Yamaha YFM350X & Raptor 350 ATV Service Manual Set, 1990 (P/N LIT-11616-07-50)

402 Pages • ZIP Download: Printable PDF • 82.43 MB

4.6starstarstarstarstar_half(5)
$18.30 Instant Download / No Shipping Fees
or

Credit/debit card, Apple Pay or Google Pay

30-day refunds for defective files or manuals not as described. Refund policy.

print
Save & print
Keep a copy on your device
lock
Secure Payment
Stripe

Yamaha Models Covered & Key Technical Specifications

Models: YFM350XA (base manual; technical specifications below), YFM350XE, YFM350XJ, YFM350XKC (California), YFM350XP, Raptor 350 (YFM350S)

Models & Model Codes:

YFM350XA — 3GD5

YFM350XE — 3GDB

YFM350XJ — 3GDK

YFM350XKC (California) — 3GDM

YFM350XP — 5NF4 (except California), 5NF5 (California)

Raptor 350 (YFM350S) — 5YT1 (USA and Oceania), 5YT2 (Canada), 5YT3 (Europe)

Model Year: 1990

Serial Numbers: YFM350XA starting numbers: 3GD-051101 (Engine), JY43GDW0*LC051101 (Frame)

YFM350XE starting numbers: 3GD-095101 (Engine), JY43GDA0*PA095101 (Frame)


  • Engine displacement: 348 cc

  • Engine type: 4-stroke, gasoline, SOHC, single cylinder

  • Compression ratio: 9.2:1

  • Bore x Stroke: 83 x 64.5 mm

  • Compression pressure: 850 kPa (121 psi) standard

  • Lubrication system: Wet sump

  • Transmission: Constant mesh, 6-speed forward, 1-speed reverse

  • Final drive: Chain

  • Drive chain type: 520V6/DAIDO, 98 links

  • Clutch type: Wet, multiple-disc

  • Starter system: Electric

  • Ignition system: C.D.I. Magneto

  • Front suspension: Double wishbone

  • Rear suspension: Swingarm (Link Suspension)

  • Tire size (F/R): AT21 x 7-10 / AT22 x 10-9

Yamaha Manual Features & Selected Content Preview

Publication Pages
YFM350XA Service Manual — P/N LIT-11616-07-50, first edition May 1990 266
YFM350XE Supplementary Service Manual — P/N LIT-11616-08-60 12
YFM350XJ Supplementary Service Manual — P/N LIT-11616-10-28 20
YFM350XKC (California) Supplementary Service Manual — P/N LIT-11616-10-89 9
YFM350XP Supplementary Service Manual — P/N LIT-11616-15-09 29
Raptor 350 (YFM350S) Supplementary Service Manual — P/N LIT-11616-17-57 66

The supplements provide model-specific changes and are used together with the included base manual. Later supplements also refer to the earlier supplements included here.

PDF Search, Bookmarks and Wiring Detail

Search and navigation: PDF pp. 308–402 have searchable text; pp. 1–307 have no searchable text layer. Internal bookmarks cover the base manual and supplements, but “Back to Main” points to a separate file outside this download. Small wiring labels require enlargement; the XA and XJ wiring sheets also need view rotation.

The ZIP contains one printable, English-language 402-page PDF. That total includes 42 title, introductory, index, and contents pages, five closing pages, and three pages containing only headers and page numbers.


Engine Overhaul, Chassis Repair and Electrical Diagnosis

The following selected workshop topics preview the contents, which also cover compression testing and toe-in adjustment.

  • Engine overhaul: Engine removal, cylinder-head and valve repair, piston inspection, crankshaft and balancer assembly, and oil-pump inspection.

  • Transmission and clutch: Crankcase separation, transmission and shift-fork inspection, reverse-drive components, clutch disassembly, wear checks, and assembly adjustments.

  • Carburetor service: Removal, disassembly, component inspection, float-height and fuel-level adjustment, throttle-cable adjustment, and model-specific carburetor data.

  • Chassis repair: Wheel-hub and rear-axle service, steering inspection, suspension removal, brake-caliper and master-cylinder repair, and hydraulic brake bleeding.

  • Electrical troubleshooting: Starting, charging, ignition, lighting, and indicator-circuit diagnosis, supported by circuit diagrams, switch-connection charts, and component test specifications.

Yamaha wrote these publications primarily for its dealers and qualified mechanics, assuming an existing understanding of mechanical repair concepts and procedures.

Engine Overhaul, Clutch and Transmission

Factory torque tables, fluid capacities, clearance specifications, and wear limits support internal component inspection.

Step-by-step repair procedures cover valve-guide replacement, valve-seat refacing, cam-chain timing, and starter-clutch inspection. The Crankshaft and Balancer Shaft and Transmission and Shifter exploded views identify internal components, while lubrication diagrams trace the engine’s oil passages.

Carburetors and Model-Specific Updates

The base manual covers the Mikuni BTM36SH, including the accelerator pump, coasting enricher, and throttle-cable wire cylinder. Its carburetor section view identifies the main, pilot, float, starter, and acceleration-pump systems. The YFM350S supplement adds BSR36 removal and disassembly information.

California YFM350XKC carburetor data is included. The XP supplement distinguishes carburetor identification marks 3GD 00 for non-California models and 3GD 10 for California models, helping match the specification table to the carburetor being serviced.

The XE supplement revises fuel-tank, lighting, wheel, cable-routing, and throttle-cable information. The XP supplement also updates piston and clutch specifications.

Starting, Ignition and Battery Diagnosis

The electrical sections detail C.D.I. ignition timing, starter motor resistance, and lighting system circuits. The Electric Starting System circuit diagram and troubleshooting chart cover the clutch, neutral, and drive-select interlocks, helping distinguish an interlock fault from a starter fault.

The XJ supplement explains the parking-brake engine revolution limiter. The XP supplement adds DC C.D.I. diagnosis, including pickup-coil and rotor-rotation detection-coil checks, and specifies DR8EA spark plugs in place of the base manual’s D8EA reference.

YFM350S coverage adds an updated wiring diagram and sealed MF battery charging charts. The base manual cautions that applying battery voltage to the C.D.I. unit during testing can damage it.

Rear Axle, Brakes and Suspension

Rear-axle procedures identify different tools: YM-37132 in the base manual and YM-37134 / 90890-01498 for YFM350S. The latter supplement warns that striking the axle end directly can damage its threads and splines.

YFM350S updates cover parking-brake cable adjustment, rear-caliper arm positioning, front-arm removal, and rear shock absorber and swingarm service. Brake work and handling the nitrogen-charged rear shock absorber require the manual’s safety precautions and appropriate workshop experience.

Selected Valve-Clearance and Pickup-Coil Specifications

For YFM350XA valve adjustment, the base manual specifies cold clearances of 0.06–0.10 mm at the intake valve and 0.16–0.20 mm at the exhaust valve. These values accompany the inspection and adjustment procedure.

For YFM350XP ignition diagnosis, the pickup-coil specification is 459–561 Ω at 20 °C (68 °F), identified by the White/Red and White/Green leads. The troubleshooting chart places this measurement within the checks for absent or intermittent spark.
