2003-2007 Honda VTX1300S service manual

2003-2007 Honda VTX1300S service manual Preview image 1
2003-2007 Honda VTX1300S service manual Preview image 1
2003-2007 Honda VTX1300S service manual Preview image 2
2003-2007 Honda VTX1300S service manual Preview image 3
2003-2007 Honda VTX1300S service manual Preview image 4
2003-2007 Honda VTX1300S service manual Preview image 5
$18.99 (incl. VAT) - Instant Download
OR

File Specifications

  • File Size: 211.44 MB
  • File Type: ZIP
  • Language: English (some of our manuals are multi-language)
  • Printable: Yes
  • Estimated Download Time: 4.33 Minutes
verified_user
Lifetime Guarantee
Re-download anytime
flash_on
Instant Download
Get it immediately
lock
Secure Payment
PayPal & Bitcoin

Models Covered in this Manual

VTX1300S / Honda Motor Co., Ltd

  • 2003: VTX1300S
  • 2004: VTX1300S
  • 2005: VTX1300S
  • 2006: VTX1300S
  • 2007: VTX1300S

Product Information

Table of Contents

GENERAL INFORMATION

  • Service Rules
  • Model Identification
  • Specifications
  • Torque Values
  • Tools
  • Lubrication & Seal Points
  • Cable & Harness Routing
  • Emission Control Systems
  • Emission Control Information
  • Labels

FRAME/BODY PANELS/EXHAUST SYSTEM

  • Frame
    • Frame Inspection
    • Frame Repair
  • Body Panels
    • Panel Removal
    • Panel Installation
  • Exhaust System
    • Exhaust Pipe
    • Muffler
    • Catalytic Converter

MAINTENANCE

  • Maintenance Schedules
    • Schedule A
    • Schedule B
  • General Maintenance Procedures
    • Engine Oil Change
    • Tire Rotation
    • Brake Inspection

LUBRICATION SYSTEM

  • Engine Oil
    • Oil Specifications
    • Oil Change Procedure
  • Transmission Oil
    • Oil Specifications
    • Oil Change Procedure
  • Final Drive Oil
    • Oil Specifications
    • Oil Change Procedure

FUEL SYSTEM

  • Fuel Tank
    • Tank Removal
    • Tank Installation
  • Fuel Pump
    • Pump Removal
    • Pump Installation
  • Carburetor
    • Carburetor Adjustment
    • Carburetor Overhaul
  • Fuel Injection System
    • Injector Removal
    • Injector Installation

COOLING SYSTEM

  • Radiator
    • Radiator Removal
    • Radiator Installation
  • Water Pump
    • Pump Removal
    • Pump Installation
  • Cooling Fan
    • Fan Removal
    • Fan Installation

ENGINE REMOVAL/INSTALLATION

  • Engine Removal
    • Preparation
    • Removal Procedure
  • Engine Installation
    • Preparation
    • Installation Procedure

CYLINDER HEAD/VALVE

  • Cylinder Head
    • Removal
    • Installation
  • Valve Adjustment
    • Adjustment Procedure
  • Valve Replacement
    • Removal
    • Installation

CYLINDER/PISTON

  • Cylinder
    • Inspection
    • Repair
  • Piston
    • Inspection
    • Replacement

CLUTCH/GEARSHIFT LINKAGE

  • Clutch
    • Clutch Adjustment
    • Clutch Replacement
  • Gearshift Linkage
    • Inspection
    • Adjustment

CRANKSHAFT/TRANSMISSION

  • Crankshaft
    • Removal
    • Installation
  • Transmission
    • Removal
    • Installation

FINAL DRIVE

  • Final Drive Inspection
  • Final Drive Repair

FRONT WHEEL/SUSPENSION/STEERING

  • Front Wheel
    • Wheel Removal
    • Wheel Installation
  • Suspension
    • Inspection
    • Repair
  • Steering
    • Inspection
    • Adjustment

REAR WHEEL/SUSPENSION

  • Rear Wheel
    • Wheel Removal
    • Wheel Installation
  • Suspension
    • Inspection
    • Repair

HYDRAULIC DISC BRAKE

  • Brake Pads
    • Replacement
  • Brake Rotors
    • Replacement

BATTERY/CHARGING SYSTEM

  • Battery
    • Battery Maintenance
    • Battery Replacement
  • Charging System
    • Inspection
    • Repair

IGNITION SYSTEM

  • Spark Plugs
    • Replacement
  • Ignition Coils
    • Inspection
    • Replacement

ELECTRIC STARTER/STARTER CLUTCH

  • Starter Motor
    • Removal
    • Installation
  • Starter Clutch
    • Inspection
    • Replacement

LIGHTS/METERS/SWITCHES

  • Lights
    • Bulb Replacement
  • Meters
    • Inspection
    • Replacement
  • Switches
    • Inspection
    • Replacement

WIRING DIAGRAMS

  • Wiring Diagrams Overview
  • Specific Systems Wiring

TROUBLESHOOTING

  • General Troubleshooting Procedures
  • Engine Troubleshooting
  • Electrical Troubleshooting

INDEX
