Nissan-Datsun Truck PL720 1986 Service Manual & Bulletin Collection
641 Pages • 1 Printable PDF (English) • Download
Nissan Models Covered & Key Technical Specifications
Models & Model Codes: Datsun Truck (PL720)
Sub-models / Variants: 2WD, Z20 Engine, Gasoline; MPG (Z20, Non-California)
Transmission Sections: L3N71B automatic (model code X6365); FS5W71B manual (diagrams and removal/installation)
VIN Engine Identifier: 4th character F = Z20
Model Year: 1986
-
Engine: 2.0L SOHC L4
-
Ignition Coil Primary Resistance (Early Type): 1.0–1.2 ohms
-
Ignition Coil Secondary Resistance (Early Type): 7,300–11,000 ohms
-
Ignition Coil Primary Resistance (Late Type): 0.8–1.0 ohms
-
Ignition Coil Secondary Resistance (Late Type): 8,000–12,000 ohms
-
Voltage Drop (Wire): < 0.001 volts
-
Voltage Drop (Ground): Approx. 0.1 volts
-
Voltage Drop (Switch Contacts): Approx. 0.3 volts
-
Voltage Drop (Starter Solenoids): Approx. 0.5 volts
Nissan Manual Features & Selected Content Preview
| Publication | Pages |
|---|---|
| 1986 Nissan-Datsun Truck PL720 2WD/Z20 service-information compilation — ALLDATA 10.10 | 264 |
| Mixed-application service bulletin and recall collection, including a 141-entry index | 377 |
The service information covers vehicle diagnosis and selected repairs, while the bulletin collection adds application-specific corrections and service references. Check each bulletin’s Applied Vehicle statement before using it on the truck.
Coverage limits: This ALLDATA export is not a page-for-page reproduction of the original Nissan factory service manual. Its base service content is selective and does not provide a full internal Z20 engine-overhaul chapter.
PDF Search, Bookmarks, and Wiring Detail
Text search and diagram labels: Running text is searchable, but lettering inside many diagrams and specification images is not. Embedded bookmarks link to the main sections and numerous numbered subsections; individual bulletins do not each have a bookmark. Small wiring labels on the checked diagrams require zooming, and some drawings are sideways.
One printable English PDF contains 641 pages total, including the three bulletin-index pages.
Carburetor, Ignition, and Drivetrain Service
These are selected content highlights, rather than a complete contents list. Other examples include heater-core replacement and California/Federal emissions-maintenance-light reset information.
-
Ignition and fuel control: Distributor disassembly and replacement, timing references, dual-plug switching, early- and late-type coil testing, detonation-control checks, and fuel-pump circuit diagnosis.
-
Carburetor repair: Step-by-step DFP-342/384 disassembly, inspection, and assembly, with float, fuel-level, choke, throttle, idle-mixture, and BCDD adjustments.
-
Emissions and ECC: EGR, EVAP, PCV, catalytic-converter operation, high-altitude conversion, and control-unit, sensor, switch, heater, and solenoid circuit tests.
-
Automatic transmission: L3N71B identification, symptom diagnosis, removal and installation, brake-band and linkage adjustment, kickdown checks, torque-converter installation, and vacuum-diaphragm rod selection.
-
Manual transmission and clutch: FS5W71B diagrams, transmission removal and installation, clutch-pedal height and freeplay adjustment, and hydraulic-system bleeding guidance.
-
Axles and wheel bearings: Differential disassembly and setup, pinion-height and bearing-preload procedures, axle-shaft replacement, and application-specific hub and wheel-bearing work.
-
Electrical troubleshooting: DMM-based open-, short-, ground-, continuity-, and voltage-drop testing, supported by harness locations, connector references, wiring diagrams, and driveability troubleshooting charts.
This material is suited to professional technicians and experienced owners comfortable with a DMM, timing light, vacuum equipment, CO testing, and drivetrain setup tools.
ECC Diagnosis and Carburetor Repair
The electronically controlled carburetor material explains open- and closed-loop mixture control, fuel shutoff, idle-up, mixture heating, and spark-plug switching. Tests cover ECC power and ground circuits, exhaust-gas and coolant-temperature sensors, throttle and clutch switches, the altitude switch, air/fuel-ratio and anti-dieseling solenoids, and detonation control.
Fuel-pump diagnosis checks the pump alongside its power supply, grounds, oil-pressure-switch input, and alternator signal. This helps distinguish a pump fault from a problem in its control circuit.
The DFP-342/384 carburetor exploded view supports component identification during disassembly and assembly. Emission checks extend to thermal vacuum valves, EGR hardware, charcoal-canister purge control, the thermostatic air cleaner, and high-altitude components.
Carburetor cleaning cautions identify diaphragms, the float, electrical parts, and plastic bushings that solvent can damage; drills or wire can also damage calibrated passages.
Transmission and Axle Repair Depth
Automatic-transmission symptom charts connect starting, engagement, shift, kickdown, and lock-up complaints with possible faults. Shared charts also reference 3N71B, L4N71B, and E4N71B units, so the transmission identification matters when selecting a diagnostic entry.
Manual-transmission coverage is more selective, centering on FS5W71B transmission diagrams, removal and installation, and clutch adjustment. Rear-axle procedures extend to H190, C200, and H233B differential setup, with J25407 and J-34309 measuring-tool references.
Separate instructions distinguish single- and dual-rear-wheel axle shafts, 2WD hub and rotor assemblies, and selected 4WD locking-hub and front-drive components. Component-specific torque tables, fluid capacities, approved fluids, wear limits, clearances, and calibration data accompany the service material.
Wiring and Application Differences
Examples include the ECC Wiring Diagram, Fuse Panel & Power Distribution — Except Fuel Injected Engine, and Ignition System Wiring Circuit. Other circuits cover starting, charging, lighting, gauges, HVAC, wipers, and accessories.
Engine-compartment, passenger-compartment, and chassis-harness locations work with connector, splice, relay, symbol, and wire-color references for circuit tracing. Symptom charts address improper idle, hard starting, stalling, and driveability complaints.
Shared pages include 1982–86 Pickup procedures and California/Canada distinctions. Other entries cover 1986.5 trucks, dual rear wheels, 4WD, Z24i, and VG30i applications; match those entries to the actual equipment.
Bulletin Applications and Shop Cautions
The appendix combines Nissan bulletins, historical recalls, and third-party transmission references. Topics include 720/71B shift-boot contamination, parking-brake adjustment, tire-pressure-label corrections, and the 720 steering-column coupling-bolt recall.
Other material has different applications: driveline-vibration instructions identify 4x4 720 trucks, while the hesitation and shift-fork bulletins cover specified later vehicles. The 1986.5 shift-fork bulletin supplements TM86-002 and TM86-003. Later general guidance also covers brakes, charging systems, A/C service, fluids, and shop equipment.
The power rack-and-pinion steering bulletin warns that incorrect seal assembly can let rack teeth cut the oil-seal lip and cause leakage. Its stated steering-system application must be checked separately.
Support the vehicle and removed drivetrain components correctly, isolate the battery before electrical repair, and use approved refrigerant-recovery practices for the R-12 A/C system.
Sensor Resistance and Drive-Plate Inspection Preview
The Water Temperature Sensor Resistance Specifications chart gives 2.1–2.9 kΩ at 20°C (68°F) and 0.68–1.00 kΩ at 50°C (122°F), showing how the sensor’s expected resistance changes with temperature.
For automatic-transmission drive-plate inspection, the maximum allowable runout is 0.5 mm (0.020 in). This limit accompanies the dial-indicator inspection information.
