.

Searchable PDF text is available across all nine chapters. Embedded bookmarks cover the chapters and major sections; the Table of Contents bookmark has no destination, and Back to Index points to a separate file that is not included. Small wiring labels and connector details require zooming.
