Need to fix, overhaul, or service your outboard engine? Download the Johnson Evinrude 60hp-235hp repair manual in PDF format for instant access to detailed instructions and information.
Specs:
Production/model years: 1973, 1974, 1975, 1976, 1977, 1978, 1979, 1980, 1981, 1982, 1983, 1984, 1985, 1986, 1987, 1988, 1989, 1990, 1991
Models or type: 60 hp - 235 hp
1986-1991: 60 HP, 3 cylinder
1973: 65 HP, 3 cylinder
1974-1991: 70 HP, 3 cylinder
1975-1985: 75 HP, 3 cylinder
1973-1980: 85 HP, 4 cylinder
1981-1991: 90 HP, 4 cylinder
1979-1980: 100 HP, 4 cylinder
1973-1984: 115 HP, 4 cylinder
1973-1976: 135 HP, 4 cylinder
1977-1991: 140 HP, 4 cylinder
1978-1991: 150 HP, 6 cylinder
1977-1983: 175 HP, 6 cylinder
1986-1991: 175 HP, 6 cylinder
1984-1985: 185 HP, 6 cylinder
1976-1983: 200 HP, 6 cylinder
1986-1991: 200 HP, 6 cylinder
1986-1991: 225 HP, 6 cylinder
1978-1985: 235 HP, 6 cylinder
Manual format: PDF / e-book (zip)
Manual Language: English
Pages: 403
Printable: Yes, all printers
Instant delivery: Download link will appear on the checkout page after your payment is complete.
#
³
Download PDF Manual and Parts List for 1973-1991 Johnson Evinrude 60hp-235hp Outboard Engine
Looking to repair or service your 1973-1991 Johnson Evinrude outboard engine? With the downloadable PDF manual and parts list, you'll have all the information you need at your fingertips. This comprehensive guide includes detailed instructions and technical specifications to help you get your engine running smoothly.
30 Engine Specs/Technical Specifications:
• Displacement: 56.1 cu. in. to 235 cu. in.
• Fuel Delivery: Carbureted
• Ignition: CDI
• Cylinder Configuration: V4, V6
• Bore x Stroke: 3.5 in. x 2.6 in. to 3.6 in. x 2.9 in.
• Compression Ratio: 8.6:1 to 9.4:1
• Horsepower: 60 to 235
• Cooling System: Water-cooled
• Lubrication System: Oil injection
• Gear Ratio: 1.85:1 to 2.1:1
• Shaft Length: 20 in. to 30 in.
• Weight: 204 lbs. to 475 lbs.
• Starting System: Electric
• Charging System: 35 amps
• Trim System: Power trim and tilt
• Steering: Remote or tiller
• Fuel Tank Capacity: 6 gal. to 24 gal.
• Alternator Output: 133 watts to 105 amps
• Maximum RPM: 4,600 to 5,200
• Number of Cylinders: 4 to 6
• Gear Shift: Forward, neutral, and reverse
• Exhaust System: Through prop
• Engine Type: 2-stroke
• Gearcase Lubricant Capacity: 12 oz. to 38 oz.
• Recommended Oil Type: TCW3
• Recommended Fuel Type: 87 Octane
• Fuel Induction System: Loop-charged
• Steering Angle: 30 degrees
• Ignition Timing: 10 degrees before top dead center
• Spark Plug Gap: 0.030 in. to 0.035 in.
About the 1973-1991 Johnson Evinrude 60 hp - 235 hp Outboard Engine: This series of outboard engines was designed to deliver reliable performance for boats of all sizes. With a range of horsepower options and cylinder configurations, these engines were versatile and well-suited for a variety of applications.
Buy the OEM Johnson Evinrude manual now and get instant access to detailed information on repairing and servicing your outboard engine. Simply click the green button on www.repairloader.com and pay using PayPal to get started.
After you've securely purchased your OEM Johnson Evinrude manual through www.repairloader.com using PayPal, we'll immediately email you all the information you need to download your manual. On the checkout page, you'll find the download link where you can quickly access and save your manual.
Price: 13.99 USD
