Evinrude E-TEC 40, 50, 60 & 65 HP Outboard Factory Service Manual, 2008 (P/N 5007525)
369 Pages • 1 Printable PDF (English) • Download
Evinrude Models Covered & Key Technical Specifications
Models: Evinrude 40 HP E-TEC, Evinrude 50 HP E-TEC, Evinrude 60 HP E-TEC, Evinrude 65 HP E-TEC
Models & Model Codes:
40 HP E-TEC — Tiller/Rope (E40DRLSCB), Tiller/Electric (E40DTLSCS), Remote/Electric (E40DPLSCB, E40DSLSCS)
50 HP E-TEC — Tiller/Electric (E50DTLSCS), Remote/Electric (E50DPLSCB, E50DSLSCS)
60 HP E-TEC — Tiller/Electric (E60DTLSCS), Remote/Electric (E60DPLSCB, E60DSLSCS)
65 HP E-TEC — Tiller/Rope (E65WDRLSCS, E65WDRYSCS)
Model Year: 2008
-
Engine displacement: 52.7 cu. in. (864 cc)
-
Engine configuration: In-line 2-cylinder, 2-cycle
-
Bore: 3.601 in. (91.47 mm)
-
Stroke: 2.588 in. (65.74 mm)
-
Full throttle operating range: 40 HP: 5000–6000 RPM; 50 and 60 HP: 5500–6000 RPM
-
Idle RPM in gear: 800 ± 50 RPM
-
Max cooling temperature: 212°F (100°C)
-
Gear ratio: 12:32 (.375)
-
Minimum battery: 640 CCA (800 MCA) or 800 CCA (1000 MCA) below 32° F
Evinrude Manual Features & Selected Content Preview
This BRP US Inc. factory service and repair manual covers the 2008 Evinrude 40, 50, 60, and 65 HP E-TEC outboards listed above. Manual P/N 5007525, copyright 2007.
Searchable Text, Bookmarks, and Wiring Diagrams
Text search and diagram detail: The manual text is searchable, and the PDF has 539 bookmarks. The cover text is outside the search layer. Small pin and connector labels on the engine wiring diagram are readable when enlarged. The cooling diagram legend on PDF p. 192 is cropped, and the complete legend appears on PDF p. 359.
One printable English PDF contains 369 pages, including 318 main-section pages, 24 safety pages, 8 index pages, 6 troubleshooting-chart pages, and 10 diagram and diagnostic-chart pages. The front cover, back cover, and one unnumbered blank page are included in that total.
E-TEC Fault Diagnosis and Outboard Overhaul
These are selected service topics from the manual. It also includes propeller selection and upper and lower engine cover service.
- EMM diagnostics: Fault code interpretation, cylinder drop testing, injector compensation, throttle position sensor calibration, and software replacement support diagnosis of starting and running problems.
- Electrical and ignition: Crankshaft and throttle position sensor tests, stator and charging checks, flywheel service, electric starter repair, and connector identification.
- Fuel injection: Pressure testing, injector removal and installation, manifold service, and vapor separator replacement, with a fuel circuit diagram and component illustrations.
- Oiling and cooling: Oil pump checks, priming, hose routing, thermostat testing, and water pump service.
- Powerhead and midsection: Disassembly, inspection, and reassembly of the powerhead, plus exhaust housing and tiller service and separate recoil starter procedures.
- Gearcase and trim: Lower unit leak testing, gear and bearing service, driveshaft shimming, and electrical tests for power trim and tilt.
The manual is intended for qualified, factory-trained marine technicians familiar with Evinrude/Johnson Special Tools.
EMM Fault Finding and Electrical Tests
The EMM Service Code Chart and Trouble Check Chart connect warning indications and symptoms with factory tests. Cylinder drop testing, combined with ignition and fuel checks, helps isolate a weak cylinder before selecting a repair.
The manual covers stored faults, injector compensation, and throttle position sensor calibration using Evinrude Diagnostics software and an interface cable. Engine Management Module (EMM) software replacement also requires the Bootstrap Tool. Connector pinouts and sensor resistance specifications support circuit testing. Internal EMM sensors are not individually serviceable.
Fuel Delivery, Oil Supply, and Cooling
Fuel and oil circuit diagrams accompany system tests and component service. The vapor separator is serviced as an assembly that includes the fuel circulation pump. The manual specifies cylinder assignment for each injector by serial number because incorrect installation can cause powerhead failure.
Hose routing and water flow diagrams trace coolant through the EMM and vapor separator. The fuel and ignition chapters include precautions for pressurized fuel spray and high-voltage circuits.
Powerhead, Gearcase, and Trim Repair
Powerhead procedures cover crankshaft journal measurements, piston and bearing inspection, and reassembly. Exploded illustrations and dressed powerhead views show component arrangement. Standard torque tables and assembly-specific tightening instructions cover fasteners. Incorrect rod cap tightening or assembly without the Rod Cap Alignment Fixture can permanently damage the connecting rod and crankshaft.
Step-by-step gearcase procedures cover pressure and vacuum leak testing, water pump overhaul, and driveshaft shimming with the specified gauge. Power trim-and-tilt service includes relay and motor tests, manual release valve service, and motor removal and servicing.
Rigging, Tiller Controls, and Scheduled Maintenance
Installation and predelivery procedures cover remote controls, outboard mounting, and adjustments, supported by battery and switch wiring and mounting-hole diagrams. Midsection and manual starter procedures include stern brackets, tiller controls, and recoil rope and spring service. Scheduled maintenance covers inspection intervals, lubrication, spark plug indexing, and self-winterization.
Selected Fuel Pressure, Sensor, and Ring Specifications
The fuel system pressure test specifies 20–35 psi with the outboard running. The crankshaft position sensor resistance test specifies 560 Ω ± 10% at 77°F (25°C).
For new piston rings, the powerhead inspection specifies a 0.011–0.023 in. end gap with each ring squared in its respective cylinder bore.
