2004-2008 Yamaha FZ6 Service and Repair Manual

Diagnostic procedures and component service for the Yamaha FZ6 models including FZ6-S, FZ6-N, and FZ6 Fazer S2. Ref: 978-1844267515

4.5starstarstarstarstar_half(2)
visibility Preview Available
Yamaha 2004-2008 Yamaha FZ6 Service and Repair Manual manual page preview - page 1 of 308

Sample pages from the 2004-2008 Yamaha FZ6 Service and Repair Manual manual

Yamaha 2004-2008 Yamaha FZ6 Service and Repair Manual manual preview page 1 - thumbnail
Yamaha 2004-2008 Yamaha FZ6 Service and Repair Manual manual preview page 2 - thumbnail
Yamaha 2004-2008 Yamaha FZ6 Service and Repair Manual manual preview page 3 - thumbnail
Yamaha 2004-2008 Yamaha FZ6 Service and Repair Manual manual preview page 4 - thumbnail
info_outline Click thumbnails to preview different pages
$17.10 (incl. VAT) Original OEM Factory Manuals & Data Instant Download / No Shipping Fees
OR BUY NOW
verified_user
Lifetime Access
Re-download anytime
flash_on
Instant Download
Get it immediately
lock
Secure Payment
PayPal
Technical Safety Notice
keyboard_arrow_down

This official OEM document is intended for professional technicians and skilled operators. Performing service on mechanical equipment involves inherent risks. By purchasing, you acknowledge that RepairLoader provides original manufacturer data for informational purposes. Always prioritize safety: use correct tools, wear protective gear, and consult a certified professional if you are uncertain of any procedure.

Yamaha Models Covered & Key Technical Specifications

Models: Yamaha FZ6-S, FZ6-N, FZ6 Fazer S2
Sub-models / Variants: FZ6-S Fazer, FZ6-N, FZ6-SA, FZ6-S2, FZ6-SA2
Build Years: 2004–2008
Serial Numbers: 1B31, 1B33/1835, 1B3B/1839, 1B3D, 5S31, 5S51, 5S41, 5S53, 5S42, 5VX1, 5VX6, 4P51, 4P52, 5VXL, 4P53/4, 4S81, 5S21, 4S86, 5S22, 5VX3, 5VX4, 5VX8, 5VX9, FZS6V, FZS6VC, FZS6W, FZS6WC, FZS6X, FZS6XC
Technical Data:

  • Engine: Four-stroke 16V in-line four, 599 cc
  • Compression ratio: 12.2 to 1
  • Cooling system: Liquid cooled
  • Transmission: Six-speed constant mesh, chain final drive
  • Fuel tank capacity: 19.4 liters
  • Front suspension: 43 mm oil-damped telescopic forks
  • Tyre sizes: 120/70 x ZR17 (front), 180/55 x ZR17 (rear)
Technical Specifications
keyboard_arrow_down
Document Number / Seller:
25436 / Daniel Bell
File Size:
99.59 MB
File Type:
PDF
Language:
English
Pages:
308
Printable:
Yes
Category:
Motorbike
Last updated / verified
May 19, 2025

Yamaha Manual Features & Content Preview

2004–2008 Yamaha FZ6 Service and Repair Manual

  • Covers 2004–2008 Yamaha FZ6, FZ6-N, and FZ6-S Fazer S2 models, detailing engine, chassis, and electrical system specifications
  • Official Haynes publication P/N 4751, 2008 edition
  • Contains 50+ full-color maintenance and service illustrations, torque setting tables, and electrical wiring diagrams
  • 308-page reference providing technical specifications and routine maintenance schedules
  • Delivered as a direct download the moment payment clears
  • File link appears in your order confirmation straight away
  • Page spreads stay legible when printed at original size
  • Indexed PDF search covers every chapter and appendix
  • This 2008 edition is the definitive reference for the full production run of the FZ6, capturing technical changes throughout the 2004–2008 model period

Maintenance and System Coverage

This 308-page publication details the maintenance requirements for the 2004–2008 Yamaha FZ6. Sections span routine maintenance for engine lubrication, cooling systems, brake fluids, and drive chain adjustment. Chapters break down components including the fuel system, air induction, and exhaust systems. Additional technical sections provide instructions for engine removal, clutch overhaul, and chassis adjustment, supporting detailed work on suspension and steering assembly. The manual documents identification numbers for all variants to assist in locating the correct parts.

Technical Data Preview

Engine oil capacity is specified at 2.5 liters for an oil change. Valve clearance for the intake is listed at 0.13–0.20 mm in the engine specification table. Coolant system capacity for the 2004–2008 Yamaha FZ6 is documented at 2.0 liters. Cylinder head bolt torque values are specified in a multi-stage sequence in the engine assembly data. The manual documents factory workshop procedures and technical data relevant for the FZ6 platform. Reference values for spark plug gaps, idle speed settings, and drive chain slack provide the necessary technical benchmarks for performance maintenance.

An official 308-page Yamaha OEM workshop manual covering the 2004–2008 Yamaha FZ6, documenting engine, chassis, electrical, and fuel-injection specifications for the full Fazer and naked model range.
