2010-2011 SsangYong Korando Service Manual
Technical reference for the SsangYong Korando transmission including detailed procedures. Documents system operations and maintenance steps. PN 3190-01
Manual Preview
Sample pages from the 2010-2011 SsangYong Korando Service Manual manual
Purchase & Download
Models Covered & Key Technical Specifications
SsangYong Korando (3190-01) 2010-2011 Service Manual
Technical reference for the SsangYong Korando transmission including detailed procedures. Documents system operations and maintenance steps. PN 3190-01 | Service Manual Binder.
- Overall length: 370 mm signifies the overall exterior dimensions of the transmission unit.
- Distance between shafts: 205 mm / 70 mm denotes the critical measurements for shaft alignment and placement.
- Weight (except transmission fluid): 62 kgf (2WD) / 63 kgf (4WD) represents the dry weight specification for the transmission assembly.
- 1st gear ratio: 3.538 indicates the ratio for the initial gear engagement and low-speed torque multiplication.
- Reverse gear ratio: 3.910 is the specified ratio for reverse operation, crucial for maneuvering.
- Capacity: 1.6 L is the transmission fluid capacity requirement for proper lubrication and cooling.
Professional Workshop Service Manual & Technical Specifications
SsangYong Korando 2010-2011 Service Manual: SsangYong Korando repair manual (2010-11) Technical-Guide
Engineering-Base: WM6F1 M/T // Engineering-Metrics: Korando 2010.10 / 6-SPEED M/T // Engineering-Base: Manual Transmission
| Integrated-Framework | System-Path | Context |
|---|---|---|
| 1. SPECIFICATION | Covers detailed component specifications. | Essential data for understanding the transmission's capabilities. |
| 2. TIGHTENING TORQUE | Lists critical torque specifications for assembly. | Ensures proper fastener tightening for durability. |
| 3. OVERVIEW | Provides a general understanding of the M/T. | Explains the basic design and function. |
| 4. POWER FLOWS | Details how power is transferred through gears. | Visualizes the mechanical operation of the transmission. |
| 5. SHIFTING MECHANISM | Describes the internal shift fork and rail system. | Explains how gears are selected and engaged. |
Service procedures are documented for the WM6F1 M/T, a manual transmission integrated with an axle for optimized driving performance. Careful attention is paid to its design, which maximizes driving performance by optimizing gear ratios according to engine torque. This manual details the complete internal configuration, including the primary and secondary output shafts, input shaft, and differential assembly.
Calibration requirements are specified for the transmission's components, ensuring precise operation. The manual details the gear ratios for all speed gears and the final drive, providing crucial specifications for engine and transmission matching. This comprehensive guide facilitates a thorough understanding of the transmission's workings and maintenance needs. Careful consideration is given to synchronizer mechanisms, including the triple, double, and single cone rings used for different gear speeds.
Electrical system documentation covers the control lever, neutral switch, and backup lamp switch functions, detailing their operation and integration with the engine ECU. The manual includes procedures for component identification and disassembly, such as the primary output shaft, secondary output shaft, and the reverse idle gear assembly. Careful attention is given to the assembly of gear components and the proper use of the synchronizer hub and sleeve.
Suspension service documentation covers the differential carrier assembly and its associated gears, seals, and spacers, ensuring proper assembly and alignment. Disassembly instructions are documented for all major transmission sub-assemblies, providing a step-by-step guide for technicians. The manual also provides essential information on troubleshooting common transmission issues, including noises and leaks, offering clear causes and corresponding repair actions.
The manual documents torque specifications for various mounting bolts and components to ensure proper dynamic load distribution, contributing to the transmission's reliability and longevity. The entire manual is structured to provide clear, actionable information for efficient and accurate service procedures, covering everything from initial removal to final assembly.
