OMC Models Covered & Key Technical Specifications

  • OMC Sterndrive — Models: 90 hp, 120 hp, 150 hp, 2.5L, 3.0L, 4.3L V6, 5.0L V8, 5.7L V8

Models & Model Codes:

90 hp — DU-12M, DUE-12M, DU-13B, DUE-13B, DU-14D, DUE-14D, DU-15S, DUE-15S, NUFR-12A, NUFM-12AX, NUFM-13M, NUFR-12AX, NUFR-13M.

120 hp — CU-13E, CUE-13E, SU-13E, SUE-13E, CU-14D, CUE-14D, CU-15S, CUE-15S, CU-16C, CUE-16C, CUTR-69M, CUFR-69M, CUTM-69M, CUFM-69M, CUTR-19E, CUFR-19E, CUTM-19E, CUFM-19E, CUFR-19EB, CUTR-19EX, CUTR-20D, CUFR-19EX, CUFR-20D, CUTM-19EX, CUTM-20D, GUFM-10S, VUFM-10S, GUFR-10S, VUFR-10S, GUFR-10C, VUFR-10C, GUFM-10C, VUFM-10C, GUFP-10C, VUFP-10C, 990215S, 990215F, 990207S, 990207F, 990207R, 990215R, 990224A, 990223A, 990224A11, 990235M, 990223A11, 990234M, 990235E, 990234E, 990243D, 990243H, 990242D, 990242H, 990243, 990242, 990242C, 990243C, 120FTHRCIS, 120FTHRCIF, 120STHRCIS, 120STHRCIF.

150 hp — HU-12M, HUE-12M, HU-12B, HUE-12B, HU-13E, HUE-13E, HU-14D, HUE-14D.

2.5L — 252FTHRCNC, 252FPHRCNC, 252STHRCNC, 252SPHRCNC, 252FTHRCTR, 252FPHRCTR, 252STHRCTR, 252SPHRCTR, 252FTHRCR, 252STHRCR, 252FTHRCO, 252STHRCO, 252FTHRCD.

3.0L — 302FTHRCNC, 302FPHRCNC, 302STHRCNC, 302SPHRCNC, 302FTHRCTR, 302FPHRCTR, 302STHRCTR, 302SPHRCTR, 302FTHRCR, 302STHRCR, 302SPHRCR, 302FTHRCO, 302STHRCO, 302SPHRCO, 302FTHRCD.

4.3L V6 — 2-barrel: 432FTMRCO, 432STMRCO, 432SPMRCO, 432FTMRCD; 4-barrel: 434FTMRCO, 434STMRCO, 434SPMRCO, 434FTMRCD.

5.0L V8, 2-barrel — 502STHRCNC, 502SPHRCNC, 502STHCCNC, 502SPHCCNC, 502STMRCNC, 502SPMRCNC, 502STMCCNC, 502SPMCCNC, 502STHRCTR, 502SPHRCTR, 502STHCCTR, 502SPHCCTR, 502STMRCTR, 502SPMRCTR, 502STMCCTR, 502SPMCCTR, 502FTHRCR, 502STHRCR, 502SPHRCR, 502FTHRCO, 502STHRCO, 502SPHRCO, 502FTHRCD.

5.0L V8, 4-barrel — 504STHRCNC, 504SPHRCNC, 504STHCCNC, 504SPHCCNC, 504STMRCNC, 504SPMRCNC, 504STMCCNC, 504SPMCCNC, 504STHRCTR, 504SPHRCTR, 504STHCCTR, 504SPHCCTR, 504STMRCTR, 504SPMRCTR, 504STMCCTR, 504SPMCCTR, 504FTHRCR, 504STHRCR, 504SPHRCR, 504FTHRCO, 504STHRCO, 504SPHRCO, 504FTHRCD.

5.7L V8 — 574STHRCNC, 574SPHRCNC, 574STHCCNC, 574SPHCCNC, 574STMRCNC, 574SPMRCNC, 574STMCCNC, 574SPMCCNC, 574STHRCTR, 574SPHRCTR, 574STHCCTR, 574SPHCCTR, 574STMRCTR, 574SPMRCTR, 574STMCCTR, 574SPMCCTR, 574FTHRCR, 574STHRCR, 574SPHRCR, 574FTHRCO, 574STHRCO, 574SPHRCO, 574FTHRCD.

Model Years: 1964–1986 (1964, 1965, 1966, 1967, 1968, 1969, 1970, 1971, 1972, 1973, 1974, 1975, 1976, 1977, 1978, 1979, 1980, 1981, 1982, 1983, 1984 1985, 1986)


Electromatic, mechanically assisted power-shift, and mechanical-linkage stern drives.

  • ----Point: 1964–1986; service procedures are separated by drive design.

  • Drive variants: Type-1 small lower unit for 88–90 hp and some 120 hp applications; Type-2 large lower unit without drivetrain shims; Type-3 large lower unit with drivetrain shims; 400 drives for 120/140 hp applications and 800 drives for larger-power applications.

OMC Manual Features & Selected Content Preview

This Seloc aftermarket repair manual covers OMC sterndrives and their gasoline engines across the 1964–1986 model years. It separates procedures where shift design, lower-unit construction, or engine family changes.

PDF Search, Chapter Bookmarks, and Diagram Detail

Search and drawing detail: An OCR text layer supports searches through much of the manual, but some tables and drawing pages are not reliably searchable. Embedded bookmarks open the contents, major chapters, appendix, and wiring section. Small wiring labels require magnification; some older diagrams have faint or broken lines that remain difficult to follow when enlarged.

The RAR download contains one printable, English-language PDF with 572 pages: five contents pages and 567 pages of chapters and appendices. The contents pages are already included in the total; there are no separate supplemental files.


Engine Overhaul, Gearcase Repair, and Shift Diagnosis

The following highlights are a selection of the manual’s contents, not a complete table of contents. Additional topics include propeller characteristics and corrosion control.

  • Drive generations: Electromatic units, mechanically assisted power-shift drives, and mechanical-linkage units, with separate early lower-unit and later 400/800 procedures.

  • Gearcase repair: Step-by-step removal, disassembly, inspection, reassembly, bearing shimming, propeller-shaft service, water-pump work, and final shift adjustment.

  • Engine overhaul: Engine removal and installation, cylinder-head reconditioning, piston-and-rod service, camshafts, crankshafts, main bearings, rear seals, and timing components.

  • Fuel and ignition: Single- and dual-diaphragm fuel pumps, carburetor rebuilding and bench adjustments, distributor service, contact-point checks, ignition timing, and spark-plug diagnosis.

  • Electrical systems: Charging-system diagnosis, starter overhaul and bench testing, gauges, warning lights, dual-battery installations, and model-specific wiring diagrams.

  • Controls, steering, and trim: Shift boxes, throttle cables, SelecTrim hydraulics, Tru-Course steering, mechanical steering, over-under helms, and tilt-mechanism repair.

  • Cooling and seasonal service: Water-flow and exhaust-gas checks, manifold inspection, thermostat replacement, intermediate-housing service, storage, and pre-season preparation.

The repair depth is best suited to experienced marine mechanics and advanced owners with suitable lifting, pressing, measuring, and electrical test equipment.

Drive Identification and Variant-Specific Tooling

Early-drive instructions distinguish Type-1, Type-2, and Type-3 lower units. The later chapters cover 400/800 construction and the transition from power-assisted shifting to mechanical linkage. These distinctions matter when selecting a gearcase, shim gauge, bearing tool, or overhaul procedure.

The later lower-unit material covers the shift converter and cable, power-assist servo, propeller shaft and shifter, driveshaft bearing housing, pinion-bearing race, oil pump, and forward gear. Cable indexing and operational adjustment are treated separately from internal assembly.

Tool references include shim gauge 314725, bearing-cup tools 314434/314436, press and holding tools 314437/314438, and drive gauges 908573/909078. The manual also identifies gauge 907971 for the later V6 applications and different pinion gauges for the 400 and 800 lower units: 315767 and 321520.

Coverage is for the ball-gear drive families described here. Cobra, King Cobra, and SX drive service requires a different manual.

Engine Families and Internal Repair

Engine chapters cover 153/181 CID four-cylinder and 250 CID inline-six engines; Buick/Kaiser/GM 225 CID V6 engines; later 229/262 CID V6 applications; GM small-block and Mark IV V8 engines; and Ford 302/351 CID V8 engines.

The later displacement designations include 2.5/3.0-liter four-cylinder, 3.8/4.3-liter V6, and 5.0/5.7-liter V8 configurations. Variant-specific material includes valve-lash or hydraulic-lifter-clearance checks, oil-pump service, manifold work, and mechanical troubleshooting. Engine specification tables, torque references, and spark-advance charts accompany the repair chapters.

Carburetors, Ignition, and Electrical References

Carburetor procedures distinguish Rochester BC, 2GC, and 4MV units, the Carter RBS, and Holley designs. The fuel chapter also explains dual-carburetor synchronization.

Distributor coverage includes Delco-Remy, Mallory, Autolite, and Prestolite units. Charging-system sections distinguish separate and integral regulators, while starter sections provide component inspection and bench-test information.

Illustrations include an OMC stern-drive sectional view, a 400/800 sectional view, exploded early-drive and later lower-unit drawings, the instrument-and-switch wiring diagram, and functional tilt, trim, and ignition circuits. Together with the troubleshooting sections, these references connect circuit faults and mechanical symptoms to the appropriate component tests.

Cooling, Intermediate Housing, and Repair Cautions

Cooling diagnosis uses water-flow and exhaust-gas checks to investigate overheating before component replacement. The water-pump section warns that exhaust leakage at the swivel housing can cause a replacement pump to fail. Upper-gearcase assembly instructions also warn that uneven tightening can damage the bearing-housing shims.

Intermediate-housing procedures cover the transom boot and ball-gear driveshaft, including bearing, seal, and spline inspection. The final maintenance chapter adds fiberglass and below-waterline care, off-season storage, and pre-season preparation.

Because the procedures include engine lifting, powered shift checks, fuel-system repair, and hydraulic/electrical work, use appropriate marine shop equipment and follow the manual’s safety precautions.

Examples of Shift-Circuit and Gearcase Test Data

For early Electromatic drives, the shift-coil circuit checks specify 4.5–6.5 ohms, measured with the ignition off, the control in neutral, and the shift leads disconnected. Separate forward and reverse checks help distinguish wiring and coil faults.

For the later drive-family leak test, the manual sets 15 psi as the maximum air pressure for the drained upper or lower unit. This is a test-pressure ceiling, not an operating-pressure specification; exceeding it can damage serviceable seals.
