Suzuki Gladius 650 (SFV650) 2009 Service Manual (P/N 99500-36190-03E)
584 Pages • 1 Printable PDF (English) • Download
Suzuki Models Covered & Key Technical Specifications
Models: SFV650, Gladius 650
Sub-models / Variants: SFV650 K9 (E-02, E-03, E-19, E-24, E-28, E-33), SFV650UK9 (E-19, E-24)
Model Year: 2009
Serial Numbers: JS1CX111100100001– (SFV650 K9 E-02, E-19), JS1VP55A 92100001– (SFV650 K9 E-03, E-28, E-33), JS1CX111200100001– (SFV650 K9 E-24), JS1CX211100100001– (SFV650UK9 E-19), JS1CX211200100001– (SFV650UK9 E-24)
-
Engine: 4-stroke, liquid-cooled, DOHC, 90° V-twin
-
Displacement: 645 cm3
-
Compression ratio: 11.5 : 1
-
Fuel system: Fuel injection
-
Transmission: 6-speed constant mesh
-
Idle speed: 1 300 ± 100 r/min
-
Coolant capacity: 1 850 ml
-
Engine oil capacity (oil change): 2 400 ml
Suzuki Manual Features & Selected Content Preview
This Suzuki factory service manual covers the 2009 Gladius 650, including the SFV650 K9 and SFV650UK9 market variants. Suzuki identifies the manual as P/N 99500-36190-03E, dated January 2009, with a March 2009 revision mark in the table of contents.
Search, Bookmarks, and Wiring Detail
Finding service information: Searchable text and chapter and procedure bookmarks help you locate tests, specifications, and diagrams. Zoom in to read small wire codes, ECM pin numbers, and connector labels in the denser schematics.
The download is one printable English PDF with 584 pages, including two blank pages and Suzuki’s publication-information page.
Engine Overhaul, FI Diagnostics, and Chassis Service
This selection of service procedures gives a sense of the manual’s scope. The body and accessories section also covers combination meter and fuel level indicator checks.
- Scheduled maintenance: Periodic service intervals, lubrication points, valve clearance adjustment, and spark plug inspection and replacement.
- Engine overhaul: Step-by-step procedures for engine removal and installation, top- and bottom-end disassembly and assembly, cam timing, and cylinder head and crankshaft inspection.
- Fuel injection diagnostics: Dealer-mode and Suzuki Diagnosis System procedures, fault-code and fail-safe tables, sensor and actuator circuit tests, and post-repair reset functions.
- Fuel, cooling, and lubrication: Fuel pressure and pump tests, injector service, oil pressure checks, oil pump and jet service, and radiator, fan, thermostat, and water pump procedures.
- Starting, charging, and ignition: Starter motor and starter clutch service, generator and charging output checks, and ignition circuit testing.
- Transmission and chassis: Gearset and shift mechanism service, wet clutch and primary drive repair, chain and sprocket replacement, fork disassembly, bearing service, and hydraulic brake bleeding.
Suzuki wrote this manual for people with motorcycle service knowledge, practical skills, and the required equipment, including the specified special tools.
Market-Specific Wiring and FI Tests
Market differences: The E-33 California coverage includes EVAP hose routing, purge solenoid service, and the related fault code. The main motorcycle wiring diagram is labeled for E-03, E-28, and E-33. The separate FI System Wiring Diagram identifies ECM terminals and marks the E-33-only purge circuit.
Fault tracing: ECM terminal assignments, stored fault data, and voltage, resistance, and continuity checks help trace a fault to a sensor, connector, or wiring circuit. The manual includes CKP and IAP sensor tests and covers the throttle position, secondary throttle, coolant and intake air temperature, tip-over, gear position, and oxygen sensor circuits. Throttle body service includes throttle valve synchronization and idle speed control (ISC) learned-value reset.
Mechanical Inspection and Shop References
Engine and driveline: Compression and oil pressure checks support diagnosis before teardown. The engine section covers valve guide replacement, valve seat repair, piston and ring inspection, crankcase separation, and bearing selection for the connecting rods and crankshaft. The transmission and clutch sections detail the shafts, shift forks, shift cam, and clutch pack. The manual warns that uneven tightening of the camshaft journal holders can damage the thrust surfaces, and that unsuitable solvents can damage the sealed drive-chain O-rings.
Chassis and brakes: Coverage includes swingarm and wheel bearings, wheel balancing, rear suspension linkage, and steering stem bearings. Brake procedures are limited to conventional hydraulic front and rear disc systems and cover master cylinders, calipers, hose replacement, fluid service, and bleeding. The manual calls for leak and operational checks after service and warns to keep sparks and flames away during fuel-system work.
Diagrams and tools: The Camshaft and Sprocket Assembly Diagram, Engine Lubrication Circuit Diagram, cooling circuit and water hose diagrams, and front and rear brake hose routing diagrams complement the electrical schematics. Tool references include the SDS set (09904-41010), mode selection switch (09930-82720), TP sensor test lead (09900-28630), fuel pressure gauge adapter and attachment (09940-40211 and 09940-40220), fork oil level gauge (09943-74111), and drive-chain cutting and joining tool set (09922-22711). Service tables list torque values, wear limits, clearances, capacities, and recommended lubricants and sealants.
A Sample of Engine and Cooling Specifications
Suzuki specifies 25 N·m initially and 42 N·m finally for the M10 cylinder head bolts. The spark plug inspection section lists a gap of 0.8–0.9 mm.
The cooling system data give a thermostat opening temperature of about 76.5 °C (170 °F) and a radiator cap valve opening pressure of 93–123 kPa.
